Sub-Zero IC-30RID-RH Use And Care Manual page 11

ST O R A G E
Freezer Storage
IC E CO NTA I NE R
The ice maker must be turned off by touching
the ice storage container is removed. The unit is equipped
with a 3-minute delay after the ice container is removed, to
ensure cubes are not ejected before the ice maker can be
deactivated or the ice container is reinstalled.
To remove the ice container (column model):
Pull the freezer basket open until it stops.
1
Lift the container out. Refer to the illustration below.
2
To remove the ice container (column combination model):
Pull the freezer basket open until it stops.
1
Slightly angle the container to lift out. Refer to the illus-
2
tration below.
Column ice container
when
Column combination ice
container
To remove the ice container (tall and drawer models):
Pull the freezer basket open until it stops.
1
Lift the container out. Refer to the illustration below.
2
Tall and drawer ice container
subzero.com | 11
