- Page 1 Washing Machine User’s Manual WTV 9732 XS0 Document Number= 2820524971_EN / 15-02-16.(8:54)
-
Page 2: Important Instructions For Safety And Environment
1 Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack expe- rience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 3: Intended Use
• Use detergents, softeners and supplements suitable for automatic washing machines only. • Follow the instructions on the textile tags and on the detergent package. • The product must be unplugged during installation, maintenance, cleaning and repai- ring procedures. • Always have the repairing procedures carried out by the Authorized Service Agent. Manufacturer shall not be held liable for damages that may arise from procedures ca- rried out by unauthorized persons. • If the power cable is damaged, it must be replaced by the manufacturer, after sales service or a similarly qualified person (preferably an electrician) or someone designa- ted by the importer in order to avoid possible risks. • Place the product on a rigid, flat and level surface. -
Page 4: Disposing Of The Waste Product
1.5 Disposing of the waste product • This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Therefore, do not dispose the product with normal domestic waste at the end of its service life. Take it to a collection point for the recycling of electrical and electronic equipment. Please consult your local authorities to learn the nearest collection point. -
Page 5: Removing The Transportation Locks
Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future. Never move the product without the transportation safety bolts properly fixed in place! 2.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. -
Page 6: Electrical Connection
• The hose should be attached to a height of at least 40 2.7 Electrical connection cm, and 100 cm at most. Connect the product to a grounded outlet protected by a 16 • In case the hose is elevated after laying it on the floor A fuse. Our company shall not be liable for any damages level or close to the ground (less than 40 cm above the that will arise when the product is used without grounding in ground), water discharge becomes more difficult and the accordance with the local regulations. laundry may come out excessively wet. Therefore, follow • Connection must comply with national regulations. - Page 7 3 Preparation sections “Important safety instructions” and “Installation”. To prepare the product for washing laundry, perform first 3.1 Sorting the laundry operation in Drum Cleaning programme. If your product • Sort laundry according to type of fabric, colour, and is not equipped with Drum Cleaning programme, perform degree of soiling and allowable water temperature. the Initial Use procedure in accordance with the methods • Always obey the instructions given on the garment tags. described under “5.2 Cleaning the loading door and the 3.2 Preparing laundry for washing drum” section of the user manual.
- Page 8 Using softeners – (*) in addition, there is siphon piece in the softener compartment. Pour the softener into the softener compartment of the detergent drawer. • Do not exceed the (>max<) level marking in the softener compartment. • If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer. Using liquid detergents If the product contains a liquid detergent cup: • Make sure that you have placed the liquid detergent cup in compartment nr. "2". • If the liquid detergent has lost its fluidity, dilute it with water before putting in the detergent cup. Detergent, softener and other cleaning agents • Add detergent and softener before starting the washing programme.
-
Page 9: Tips For Efficient Washing
Using bleaches Clothes • Select a programme with prewash and add the bleaching Colours agent at the beginning of the prewash. Do not put (Recommended temperature range based detergent in the prewash compartment. As an alternative on soiling level: cold -40 °C) application, select a programme with extra rinse and add the bleaching agent while the machine is taking water Powder and liquid detergents recommended for colours can be used at dosages from the detergent compartment during first rinsing step. -
Page 10: Operating The Product
4 Operating the product 4.1 Control panel 1 - Programme Selection knob (Uppermost position On / Off) 5 - Start / Pause button 2 - Display 6 - Auxiliary Function buttons 3 - Delayed Start Button 7 - Spin Speed Adjustment button 4 - Programme Follow-up indicator 8 - Temperature Adjustment button Dark wash Dark wash Cottons Pre-wash Main Rinse Wash Spin Delicate Pet hair Door Ready (Darkcare) (Darkcare) wash... - Page 11 4.2 Preparing the machine the remaining time indicator. • BabyProtect 1.Make sure that the hoses are connected tightly. This is a long lasting programme which you may use for 2.Plug in your machine. your laundry for which you require an anti-allergic and 3.Turn the tap on completely. hygienic washing at high temperature with intensive and 4.Place the laundry in the machine.
-
Page 12: Special Programmes
4.6 Special programmes For specific applications, select any of the following programmes. • Rinse Use this programme when you want to rinse or starch separately. • Spin + Drain Use this programme to apply an additional spin cycle for your laundry or to drain the water in the machine. Before selecting this programme, select the desired spin speed and press Start / Pause button. First, the machine will drain the water inside of it. -
Page 13: Programme And Consumption Table
4.9 Programme and consumption table Auxiliary functions Selectable temperature Programme range °C 60** 1.26 1400 40-60 Cottons Eco 60** 0.74 1400 40-60 40** 0.74 1400 40-60 2.54 1400 • • • Cold-90 Cottons 1.72 1400 • • • Cold-90 1.00 1400 •... -
Page 14: Auxiliary Function Selection
4.10 Auxiliary function selection 4. Press Start / Pause button. The delayed start time you have set is displayed. Delayed start countdown starts. “_” Select the required auxiliary functions before starting symbol next to the delayed start time moves up and down the program. Furthermore, you may also select or on the display. cancel auxiliary functions that are suitable to the running programme without pressing the Start / Pause button when Additional laundry may be loaded during the delayed the machine is operating. -
Page 15: Progress Of Programme
To deactivate the Child Lock: You may also change the speed and temperature settings; Press and hold 1 and 2 auxiliary function buttons for 3 see, "Spin speed selection" and "Temperature selection". seconds while any programme is running. The lights on the If no change is allowed, the relevant light will flash for 3 and 2 Auxiliary Function buttons will flash, and "C03", times. "C02", "C01" will appear on the display respectively while you keep the buttons pressed for 3 seconds. Then, "COFF" adding or taking out laundry will appear on the display indicating that the Child Lock is 1. Press Start / Pause button to switch the machine to... -
Page 16: Maintenance And Cleaning
5 Maintenance and cleaning Service life of the product extends and frequently faced problems decrease if cleaned at regular intervals. 5.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. If the holes on the bellow shown in the figure is blocked, open the holes using a toothpick. -
Page 17: Draining Remaining Water And Cleaning The Pump Filter
5.5 Draining remaining water and cleaning the 3 Some of our products have emergency draining hose and some does not have. Follow the steps below to discharge pump filter the water. The filter system in your machine prevents solid items such as buttons, coins and fabric fibers clogging the pump Discharging the water when the product does not impeller during discharge of washing water. -
Page 18: Technical Specifications
6 Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Model name WTV 9732 XS0 Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.255 Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0.738 Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0.738 Power consumption in ‘off-mode’ (W) 0.400 Power consumption in ‘left-on mode’ (W) 0.800 Annual Water Consumption (l) -
Page 19: Troubleshooting
7 Troubleshooting Program does not start after closing the door. • Start / Pause / Cancel button was not pressed. >>> *Press the Start / Pause / Cancel button. Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled. (See “Canceling the programme”) Water in the machine. - Page 20 www.beko.com...
Need help?
Do you have a question about the WTV 9732 XS0 and is the answer not in the manual?
Questions and answers
I cannot open the filter.
To open the filter on a Beko WTV 9732 XS0:
1. Unplug the machine to cut off power.
2. Wait for the water inside the machine to cool down, as it may reach up to 90°C.
3. Open the filter cap.
4. Turn the filter to remove it completely.
This answer is automatically generated
