Washing Machine
User Manual
WTV 9745 X0MA
Document Number
:
2820527539_EN/ 28-09-20.(8:14)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTV 9745 X0MA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beko WTV 9745 X0MA

Summary of Contents for Beko WTV 9745 X0MA

  • Page 1 Washing Machine User Manual WTV 9745 X0MA Document Number 2820527539_EN/ 28-09-20.(8:14)

  • Page 2: General Safety Instructions

    General safety instructions This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 Life and property safety Never place the product on a carpet-covered floor. Otherwise, lack of airflow beneath the machine will cause electrical parts to overheat.
  • Page 3 Laundry stained with Liquid cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers must be washed in hot water with plenty of detergent beforehand. After the washing programme, it can be used in the Refresh programme or in the Wash&Wear auxiliary function selection.

  • Page 4: Children's Safety

    In failures that cannot be repaired using information given in safety instructions, turn off the machine, unplug the power cable and call the Authorised Service Agent. The machine must not be used only in the Refresh programme for a long time.

  • Page 5: Electrical Safety

    Do not forget to close the loading door when leaving the room where the product is located. Store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package.

  • Page 6: Important Instructions For Environment

    Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling.

  • Page 7: Technical Specifications

    Technical specifications Supplier name or trademark Beko Model name WTV 9745 X0MA Rated capacity (kg) Maximum spin speed (rpm) 1400 Built-in Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Single Water inlet / Double Water inlet • / - •...

  • Page 8: Appropriate Installation Location

    4.1 Installation • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures.

  • Page 9: Connecting Water Supply

    Keep the transportation safety bolts in a safe place to reuse when the product needs to be moved again in the future. Install the transportation safety bolts in reverse order of the disassembly procedure. Never move the product without the transportation safety bolts properly fixed in place! 4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 –...

  • Page 10: Adjusting The Feet

    4.1.6 Adjusting the feet WARNING: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing, noise and vibration problems.
  • Page 11 4.2 Preparation 4.2.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the product.

  • Page 12: Correct Load Capacity

    4.2.5 Correct load capacity The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing programme. The product automatically adjusts the water amount according to the weight of the laundry put inside it. WARNING: Comply with the information in “4.3.3 Programme and consumption table”.
  • Page 13 Using softeners Pour the softener into the softener compartment of the detergent drawer. • Do not exceed the (>max<) level marking in the softener compartment. • If the softener has lost its fluidity, dilute it with water before adding it in the detergent compartment. WARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing machines to soften the clothes.

  • Page 14: Tips For Efficient Washing

    • Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. • Do not pour the bleach onto the laundry. • Do not use it with the colored items. •...

  • Page 15: Operating The Product

    4.3 Operating the product 4.3.1 Control panel WTV 9745 X0MA Cottons Cottons Cottons Eco Cottons Eco Refresh AntiCrease+ Refresh AntiCrease+ On / On / Hygiene+ Synthetics Synthetics Temperature Temperature Daily Express Daily Xpress StainExpert Xpress Super Short Xpress Super Short...

  • Page 16: Programme And Consumption Table

    4.3.3 Programme and consumption table Auxiliary functions Selectable temperature Programme range °C Cottons 60** Cold - 60 54,7 0,442 1400 Cottons Eco Cold - 60 54,7 0,442 1400 • Cold - 60 1,45 1200 • • • • Synthetics • Cold - 60 0,90 1200...

  • Page 17: Programme Selection

    4.3.4 Programme selection 1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with "Programme and consumption table". Programmes are limited with the highest spin speed appropriate for that particular type of fabric. When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
  • Page 18 • Hygiene+ Use this programme for your laundry for which you require an anti-allergic and hygienic washing at high temperature with intensive and long washing cycle. The high level of hygiene is ensured thanks to long heating duration and additional rinsing step. •...
  • Page 19 • Auto Program Use to wash frequently washable cotton, synthetic or blended (cotton+synthetic) clothes. Programme detects the type and quantity of the laundry to automatically adjust water consumption and programme time. CAUTION: Do not wash your woolen and delicate clothes in this programme. Select a suitable temperature if the temperature shown on the temperature display is not compatible with the warnings on the garment label.

  • Page 20: Temperature Selection

    4.3.6 Temperature selection Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the current programme. 88:88 1888 Press the Temperature Adjustment button to change the temperature.

  • Page 21: Rinse Hold

    If you want to spin your laundry after the Rinse Hold function: - Adjust the Spin Speed. - Press Start / Pause / Cancel button. The programme will resume. Machine drains the water and spins the laundry. If you want to drain the water at the end of the programme without spinning, use No Spin function. 88:88 No change can be made in programmes where spin speed adjustment is not allowed.

  • Page 22: Auxiliary Functions

    4.3.8.1 Auxiliary functions • Prewash A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time. • Fast+ When this function is selected, the durations of the relevant programmes get shorter by 50%. Thanks to the optimised washing steps, high mechanic activity and optimum water consumption, high washing performance is achieved in spite of the reduced duration.

  • Page 23: Starting The Programme

    4.3.9 End Time Time display Remaining time for the completion of the programme while it is running is displayed as “01:30” in hours and minutes format. Programme time may differ from the values in section "Programme and consumption table" depending on the water pressure, water hardness and temperature, ambient temperature, amount and the type of laundry, auxiliary functions selected and the changes at the mains voltage.

  • Page 24: Loading Door Lock

    4.3.11 Loading door lock There is a locking system on the loading door of the machine that prevents opening of the loading door in cases when the water level is unsuitable. "Door Locked" symbol appears on the display when the loading door is locked. Opening the loading door in case of power failure: In case of power failure, you can use the loading door emergency handle under the pump filter cap to open the loading door manually.

  • Page 25: Switching The Machine To Pause Mode

    If the water level in the machine is not suitable when you press Start/Pause button, the door lock cannot be deactivated and the door lock icon on the display remains on. 88:88 1888 If the temperature of the water inside the machine is above 50°C, you cannot deactivate the door lock for safety reasons, even if the water level is suitable.

  • Page 26: End Of Programme

    4.3.14 End of programme End symbol appears on the display when the programme is completed. If you do not press any button for 10 minutes, the machine will switch to OFF mode. Display and all indicators are turned off. Completed programme steps will be displayed if you press On / Off button. 4.3.15 Adjusting the VOLUME level Low volume and high volume Press and hold 1st and 2nd auxiliary function buttons for 3 seconds to adjust the volume level.

  • Page 27: Maintenance And Cleaning

    4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time.

  • Page 28: Draining Remaining Water And Cleaning The Pump Filter

    4.4.5 Draining remaining water and cleaning the pump filter The filter system in your machine prevents solid items such as buttons, coins and fabric fibers clogging the pump impeller during discharge of washing water. Thus, the water will be discharged without any problem and the service life of the pump will extend.

  • Page 29: Troubleshooting

    Troubleshooting Problem Cause Solution Programs do not start after the Start / Pause / Cancel button is not pressed. • Press Start / Pause / Cancel button. loading door is closed. It may be difficult to close the loading door in case of •...
  • Page 30 Problem Cause Solution Washing takes longer than Water pressure is low. • Product waits until taking in adequate amount specified in the user manual.(*) of water to prevent poor washing quality due to the decreased amount of water. Therefore, the washing time extends.
  • Page 31 Problem Cause Solution Washing performance is poor: Oily Regular drum cleaning is not applied. • Clean the drum regularly. For this, please see stains appeared on the laundry. “4.4.2 Cleaning the loading door and the drum” (**) Washing performance is poor: Odours and bacteria layers are formed on the drum as •...
  • Page 32 Problem Cause Solution Detergent residue in the detergent Detergent was put in wet drawer. • Dry the detergent drawer before putting in detergent. drawer. (**) Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
