- Page 1 LMM-100DMX User Manual...
- Page 2 T able of Contents Safety ..................2 Important Safety Instructions ............3 Precautions..................4 Suspension ..................4 Description ................5 ................Features ................Overview Installation ................6 Operation .................. 7 ..............DMX Channels Specifications................8...
- Page 3 Safety Important Safety Information WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE TO RAIN OR MOISTURE. WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING CONNECTION. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR ATTEMPT TO OPEN THE LIGHTING FIXTURE.
- Page 4 Precautions If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is well ventilated to help prevent overheating. Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C.
- Page 5 Description The LMM-100DMX is a versatile heavy-duty mirror ball motor that slowly spins your mirror ball giving you a great classic effect. Featuring DMX control that allows you to control the speed and rotation direction of your mirror ball motor. Made from high-quality materials, and designed to safely support your mirror ball over-head while allowing the ball to spin creating the traditional mirror ball effect.
- Page 6 To install your AVE LMM-100 follow the below steps; Step 1: The fixation holes are located on the base plate.
- Page 7 Operation To access the menus and functions of the LMM-100DMX, use the on board dipswitch control. Stand-Alone Operation In order to select Manual Mode, set DIP-switch 10 to OFF. Rotation speed can be selected via DIP-switch 1: 0.5 RPM = ON; 1 RPM = OFF.
- Page 8 Specifications Supported Mirror balls: Up to 50cm (20”) Max Load WLL (4-fold): 30kg Max Load BVG C1 (10-fold):: 12 kg DMX Channels: 1CH DMX Connectors: 3-Pin XLR Enclosure: Steel Power Consumption: 13W Power Supply: 240V AC / 50Hz Power Connectors: Fixed Mains Dimensions: 230 x 130 x 140 mm Weight: 3 kg...
