- Page 1 TRI-5 User Manual...
- Page 2 T able of Contents Safety ..................2 Important Safety Instructions ............3 Precautions..................4 Suspension ..................4 Description ................5 ................Features Setup ..................6 ..............Power Linking ................Mounting ................Operation ................Menu Map ..............DMX Channel Specifications................8...
- Page 3 Safety Important Safety Information WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE TO RAIN OR MOISTURE. WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING CONNECTION. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR ATTEMPT TO OPEN THE LIGHTING FIXTURE.
- Page 4 Precautions If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is well ventilated to help prevent overheating. Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C.
- Page 5 Also included is a yoke for hanging the par from stands, or lighting truss systems. The Tri-5 is supplied out of the box with ‘Auto’ programs including a ‘sound active’ mode for plug- and-play operation with an amazing visual effect. The Tri-5 can also be controlled via DMX for integration into larger lighting shows and setups with the 3-pin XLR connectors.
- Page 6 Mounting The Tri-5 is fitted with a yoke that can be attached to a floor stand for use on flat & sturdy surfaces. For hanging the fixture to a lighting stand or trussing, simply attach a lighting clamp to the yoke, ensuring that the clamp is tightened to prevent unwanted movement.
- Page 7 Menu Map Main Program Level Description Level Addr 1 – 512 DMX Address Value Chnd 3 Channel DMX Mode 7 Channel DMX Mode SLnd nASt Master Slave Mode 1 Slave Mode2 Slave Mode3 Slave Mode4 Shnd SoUn Sound Active Mode Auto Auto Programs Colo...
- Page 8 Specifications Light Source: 36 x 3W LED Diodes Diode Colours: Red, Green, Blue Beam Angle: 24° DMX Channels: 3CH / 7CH DMX Connectors: 3-Pin XLR Enclosure: Metal Alloy Power Consumption: 120W Power Supply: 240V AC / 50Hz Power Connectors: IEC Mains Dimensions: 260 x 260 x 360 mm Weight: 2.0 kg...
