User Manual
MELAdem
MELAdem
Reverse osmosis unit
EN
Dear customer,
We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated
family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice-
based use. Our focus on innovation, quality and the highest standards of operational reliability has established MELAG
as the world's leading manufacturer in the instrument reprocessing and hygiene field.
You, our customer are justified in your demand for the best products, quality and reliability. Providing
hygiene"
and
"Quality – made in
agement system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in ac-
cordance with EN ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance with
strict quality criteria.
The MELAG management and team.
®
56
®
56 M
Germany", we guarantee that these demands will be met. Our certified quality man-
"competence in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELAdem 56 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MELAG MELAdem 56

  • Page 1 Reverse osmosis unit Dear customer, We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice- based use.
  • Page 3: Table Of Contents

    Contents Contents 1 General guidelines ................................ 4 Symbols used.................................. 4 Formatting rules ................................... 4 Disposal .................................... 4 2 Safety..................................... 5 3 Product description................................ 6 Intended use .................................. 6 Mode of functioning................................ 6 Scope of delivery.................................. 6 Views MELAdem 56................................ 7 Views MELAdem 56 M................................. 8 4 Setup and installation ................................ 10 Installation location................................ 10 Space requirements ................................ 10 Cold water connection................................ 10 Connection of the reverse osmosis unit .......................... 10 5 Commissioning................................... 15...
  • Page 4: General Guidelines

    Make sure that you always have access to digital or printed version of the user manual. Should the manual no longer be legible, is damaged or has been lost, you can download a new copy from MELAG down- load centre at www.melag.com.
  • Page 5: Safety

    MELAG-authorized technical customer ser- vice. Consumables and spare parts Only use original MELAG consumables and spare parts. The use of foreign parts may result in damage and loss of warranty.
  • Page 6: Product Description

    The reverse osmosis units MELAdem 56 and MELAdem 56 M are not a medical device within the meaning of European Regulation 2017/745 on medical devices.
  • Page 7: Views Meladem 56

    3 Product description Views MELAdem 56 10 11 Pos. Designation Description Power supply Supplies the pump with current. Power connector Supplies the power supply with current. Dirt filter Filters the through flowing water to protect the pump. Pressure switch Controls the power supply of the pump. Prevents e.g. a too high pressure increase in the pressure tank.
  • Page 8: Views Meladem 56 M

    3 Product description Views MELAdem 56 M Pos. Designation Description Dirt filter Filters the water flowing through to protect the pump. Osmosis module The core of the reverse osmosis unit. Power connector Supplies the power supply with current. Connection for outlet hose Through the outlet hose (length: 2 m, Ø 6/4 mm) the concentrate is discharged via the steam sterilizer into the wastewater.
  • Page 9 3 Product description Pos. Designation Description Recessed grip Acts as a carry aid for transport purposes. Permeate line The permeate line (Ø 6/4 mm) runs from the ion exchanger to the pressure tank. Shut-off valve Serves for closing the pressure tank. Manometer Displays the current feed water pressure in the pressure tank.
  • Page 10: Setup And Installation

    Make sure that the temperature along the inlet hose does not rise above 40 °C. If the room in which the water treatment unit is installed does not have a floor drain, MELAG recommends a leakage water detector (e.g. water stop from MELAG), which shuts off the water supply in the event of damage via a moisture sensor on the floor and with the help of a solenoid valve.
  • Page 11 4 Setup and installation Connection of the MELAdem 56 NOTICE Ensure that the hoses do not suffer kinking or crushing. Switch off the steam sterilizer at the power switch. Measure the primary pressure at the pressure tank with the delivered manometer. The target pressure is 0.6 bar. Should the primary pressure of an empty pressure tank exceed this value, reduce the pressure by pressing in the valve tappet.
  • Page 12 4 Setup and installation Connect the feed water hose (pos. b), the outlet hose (0.7 m, pos. c) and the inlet hose (pos. d) onto the connections on the floor trough of the steam sterilizer. Hang the reverse osmosis unit on the screws of the spacers (pos. e ) on the rear wall in the floor unit.
  • Page 13 (pos. j) on the underside of the steam sterilizer and fold over the safety latch. Connection of the MELAdem 56 M Switch off the steam sterilizer at the power switch. Remove the valve cap (pos. a) on the rear side of the pressure tank and measure the primary pressure using the delivered manometer.
  • Page 14 4 Setup and installation Connect the outlet hose (pos. b) and the inlet hose (pos. c) onto the connections on the floor trough of the steam sterilizer. Cliniclave 45 M: Place the hoses over the bracket (pos. d) in the rear area of the steam sterilizer towards the front and out of the floor unit.
  • Page 15: Commissioning

    Do not operate the water treatment unit for a long period unsupervised, e.g. over night. This could void the insurance cover for the building. MELAG accepts no liability for any damage that may occur due to unsupervised operation.
  • Page 16: Rinsing And Checking The Meladem 56 M

    Do not operate the water treatment unit for a long period unsupervised, e.g. over night. This could void the insurance cover for the building. MELAG accepts no liability for any damage that may occur due to unsupervised operation.
  • Page 17: Checking The Operating Pressure

    5 Commissioning Checking the operating pressure Perform regular checks of the pressure on the pressure tank manometer before first program start. With daily operation, the pressure tank is still sufficiently full from the previous day. The blue pointer shows the current pressure of the water treatment unit. The red pointer is used to check the maximum pressure of the water treatment unit.
  • Page 18: Maintenance

    6 Maintenance 6 Maintenance Maintenance intervals Interval Measure Daily ▪ Check the permeate with a conductivity meter or with the built-in conductivity measurement of the steam sterilizer. ▪ Check the pressure in the pressure tank via the manometer. Every 12 months ▪...
  • Page 19: Removing And Attaching The Filter Containers

    6 Maintenance Removing and attaching the filter containers Removing a filter container Start the program Conductivity meas. for depressurising the unit. Switch off the steam sterilizer and close the pressure tank shut-off valve. Guide the container key (pos. a) from bottom to top over the filter container (pos. b).
  • Page 20: Replacing The Fine Filter

    Replacing the fine filter PLEASE NOTE Only use original MELAG consumables and spare parts. The use of foreign parts may result in damage and loss of warranty. Replace the cartridge of the mechanical fine filter (pre-filter) once a year. If there is a high pressure loss, filling the pres- sure tank takes more time.
  • Page 21: Replacing The Activated Carbon Filter

    Replacing the activated carbon filter PLEASE NOTE Only use original MELAG consumables and spare parts. The use of foreign parts may result in damage and loss of warranty. Replace the cartridge of the activated carbon filter once a year or when replacing the fine filter.
  • Page 22: Replacing The Mixed-Bed Resin Cartridge

    Replacing the mixed-bed resin cartridge PLEASE NOTE Only use original MELAG consumables and spare parts. The use of foreign parts may result in damage and loss of warranty. When the mixed-bed resin is exhausted (poor permeate quality), replace the mixed-bed resin cartridge.
  • Page 23: Cleaning The Filter Insert Of The Dirt Filter

    6 Maintenance Cleaning the filter insert of the dirt filter Switch off the steam sterilizer at the power switch. Close the pressure tank shut-off valve. Start the program Conductivity meas. for depressurising the unit. Loosen the screws (TX20) from the cover of the osmosis module and pull the cover upwards.
  • Page 24: Technical Data

    7 Technical data 7 Technical data Product type MELAdem 56 MELAdem 56 M Product dimensions (H x W x D) 44.4 x 50 x 17.3 cm 48.1 x 50 x 70 cm Total unit weight with filters approx. 18 kg (incl. pressure tank) approx.
  • Page 25: Accessories And Spare Parts

    8 Accessories and spare parts 8 Accessories and spare parts You can obtain the specified articles and an overview of further accessories from your stockist. Category Article Art. no. Accessories and Mixed-bed resin cartridge ME37470 consumables Fine filter ME37450 Activated carbon filter ME37460 Osmosis module (100 gpd, incl.
  • Page 26: Glossary

    The term “authorised technician” refers to an employee of a customer service provider or stockist who has been trained and authorised by MELAG to perform maintenance and installation work on MELAG devices. Only they may carry out this work. Conductivity...
  • Page 28 MELAG Medizintechnik GmbH & Co. KG Geneststraße 6-10 10829 Berlin Germany Email: info@melag.com Web: www.melag.com Original instructions Responsible for content: MELAG Medizintechnik GmbH & Co. KG We reserve the right to technical alterations Your stockist...
