- Page 1 Assembly and Usage Instructions MultiTower S-PLUS 1T and 2T CompactMaster S-PLUS 1T and 2T 3 05/2021 No 291350...
-
Page 3: Table Of Contents
2.4 Other applicable safety instructions ..........9 2.5 Technical data .................. 9 2.6 General assembly instructions MultiTower S-PLUS 1T and 2T ... 10 2.7 Overview of scaffolding types MultiTower S-PLUS 1T and 2T ..15 2.8 General assembly instructions CompactMaster S-PLUS 1T and 2T ....................17 2.9 Overview of scaffolding types CompactMaster S-PLUS 1T... -
Page 4: General Information
(see Section 1.2). 1.2 Manufacturer ZARGES GmbH Tel.: +49 8 81 / 68 71 00 Fax: +49 8 81 / 68 72 95 PO Box 16 30 Email: zarges@zarges.de... -
Page 5: Date Of Issue
The operator bears sole responsibility for ensuring • that the safety regulations are adhered to, • that improper use (see Section 1.8), faulty setting up and impermissible operation are excluded and thus • ensuring that the equipment is put to its intended use (see Section 1.7) and •... -
Page 6: Assembly
Assembly 2.1 Safety regulations 1. Do not stand on the frame of the folding unit! Use only platforms, the rungs or a climbing aid to climb the scaffold unit. 2. Only undamaged and fault-free original spare parts for the manufacturer's scaffold system referred to in the inspection certificate may be used. -
Page 7: Usage Regulations
13. Work on the working platform is only permitted with complete 3-part side protection, i.e. guard-rail frames, knee protection and peripheral toeboards. Toeboards are not necessary on the rest platforms. 14. When setting up the scaffold unit against a wall, stand-off brackets can also be used in addition to ballast (accessory, Order No. -
Page 8: Working On Electrical Equipment With The Scaffold Unit
29. The platform height must not be increased with the aid of ladders, crates or other devices. 30. Tools and materials may only be handed upwards. Always take the weight of tools and materials into consideration to avoid overloading the work platform. -
Page 9: Other Applicable Safety Instructions
2.4 Other applicable safety instructions The stipulations of DGUV information sheet 201-011 "Instructions for the Handling of Work Scaffolds and Protection Scaffolds" apply for the inspection, assembly and use of the scaffold unit. BGV C22 and the stipulations of DGUV information sheet 203-004 "Safety rules for the use of electrical equipment in the case of increased electrical hazard"... -
Page 10: General Assembly Instructions Multitower S-Plus 1T And 2T
Assembly is identical for all platform lengths (1.80 m / 2.50 m). For the height of the push-on end frame (1 m or 2 m), see “Overview of scaffolding types MultiTower S-PLUS 1T and 2T” on page 15. Insert the swivel castors into the... - Page 11 The basic braces are only required for specific scaffolding types, (see “Overview of scaffolding types MultiTower S-PLUS 1T and 2T” on page 15). 2b. Connect push-on end frame with basic braces. Attach basic braces above and below the first rung. Attach and fasten the 2 m push-on end frame...
- Page 12 The diagonal braces are only required for scaffolding types with 1 m push-on end frame, (see “Overview of scaffolding types MultiTower S-PLUS 1T and 2T” on page 15). Insert diagonal braces. Insert both advanced guardrails on the top rung and lock.
- Page 13 Insert platform and lock it at two opposite points. Align the scaffold unit using a spirit level. Fit all four stabilisers. For the position of the stabilisers, see “Basic dimensions” on page 26. Attach the ballast weights, if required. For ballast weights, see “Parts list incl.
- Page 14 10. Repeat steps 3, 5 and 6 until the scaffold height is reached. 11. Attach the top platform in the centre and lock it at two opposite points. 12. Insert both end toeboards (U-profiles are open towards the top). 13. Push in the side toeboards on both sides.
-
Page 15: Overview Of Scaffolding Types Multitower S-Plus 1T And 2T
14. Hook in stirrup step. 2.7 Overview of scaffolding types MultiTower S-PLUS 1T and 2T 1 m push-on end frame The following scaffold towers are equipped with 1 m push-on end frames above the swivel castors. Length Braces / platform Rungs 1.80 m... - Page 16 2 m- push-on end frame The following scaffold towers are equipped with 2 m push-on end frames above the swivel castors. Length Braces / platform Rungs 1.80 m 2.50 m 52225 52226 1 to 1 52245 52246 1 to 1 52265 52266 52285...
-
Page 17: General Assembly Instructions Compactmaster S-Plus 1T And 2T
2.8 General assembly instructions CompactMaster S-PLUS 1T and 2T The illustrations show a set-up with single platform. Assembly is identical for a double platform. Insert the swivel castors into the folding unit and fasten them with omega springs. Pull the folding unit out fully until the hinge snaps into place audibly. - Page 18 The following step only applies for specific scaffolding types, (see “Overview of scaffolding types CompactMaster S-PLUS 1T and 2T” on page 24). 3a. Fasten the horizontal brace to the lowest rung. The following step only applies for specific scaffolding types, (see “Overview of scaffolding types CompactMaster S-PLUS 1T and 2T”...
- Page 19 For the height of the push-on end frame (1 m or 2 m), see “Overview of scaffolding types CompactMaster S-PLUS 1T and 2T” on page 24. Attach and fasten the push-on end frame on both sides. The following steps, 5aa to 5ac, only apply for specific scaffolding types, (see “Overview of scaffolding types...
- Page 20 5ab. Insert platform and lock it at two opposite points. 5ac. Insert advanced guardrail at the top rung on the opposite side from the folding frame and lock.
- Page 21 The following step only applies for specific scaffolding types, (see “Overview of scaffolding types CompactMaster S-PLUS 1T and 2T” on page 24). 5b. Insert the diagonal brace at rung 2. The next step only applies for the following folding frames, (see “Overview of scaffolding types CompactMaster S-PLUS 1T and 2T”...
- Page 22 Align the scaffold unit using a spirit level. Fit all four stabilisers. For the position of the stabilisers, see “Basic dimensions” on page 26. Attach the ballast weights, if required. For ballast weights, see “Parts list incl. ballasting” on page 29. 10. Attach and fasten the 2 m push-on end frame on both sides.
- Page 23 11. Insert both advanced guardrails and the platform (see steps 5aa to 5ac). 12. Repeat steps 10 to 11 until the scaffold height is reached. 13. Attach the top platform in the centre and lock it at two opposite points. 14.
-
Page 24: Overview Of Scaffolding Types Compactmaster S-Plus 1T And 2T
16. Hook in stirrup step. 2.9 Overview of scaffolding types CompactMaster S-PLUS 1T and 2T 1 m push-on end frame The following scaffold towers are equipped with a 1 m push-on end frame above the folding unit. Type Braces / platform Rungs 53099 53199... -
Page 25: Note On Dismantling The Scaffold Tower
2 m- push-on end frame The following scaffold towers are equipped with a 2 m push-on end frame above the folding unit. Type Braces / platform Rungs 2 to 6 53121 2 to 6 53221 2 to 6 53141 2 to 6 53241 6 to 6 2 to 6... -
Page 26: Basic Dimensions
2.11 Basic dimensions MultiTower S-PLUS 1T and 2T 1350 1800 / 2500 60° 60° 3378 3978 A [mm] B [mm] C [mm] Height-adjustable swivel castor (42917) min. 1085 2344 Height-adjustable swivel castor (42917) max. 1378 2637... - Page 27 CompactMaster S-PLUS 1T and 2T 1275 1800 1450 45° 45° 3016 3616 A [mm] B [mm] C [mm] Height-adjustable swivel castor (42759) min. 1593 2852 Height-adjustable swivel castor (42759) max. 1743 3002...
-
Page 28: Identification
2.12 Identification Type plate for folding frame and push-on end frame Maximum permissible load Maximum platform height Article number EAN code Type plate for all components apart from the folding frame and push-on end frame (e.g. braces, platforms) 42907 4 0 0 3 8 6 6 4 2 9 0 7 5... -
Page 29: Parts List Incl. Ballasting
2.13 Parts list incl. ballasting The parts list contains the designations of the individual parts, the corresponding weights, the article numbers of the individual parts, the number of individual parts contained in the complete scaffold tower and the article number of the complete scaffold tower. - Page 30 MultiTOWER S-PLUS 1T, single platform 0.75 x 2.50 m Scaffold size [m] 0.75 x 2.50 Working height approx. 3.40 4.50 5.35 6.45 7.30 8.40 9.25 10.40 11.20 12.35 13.20 Weight [kg] 105.9 132.5 168.8 182.8 219.1 233.1 277.8 291.8 328.1 342.1 378.4 Parts list Order No.
- Page 31 MultiTower S-PLUS 2T, double platform 1.35 x 1.80 m Scaffold size [m] 1.35 x 1.80 Working height approx. 3.40 4.50 5.35 6.45 7.30 8.40 9.25 10.40 11.20 12.35 13.20 Weight [kg] 105.6 140.7 190.5 197.1 242.5 248.5 293.9 300.5 345.9 352.5 397.9 Parts list Order No.
- Page 32 MultiTower S-PLUS 2T, double platform 1.35 x 2.50 m Scaffold size [m] 1.35 x 2.50 Working height approx. 3.40 4.50 5.35 6.45 7.30 8.40 9.25 10.40 11.20 12.35 13.20 Weight [kg] 124.0 161.8 218.4 236.2 292.8 319.0 375.6 393.4 450.0 467.8 524.4 Parts list Order No.
- Page 33 CompactMaster S-PLUS 1T, single platform 0.85 x 1.80 m Scaffold size [m] 0.85 x 1.80 Working height approx. 3.75 4.60 5.70 6.55 7.65 8.50 9.60 10.45 11.60 12.40 13.55 Weight [kg] 105.8 123.6 147.8 169.6 189.8 216.0 231.8 249.6 273.8 291.6 315.8 Parts list Order No.
- Page 34 CompactMaster S-PLUS 2T, double platform 1.45 x 1.80 m Scaffold size [m] 1.45 x 1.80 Working height approx. 3.75 4.60 5.70 6.55 7.65 8.50 9.60 10.45 11.60 12.40 13.55 Weight [kg] 108.1 161.4 189.4 225.0 250.7 284.0 312.0 345.3 373.3 406.6 434.6 Parts list Order No.
-
Page 35: Assembly Drawings
2.14 Assembly drawings MultiTower S-PLUS The assembly structure illustrated is merely an example. The actual structure of the scaffold unit may differ. Advanced guardrail Side toeboard Push-on end frame Triangular stabiliser Horizontal brace Swivel castor Diagonal brace End toeboard... - Page 36 CompactMaster S-PLUS The assembly structure illustrated is merely an example. The actual structure of the scaffold unit may differ. Advanced guardrail Side toeboard Push-on end frame Folding unit Triangular stabiliser Swivel castor Platform Diagonal brace End toeboard...
-
Page 37: Structural Safety Regulations
Structural safety regulations 3.1 General information Chassis beams and stabilisers ensure that the scaffold tower is stable. However, depending on the place of deployment (indoor / outdoor use), these may need to be fitted with ballast weights. For the ballasting, see “Parts list incl. ballasting” on page 29 (lower section of the tables) 3.2 Attaching the ballast Where the ballast weights are attached and how many of them are required depend... -
Page 38: Maintenance, Servicing, Storage And Cleaning
3.4 Maintenance, servicing, storage and cleaning The scaffold unit can be cleaned using water with a little household cleaning agent added. Paint spots can be removed using turpentine. Cleaning agents must not be allowed to seep into the soil. • Dispose of used cleaning fluids in accordance with the applicable environmental regulations. - Page 39 Swivel castors • Check the castor for smooth running and check that the brake stops the castor rolling or twisting. • In the case of swivel castors with height adjusters, also check that the height adjusters move easily. • Check the drop-out protection (wing bolt, securing plug) on the chassis beams and base frame.
-
Page 40: Spare Parts
Spare parts Designation Art. no. Figure Designation Art. no. Figure Folding frame unit, 42947 Folding frame unit, 42948 single platform double platform Push-on end frame 42905 Push-on end 42902 1 m, single platform frame 1 m, double platform Push-on end frame 42904 Push-on end 42901... - Page 41 Designation Art. no. Figure Designation Art. no. Figure Basic brace Advanced guardrail 1.80 m 42886 1.80 m 42837 2.50 m 42887 2.50 m 42838 3.00 m 42888 3.00 m 42839 End toeboard Side toeboard 0.75 m 42913 1.80 m 42943 1.35 m 42911 2.50 m...
- Page 42 ZARGES GmbH Tel.: +49 8 81 / 68 71 00 Fax: +49 8 81 / 68 72 95 PO Box 16 30 Email: zarges@zarges.de D-82360 Weilheim Internet: http://www.zarges.de...
