Lumena PROSOLAR HELIOSOL User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
•
If a fitting is found to be damaged, cease use immediately.
•
Contains batteries – avoid extreme heat/ fire and recycle sensibly – check with your local authority or retailer for further advice.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light, especially when mounting it in high places.
•
Secure all cabling, leaving slightly slack.
•
All connections should be made as watertight as possible to avoid electrical shortage.
•
Do not modify this fitting or it may void any warranty and result in an unsafe product. Always consult the manufacturer.
•
Ensure all mounting instructions are followed.
•
Ensure the fitting is mounted out of range of head height to avoid injury.
•
The unit will not charge correctly if the panel is behind glass or in artificial light.

SPECIFICATIONS

Wattage: 200W // 300W // 400W
LEDs: In-built Caiting SMD 2835 LEDs (60˚ Beam Angle) 200W = 126pcs / 300W = 198pcs, 400W = 198pcs
Colour Temperature: 6000K (Daylight)
Lumen Output: 2600lm // 3800lm // 4800lm
LED Life Expectancy: 20,000 hours (approx.)
Function: Variable – see remote control settings
Light Sensor LUX Level: 5 lux (approx.)
IP Rating: IP65
Battery Type: LiFePO4 (Lithium)
200W (4pc) = 3.2V 20AH, 300W (6 pcs) = 3.2V 30AH, 400W (8 pcs) = 3.2V 40AH
Battery Charge Time: 4-6 hours (approx.)
Solar Panel: Monocrystalline 200W = 5V 20W, 300W = 5V 30W, 400W = 5V 40W
Max Illumination Time at Full Charge: 12-14 hours (varies by function, location,
weather and seasonal light conditions)
Cable Length: 2m (approx.) plug & play
Materials: Die Cast Aluminium, Steel, Tempered Glass
Mounting: Surface mount (adjustable brackets) – compatible with pole mounting clamps
Recommended Mounting Height: 3-5m
Remote Control: Infrared (up to 12m range) – requires 2 x AAA batteries (not included)
Working Temperature: -10˚C to 40˚C
Included: Flood Light, Solar Panel, 2x Bracket & Fixings, 1 x socket wrench, Remote Control, 4x Expanding Anchor Bolts
Accessories (optional): 4m extension cable available (plug & play), 76mm column bracket, 60mm column bracket
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt. To maintain
efficiency, specifically clean the solar panel and flood light lens on a regular basis. Also, keep the solar panel free of debris and snow to prevent
reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could damage the fitting. Please refer to our website
for more information on the best way to clean different materials.

RETURNS:

If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
rd
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us for more
information. Please recycle packaging whenever possible.
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
Full product range & more information: www.lumenalights.com
HELIOSOL Solar Flood Light (Remote Control)

WARNINGS

Tel: +44 1327 871161
USER MANUAL
5 YEAR
GUARANTEE
see website for
more details
Email: sales@lumenalights.com
✔✔✔✔✔
