Lumena Pro Solar Secursol User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 7W // 15W
Lamp: In-built LED SMD 2835 40 + 10pcs // 76 + 12pcs (100˚ Beam Angle)
Colour Temperature: Main = 6000K (Daylight) & Wall Wash = 3000K (Warm)
Lumen Output: 700 lm // 1500 lm
LED Life Expectancy: up to 35,000 hours
Sensor: PIR (Motion Sensor) + Photocell (Dusk to Dawn)
IP Rating: IP65
PIR Detection Range: 5-8m 120˚ beam angle
PIR Sensor Delay Time: approx. 20 seconds
Battery Type: Lithium Ion 18650 3.7v/5400mAh // 7.4v/5400mAh (replaceable)
Battery Charge Time: up to 12 hours (approx.)
Solar Panel: 7W = 3.7Wp // 15W = 7.3Wp Polycrystalline Silicon – Adjustable by 70˚
Max Illumination Time at Full Charge: 20hrs > 6 nights (varies by function)
Materials: ABS, Polycarbonate, Glass Solar Panel
Weight: 1.3KG // 2.5KG (approx.)
Mounting: Surface mount plate supplied (4 corner mounting)
Install Height: Up to 4m (recommended)
Remote Control: Infrared (up to 7m range) – 1 x 3v CR2025 battery included

WARNINGS

•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light, especially when mounting it in high places.
•
Ensure the fitting is mounted out of range of head height to avoid injury.
•
Fitting must be mounted to a solid surface
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface
dirt. To maintain efficiency, specifically clean the solar panel, LEDs and PIR on a regular basis. Also, keep the solar panel free of
debris and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could
damage the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

If purchased from a 3 rd party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
Producer Registration Number: WEE/KC3440XY
Secursol Adjustable PIR Solar Light (Remote Control)
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
233mm (7W)
310mm (15W)
190mm (7W) // 260mm (15W)
Tel: +44 1327 871161 Email: sales@lumenalights.com
USER MANUAL
100mm (7W)
127mm(15W)
✔✔✔
3 YEAR
GUARANTEE
see website for
more details
