Lumena PROSOLAR SECURBOL User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 7W
Lamp: In-built LED SMD 2835 40 + 10pcs (100˚ Beam Angle)
Colour Temperature: Main = 6000K (Daylight) & Wall Wash = 3000K (Warm)
Lumen Output: 700 lm
LED Life Expectancy: up to 35,000 hours
Sensor: PIR (Motion Sensor) + Photocell (Dusk to Dawn)
IP Rating: IP65
PIR Detection Range: up to 2m 120˚ beam angle
PIR Sensor Delay Time: approx. 20 seconds
Battery Type: Lithium Ion 18650 3.7v/5400mAh (replaceable)
Battery Charge Time: up to 12 hours (approx.)
Solar Panel: 7W = 3.7Wp Polycrystalline Silicon – Adjustable by 70˚
Max Illumination Time at Full Charge: 20hrs > 6 nights (varies by function)
Materials: ABS, Polycarbonate, Glass Solar Panel, Radiata Pine (pressure treated)
Weight: 9KG (approx.)
Mounting: Root Mounting
Path Light Height: 1200mm (400mm to be buried under ground)
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light.
•
Ensure the fitting is mounted out of range of head height to avoid injury.
•
Fitting must be installed as per the installation instructions or guarantee will be void.
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface
dirt. To maintain efficiency, specifically clean the solar panel, LEDs and PIR on a regular basis. Also, keep the solar panel free of
debris and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could
damage the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

If purchased from a 3 rd party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
Adjustable 800mm Radiata Pine Solar Path Light
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
USER MANUAL - SECURBOL

WARNINGS

Tel: +44 1327 871161
with PIR Sensor
✔✔✔
3 YEAR
GUARANTEE
see website for
more details
Email: sales@lumenalights.com
