Lumena PROSOLAR ENDURA User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 3W
LED: In-built Cree 2835 SMD3030 LED Chips 6*0.5w (120˚ Beam Angle)
Colour Temperature: 3000K (Warm White) or 6000K (Daylight White)
Lumen Output: Approx. 480 lm
LED Life Expectancy: up to 50,000 hours
Sensor: Light / Charge Sensor
Light Control Level: 20 Lux
IP Rating: IP65
Battery Type: Sinowatt Lithium Ion INR18650 Cell - 3.7v / 2200mAh 8.14Wh (replaceable)
Battery Charge Time: 6-8 hrs full sunshine (approx.)
Max Illumination Time at Full Charge: 10 Nights / Over 100hrs
Solar Panel: Highly efficient 1.2w (ETFE Laminated)
Materials: Extruded Aluminium Alloy & Polycarbonate
Weight: 0.68KG (excluding fixings / spike)
Mounting: External Surface Mount / Ground Spike
Lighting Function: COEUS Technology 1hr 100%, 2hrs 80%, 30% until dawn
Working Temperature: -25˚C ~ 65˚C
Included: 2x Anchor Bolts / 1x Ground Spike per fitting
UK REG NO: 6148067
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light.
•
Fitting must be mounted to a solid surface or using relevant anchor bolts / J-Bolts
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
•
Ensure the waterproof bung is in place at all times, other than when turning the unit on or off.
•
Due to temperature difference in and outside the fitting, condensation may be present internally but will not affect use.
CLEANING & MAINTENANCE:
Occasional cleaning and care is recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt.
To maintain efficiency, specifically clean the solar panel and polycarbonate lens on a regular basis. Also, keep the solar panel free
of debris and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could
damage the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

rd
If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
ENDURA Long Autonomy Solar Path Lights
Surface Mount & Ground Spike – 2 PACK

WARNINGS

Tel: +44 1327 871161
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
USER MANUAL
84mm
84mm
528mm
✔✔✔✔✔
5 YEAR
75mm
GUARANTEE
see website for
more details
75mm
unless ground spike is used.
,
Email: sales@lumenalights.com
