Lumena Radiata PACAMAN Instruction Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Transformer Required: 12v AC (wattage dependent on total wattage of circuit)
Lamp Holder: MR16 (lamp supplied)
Colour Temperature: 3000K (Warm White) / 6000K (Daylight White)
IP Rating: IP65
Cable: H05RN-F 2 core rubber cable open end (non-armoured) – approx. 1.4m
Materials: Radiata Pine, Anodised Aluminium, Tempered Glass
Treatment: Pressure treated with Tanalith E preservative in accordance
with BS8417 to meet Use Class 4
Weight: 15KG (approx.)
Mounting: Root Mount (bury 3-400mm under ground)
Included: Bollard light, replaceable MR16 (fitted), back panel / cable cover (optional),
10 x pins per back panel
UK REGISTERED DESIGN: 6249431
•
This is a Class 3 product (low voltage) no earth required.
•
12V TRANSFORMER REQUIRED – sold separately
•
This unit must be fitted by a competent person – if in doubt consult a qualified electrician.
•
Always use the correct type and wattage of 12v transformer.
•
To prevent electrocution, switch off mains supply before installing or maintaining this fitting. Ensure other persons cannot restore
the electrical supply without your knowledge.
•
This light fitting should be connected to a circuit with a 30Ma RCD fitted.
•
If replacing an existing fitting, make a careful note of the connections.
•
Always switch off at the mains & allow the fitting to cool before commencing any electrical work or changing the bulb.
•
Always use the correct type & wattage of bulb. Never exceed the wattage stated.
•
All connections should be made as watertight as possible to avoid electrical shortage.
•
The unit may get warm whilst on for a period of time.
•
If the luminaire or cable is found to be damaged, cease use immediately.
RETURNS & DISPOSAL:
rd
If purchased from a 3
If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or
contact us for more information. Please recycle packaging when possible.
THANK YOU FOR YOUR PURCHASE
party, please contact your supplier.
Full product range & more information: www.lumenalights.com
Radiata PACAMAN Timber Path Light 12v

WARNINGS

Tel: +44 1327 871161
Producer Registration Number: WEE/KC3440XY
INSTRUCTION MANUAL
95mm
200mm
(300 to 400mm
under ground)
GUARANTEE
see website for
Email: sales@lumenalights.com
1300mm
✔✔✔✔✔
5 YEAR
more details
