Lumena PRO SOLAR SIGNALITE User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 5w / 10w / 20w
Lamp: In-built Epistar LED x 24 / 48 / 96 chips
Colour Temperature: 6000-6500K (Daylight White)
Lumen Output: 500 / 1000 / 2000 lm
LED Life Expectancy: up to 50,000 hours
Max Illumination Time at Full Charge: 3-5 nights
Sensor: Light / Charge Sensor
Beam Angle: 120 degrees
Battery Type: Lithium Ion 3.7 4400mAh / 8800mAh / 17600mAh (Replaceable)
Battery Lifespan: up to 8 years
Battery Charge Time: 6-8 hours
Solar Panel: Polycrystalline – Lifespan up to 25 years
IP Rating: IP65
Materials: Aluminium Alloy, Polycarbonate
Weight: 875g / 1.65kg / 3.2kg (approx.)
Mounting: Surface mount (keyhole & standard)
Functions: At dusk, 5 hours at 100%, followed by 25% until dawn / no battery charge (dusk to dawn)
Working Temperature: -25
Included: Solar Light, 3-4 x screws & wall plugs, Instructions
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light, especially when mounting it in high places.
•
Ensure the fitting is mounted out of range of head height to avoid injury.
•
Fitting must be mounted to a solid surface.
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
•
For replacement battery, contact the manufacturer.
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface
dirt. To maintain efficiency, specifically clean the solar panel and LEDs on a regular basis. Also, keep the solar panel free of debris
and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could damage
the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

If purchased from a 3 rd party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
THANK YOU FOR YOUR PURCHASE
˚ ˚
~ 65 C
Full product range & more information: www.lumenalights.com
Signalite Solar Sign Light – 5w / 10w / 20w
117mm

WARNINGS

Tel: +44 1327 871161
Producer Registration Numbers: WEE/KC3440XY / BPRN0843
USER MANUAL
350mm / 650mm /
125mm
67mm
✔✔✔
3 YEAR
GUARANTEE
see website for
more details
Email: sales@lumenalights.com
