RF Setting
In this page, you can set up the output modulation with its parameters and the output frequencies.
Reminder:
The output frequencies are 4 continuous ones. You only need to fill the first one and
the system will show the other three.
Our device supports all the major modulation, but it will display one in a regular
Mode Modulation
device. Please contact our sales for more OEM requirements.
Different combination will have different bandwidth. We suggest you leave it as
Modulation Settings
defaulted.
RF Enable
RF channel enable
Frequency
Input the frequency in the first box and the system will do the rest.
