Elmdene UNIVERSAL-12V-5A-M Manual

Elmdene International Ltd
3 Keel Close, Interchange Park
Portsmouth, Hampshire, PO3 5QD, UK
Universal PSU Range
Models :
UNIVERSAL-12V-5A-M
UNIVERSAL-12V-5A-L
UNIVERSAL-24V-3A-M
UNIVERSAL-1224-L
INTRODUCTION
This manual covers a range of Power Supplies and enclosures designed for use for use in Access Control
and General Security applications. Each version comprises a 13.8Vdc or 27.6Vdc high efficiency,
switched mode Power Supply designed to fit into a robust metal enclosure. It has a unique universal
mounting system to allow fitment of a variety of 3
Supplies provide continuous full rated current to load plus an additional 0.5A
lead acid batteries. Normal operation and fault signal outputs are provided.
F
EATURES
•
Continuous full rated current to load.
Universal mains input rated voltage ranging from 100Vac to 240Vac.
•
•
12Vdc, 24Vdc and selectable 12Vdc / 24Vdc options.
•
High efficiency electronics for reduced running costs and lower operating temperatures.
•
Installer safe design with all high voltage electronics fully protected.
•
Full electronic short circuit and overload protection on load output under mains operation.
•
Mains transient protection circuit.
•
Front and rear tamper detection.
•
Mains present LED.
•
LED Fault indication.
•
Universal mounting means for 3
•
Individually fused output(s).
•
Deep discharge protection helps prevent battery failure when operating in standby mode for
extended periods.
SAFETY
Refer to the Power Supply Equipment (PSE) instruction for safe use.
rd
party controllers or electronic devices. The Power
rd
party Control Modules.
Tel:+44 (0)23 9269 6638
Fax: +44 (0)23 9266 0483
Web: www.elmdene.co.uk
battery charging for standby
