- Page 1 AURA E2 heater Installation and operating instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS General safety instructions AURA heater Heater assembly and installation Stacking the stones Technical specifications Heater power and voltage Heater dimensions Required amount of stones Minimum distances to inflammable material General instructions for users of AURA heaters Note Installation cable Additional connection options Things to keep in mind when using the heater First heating Sauna room... -
Page 3: General Safety Instructions
A stone compartment with too few stones or filled improperly creates a fire hazard! • Covering the heater creates a fire hazard. This device may be used by children who are 8 years of age or older, as well as by persons whose physical, sensory or mental abilities have deteriorated or who lack of experience and knowledge, only under supervision or when they have been instructed on the safe use of the device and they understand the hazards associated with using the device. This device complies with the requirements of: Mondex pursues an active policy of product development and continuous improvement. For this reason, Mondex reserves the right to make changes relating to the design and technical specifications of their products without prior notice. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2022... -
Page 4: Aura Heater
AURA HEATER HEATER ASSEMBLY AND INSTALLATION Heater assembly 1. Store the heater in its original package in an upright position and in a warm and dry location until it is installed. 2. The package includes the heater, thermostat sensor, electronic controller and the required cables. Inspect the heater components visually. -
Page 5: Stacking The Stones
There must always be a stone between a resistor and the frame. Do not make a heap of stones on top of the heater! Do not use the heater without the stones! Dents caused by the user are not covered by Mondex’s warranty or other product liability. When stacking the stones, be careful not to dent the heater’s metal surfaces to avoid damaging them. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2022... -
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS HEATER AURA 6.6 AURA 9.0 Power 6.6 kW 9.0 kW Voltage 400 V 3N~ 400 V 3N~ Connecting cable 5 x 1,5 mm² 5 x 2,5 mm² Fuse 3 x 10 A 3 x 16 A Height (mm) 1010 1010 Width (mm) Depth (mm) Sauna size... -
Page 7: General Instructions For Users Of Aura Heaters
GENERAL INSTRUCTIONS FOR USERS OF AURA HEATERS Note Electrical connections may only be made by an electrician with a valid installation authorisation according to the current regulations. The Aura electric heater is suitable for use in a family sauna, one (1) heater per sauna room. Retain the installation and operating instructions for further reference. Installation cable Use rubber cable H07RN-F as a connection cable. Additional connection options Control of electric heating with the heater: The electric heating control cable is brought directly to the heater’s junction box and further to the heater’s terminal block with a rubber cable that is dimensionally identical to the incoming cable. NOTE! Failure to observe the connection instructions may cause a fire hazard! NOTE! Remove all plastic film before using the heater! THINGS TO KEEP IN MIND WHEN USING THE HEATER First heating During the first heating, the resistors may emit fumes. Therefore, ensure that the room is properly... -
Page 8: Sauna Room Structure
Sauna room structure The sauna and its ceiling, in particular, should have good thermal insulation, as heat tends to escape through the ceiling. Due to the moisture, we recommend that you use aluminium paper. The size of the heater should be selected according to the size of the sauna (in cubic metres). In addition to calculating the power need for the regular sauna structure (glass wool–foil–wood), the following should be taken into consideration. If the sauna has any uninsulated wood, tile or concrete surfaces or the walls are made of logs, the heater power needs to be increased. For every uninsulated square metre, the heater power need increases by the same amount as if increasing the space volume by 1.2 m and on timber... -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Installation of external control and sensor The type E2 heater package includes: Controller Temperature sensor The wall-mounted sensor is placed above the heater. Reinforcing plate The temperature sensor must be installed so that it cannot be affected by inlet air. Plastic clip Place the sensor the following way: 10 cm in a vertical distance from the ceiling, and 10 cm in a horizontal distance from the heater (compare sketch on page 10). -
Page 10: Installation Instructions For The Thermostat And Controller
INSTALLATION INSTRUCTIONS FOR THE THERMOSTAT AND CONTROLLER Changing room Sensor Utility room Controller Heater Sauna Fuse Supply cable 5 x 1.5 mm / 5 x 2.5 mm 10 cm Sensor on the 10 cm wall min. 1 m Controller The controller must be placed at a minimum distance of 1 m from the heater INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2022... -
Page 11: Wiring Diagram
WIRING DIAGRAM F2/5A RLY1, RLY3, RLY5 RLY2, RLY4, RLY6 OVERHEATING PROTECTOR Controller card wiring, controller Controller card wiring, heater Heater: Display: 1 White Note! The termi- 2 Brown nal screws must 3 Green 4 Yellow face the wall. 5 Grey 6 Pink Sensor: 1 Brown... -
Page 12: Heater Control And Operation
HEATER CONTROL AND OPERATION ON/OFF MENU DOWN Switching on the heater The right-hand decimal point on the display is The heater is switched on by pressing the lit to indicate that the timing setting is displayed. ON/OFF button. The setting can be changed by using If three lines appear on the display, the buttons the UP and DOWN buttons, either by are locked. repeatedly pressing them briefly or by keeping them depressed longer. The time will first change The buttons can be unlocked by in 30-minute increments, and after ten hours, in pressing the ON/OFF and MENU one-hour increments. -
Page 13: Stopping The Heating Or Timing Process
The target temperature can be The heating process can be started by adjusted by using the UP and DOWN pressing the MENU button again. buttons. When the target temperature has been Parental control adjusted, the current temperature will again be displayed after a while. The remaining heating The heater has a menu for separately set time is displayed by pressing the MENU parameters. button during the heating process. You can enter the menu by pressing The duration of heating can now be the MENU and ON/OFF buttons changed by using the UP and DOWN simultaneously for a while. The abbreviation of buttons, and the current temperature will be the first parameter will be displayed. displayed when the change has been made. If the duration of heating is changed to zero, the The current value of the parameter can be heating stops immediately. displayed by pressing the MENU button. Stopping the heating or timing process You can change the parameter value The heater can be turned off by pressing... -
Page 14: Troubleshooting
TROUBLESHOOTING HEATER DOES NOT WARM UP Check the heater fuses at the fuse box Is the power on? Check that all three heating resistors are glowing then the heater is on Has the overheating protector tripped? –> This is reset by pressing the button in the sensor box until a click is heard. The cause of overheating must always be determined before the heater is switched on again! If necessary, contact the dealer or manufacturer. WARNINGS - Due to a risk of fire, do not use the sauna to dry clothes or laundry. -
Page 15: Warranty And Maintenance
“Changing the heater stones”. Removing or re-stacking of heater stones are not covered by the warranty in a potential warranty maintenance. The manufacturer will not compensate the buyer for expenses incurred by a product defect or malfunction, loss caused by disruption of business operations, or any other direct or indirect damage. For more detailed warranty terms and conditions, please see www.mondex.fi/en/product-support/. MAINTENANCE AND SPARE PARTS In case of a fault that cannot be solved, please contact the store where you purchased the heater or email info@mondex.fi. Spare parts can be purchased from Mondex distributors and the manufacturer. -
Page 16: Heater Maintenance History
HEATER MAINTENANCE HISTORY We recommend changing the heater stones at one-year intervals. Change them more regularly if the heater is used often. DATE MEASURE Premec Oy Kettukallionkatu 4 84100 Ylivieska, Finland info@mondex.fi www.mondex.fi Technical support: info@mondex.fi...
