- Page 1 AURA Installation and Operating Instructions...
-
Page 2: Table Of Contents
General safety instructions AURA heater Heater assembly and installation Stacking the stones Technical specifications Heater power and voltage Heater dimensions Required amount of stones Minimum distances to inflammable material General instructions for users of AURA heaters Note Installation cable Additional connection options Things to keep in mind when using the heater First heating Sauna room Temperature control Heating time Water thrown on heater... -
Page 3: General Safety Instructions
To ensure safe use of the sauna, please read these safety instructions first! Electrical connections may only be made by an electrician with valid installation authorization according to the current regulations. The Mondex electric heater is suitable for use in a family sauna, one (1) heater per sauna room. Retain the installation and operating instructions for further reference. Always check the adequacy of the fire protection distances! Failure to observe the connection instructions may result in a risk of fire! Always check the sauna room before switching the heater on! Always check that the controller has switched the heater off after the set time period! Due to the risk of fire, do not use the sauna to dry clothes or laundry. Exercise caution with a hot heater, since the heater stones and metal parts become very hot and can cause burns. The water steam rising from the heater is hot and can cause burns. Children, disabled and ill persons who are using the sauna should be supervised. Benches and floors may be slippery, therefore move in the sauna with caution. Do not go to a hot sauna under the influence of narcotic substances (alcohol, drugs, narcotics, etc.). A stone compartment without stones or filled improperly will present a risk of fire! Covering the heater will present a risk of fire. This device is not intended for use by persons whose physical, sensory or mental abilities or lack of experience and knowledge prevent them from using the device safely, without supervision or before they have been instructed on safe use of the device and they understand the hazards associated with using the device. Children may not play with the device. Children may not clean the device or perform maintenance on the device unsupervised. Mondex pursues an active policy of product development and continuous improvement. For this reason, Mondex reserves the right to make changes relating to the design and technical specifications of their products without prior notice. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 4: Aura Heater
AURA HEATER HEATER ASSEmBLY AND INSTALLATION 1. Store the heater in its original package in an upright position and in a warm and dry location until it is installed. 2. Inspect the heater visually. If you notice any discrepancies or deficiencies, please contact the store where you purchased the heater or e-mail info@mondex.fi 3. The heater is installed so that it leans against a wall using the bracket provided (see the dimensions on page 10). 4. To facilitate installation, adjust the heater’s feet so that they extend out 8–9 cm. NOTE! Leave a gap of 5 cm between the floor and the heater! INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 5: Stacking The Stones
There must always be a stone between a resistor and the netting. Exposed resistors may be a fire hazard, so the stones should be stacked as tightly as possible. Dents caused by the user are not covered by Mondex’s warranty or other product liability. When stacking the stones, be careful not to dent the heater’s metal surfaces to avoid damaging them. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS HEATER AURA 6.6 AURA 9.0 Power 6.6 kW 9.0 kW Voltage 400 V 3N~ 400 V 3N~ Connecting cable 5 x 1.5 mm² 5 x 2.5 mm² Fuse 3 x 10 A 3 x 16 A Height (mm) 1010 1010 Width (mm) Depth (mm) Sauna size 5–9 m³ 8–15 m³ Amount of stones 70 kg 70 kg INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 7: Minimum Distances To Inflammable Material
DISTANCES TO INFLAmmABLE mATERIAL mODEL AURA 6.6 900 2,000 100 AURA 9.0 900 2,000 120 NOTE! Ensure that when installing the safety collar, dimension D is measured from the front surface of the heater to the bench structures! INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 8: General Instructions For Users Of Aura Heaters
GENERAL INSTRUCTIONS FOR USERS OF AURA HEATERS Note Electrical connections may only be made by an electrician with valid installation authorization according to the current regulations. The Aura electric heater is suitable for use in a family sauna, one (1) heater per sauna room. Retain the installation and operating instructions for further reference. Installation cable Use rubber cable H07RN-F as a connection cable. Additional connection options Control of electric heating with the heater: The electric heating control cable is brought directly to the heater’s junction box and further to the heater’s terminal block with a rubber cable that is dimensionally identical to the incoming cable. NOTE! Failure to observe the connection instructions may result in a risk of fire! NOTE! Remove all plastic film before using the heater! -
Page 9: Water Thrown On Heater
Water thrown onto the heater We recommend using hand warm water. The water should be fresh household water. Throwing the water onto the heater sides / lower stones generates softer steam. If you want steam that feels hotter and more intense, pour plenty of warm water on top of the heater all at once. Sauna room structure The sauna and its ceiling, in particular, should have good thermal insulation, as heat tends to escape through the ceiling. Due to the moisture, we recommend that you use aluminium paper. The size of the heater should be selected according to the size of the sauna (in cubic metres). In addition to calculating the power need for the regular sauna structure (glass wool–foil–wood), the following should be taken into consideration. If the sauna has any uninsulated wood, tile or concrete surfaces or the walls are made of logs, the heater power needs to be increased. For every uninsulated square metre, the heater power need increases by the same amount as if increasing the space volume by 1.2 m and on timber surfaces by 1.5 m . The factor for glass surfaces (glass walls, doors and uninsulated stone surfaces) is also 1.2 m per square metre. In borderline cases, you should choose a heater with higher power. The sauna needs efficient ventilation for a good oxygen level and a sufficient amount of fresh air. The air in the sauna needs to change at least 6 times per hour. For a sauna with an electric heater, mechanical ventilation is the most convenient ventilation method. The supply air should be provided through an inlet located 500 mm, at a minimum, above the heater, either on the wall or in the ceiling. The exhaust valve should be placed on the opposite wall, as far away from the heater and as close to the floor level as possible. It is highly recommendable to install an exhaust air valve in the ceiling as well for easier removal of moisture after sauna sessions. For more information, refer to the construction instructions and building regulations. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 10: Wall Mount Installation
WALL mOUNT INSTALLATION FLOOR See page 7 for the heater’s minimum distances to inflammable materials. NOTE! Keep in mind that the adjustable feet add to the total height of the heater. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 11: Installation Instructions
CONTROLLER INSTALLATION CONTROLLER CARD CONNECTIONS 1. See the installation instructions on page 12 to determine COLOUR the installation height and distance. 2. Drill a hole of an appropriate size in the panel for the wire, Pink or if you use a connection box, for the box. Do not puncture the insulation. If you puncture the insulation board / foil, you Grey must patch the hole with aluminium foil tape. 3. Route the wires from the heater along the bottom edge LIGHT of the panel to the hole and thread the wires out of the hole/box. Blue 4. Connect the wires to the switchboard (see page 13). Attach the switchboard to the wall/box. The front plate of Green the switchboard attaches to the switchboard by means of two plastic tacks. The colour options underneath the RELAY White transparent plastic may vary. 5. Install the controller to the heater as instructed on page 13. TEMP Brown NOTE! Electrical connections may only be carried out by an Yellow electrician with valid installation authorization. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 12: Installation Dimensions Of The Thermostat And Controller
INSTALLATION DImENSIONS OF THE THERmOSTAT AND CONTROLLER A) The minimum distance between the thermostat and the outer edge of the heater is 500–1000 mm. Note the inlet air valve! The minimum distance between the thermostat sensor and the inlet air valve is 1000 mm, unless the inlet air can be directed away from the thermostat. If the inlet air can be directed away from the thermostat, the distance can be 500–1000 mm. B) The distance between the thermostat sensor and the ceiling is 100 mm C) The minimum distance between the controller and the heater is 500 mm D) The maximum installation height from the floor is 1000 mm NOTE! The length of the thermostat cable is 5 m and the length of the controller cable is 10 m. Do not extend the cables! INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 13: Wiring Diagram
WIRING DIAGRAm Room thermostat NOTE! YELLOW The connection is BROWN not in scale. WHITE GREEN BLUE GREY PINK LIGHTING CONTROL: 230V AC, max 100W / 0.5A LIGHT LIGHT ELECTRONICS RESISTORS ON/OFF HEATING CONTROL (230 VAC) INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 14: Operation Of Heater Controller
HEATER CONTROL AND OPERATION Heater on/off Press this button to switch the heater on and off. If the timer function is set, pressing this button activates the timer, which then controls the heater operation. Tip: Keeping the button depressed longer will override the timer function and the heater switches on immediately. menu This button cycles you through the heater menu options as follows: (Basic status -> Target temperature -> Heating time -> Timer setting -> Basic status) Decrease This button decreases the value being set. Increase This button increases the value being set. Lights If the heater is equipped with lights, they are switched on using this button. Pressing the button again switches off the lights. Heating/timer indicator This indicator is on constantly when the heater is on. The indicator “glows” if the timer function is active. The indicator is off when the heater is off. Heater light indicator When this indicator is on, changing the target temperature is possible. menu settings indicator This indicator is on when a menu setting is being adjusted (timer, heating time, heater target temperature). Numerical display A screen displaying three digits INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 15: Menu Structure
Parameter Target temperature Heating time Timer setting Adjustment range 40 – 110 °C 1.0 – 4.0 h 0.0 h – 24.0 h Accuracy 1 °C 0.5 h (30 min) 0.5 h (30 min) Default value 60 °C 1 h 0 h (not in use) Target temperature The target temperature of the sauna can be adjusted at an accuracy of one degree Celsius. The minimum temperature is +40 degrees and the maximum is +110 degrees Celsius. The setting is saved in the memory. There are two different methods to adjust the target temperature: 1. Press the Menu button to display the target temperature. Press the (Increase / + ) and (Decrease / – ) buttons to change the value. The controller exits the target temperature setup menu automatically in approximately 10 seconds if no button is pressed. You can also exit the menu by pressing the Menu button repeatedly. 2. Pressing the or button when the sauna temperature is displayed on the screen gives direct access to the target temperature setup. To exit, follow the instructions in item 1 above. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 16: Timer Setting
The heater is switched off by pressing the On/Off button. The decimal point farthest to the right on the screen indicates that the heater resistors are on. The decimal point disappears when the resistors are not on. Heating indicator Tip: If the timer has been set but the heater is not on, the timer setting can be overridden by keeping the On/Off button depressed for a couple of seconds. This switches the heater on immediately. The timer setting will still be retained in the memory. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 17: Controller Error Codes
ER1 = The thermal sensor is missing or the temperature is too low. Check the wiring and installation of the thermal sensor. ER2 = The thermal sensor has short-circuited or the temperature is too high. Ensure that the wiring of the thermal sensor is intact and that the sensor has not short-circuited. Also check the controller wiring in the wiring diagram on page 13. PCB = The temperature of the heater’s control electronics is too high. Check the controller wiring in the wiring diagram on page NO ERROR CODES Check if the overheating protector has been activated. DISPLAYED BUT THE Acknowledge the overheating protector by carefully pressing the SAUNA FAILS TO HEAT button located on the thermal sensor casing. LIGHTING DOES NOT Ensure the connections are made correctly and that the heater WORK and light contacts are appropriate. HEATER FAILS TO WARm Contact technical support. UP PROPERLY INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 18: Troubleshooting
Is the set temperature higher than the sauna’s temperature? Has the overheating protector been activated? Do the fuses work? Does the controller display an error code? If the heater malfunctions, an error code is displayed on the controller screen. The error code definitions are provided on page 17. If the problem cannot be resolved with the instructions provided, contact technical support or maintenance. Once the malfunction has been addressed, the error codes disappear. Such situations include a cleared short-circuit in the sensor or the heater cooling off sufficiently after overheating. After that, you may try to switch the heater on again. WARNINGS - Due to a risk of fire, do not use the sauna to dry clothes or laundry. - Exercise caution with a hot heater, since the heater stones and metal parts become very hot and can cause burns. - The water steam rising from the heater is hot and can cause burns. - Children, disabled and ill persons who are using the sauna should be supervised. - Benches and floors may be slippery, therefore move in the sauna with caution. - Do not go to a hot sauna under the influence of narcotic substances (alcohol, drugs, narcotics, etc.) INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 19: Warranty And Maintenance
“Changing the heater stones”. Removing or re-stacking of heater stones are not covered by the warranty in a potential warranty maintenance. mAINTENANCE AND SPARE PARTS In case of a fault that cannot be solved, please contact the store where you purchased the heater or email info@mondex.fi. Spare parts can be purchased from Mondex distributors and the manufacturer. When purchasing spare parts, please refer to the name, power, serial number and manufacturing date of the heater to ensure you receive the correct parts. NATURAL STONE AS mATERIAL Small pebbles or pieces may come off the natural stone used in the heater. As this is not a failure of the organic material but a natural feature that cannot be predicted at the time of manufacturing the product, the manufacturer is not responsible for any damage. CHANGING THE HEATER STONES Re-stack the heater stones and replace any eroded stones annually (every three months in commercial/ professional use). The good condition and proper, spacious stacking of the stones around the resistors inside the heater ensure a sufficient air flow between the resistors. If this is not carried out annually, a proper air flow may be obstructed and the resistors may break prematurely, which is not covered by the warranty. INSTALLATION AND OPERATING INSTRUCTIONS AURA 12/2017... -
Page 20: Heater Maintenance History
HEATER mAINTENANCE HISTORY We recommend changing the heater stones at one-year intervals. DATE MEASURE info@mondex.fi Premec Oy www.mondex.fi Kettukallionkatu 4 84100 Ylivieska Finland...
