MProgram change
Status Second
CnH РРН
pp = Patch Number OH - 7FH (1 - 128 )
n * MIDI Channel OH - FH (1- 16)
Program change information is used to change Patches.
This information is ignored in the Rhythm Part.
MPitch Bender change
Statua Second Third
EnH uH ттн
В = Pitch Bender change value ( Lower byte )
OOH ~ 7FH ( 0 - 127 )
mm = Pitch Bender change value ( Upper byte )
OOH ~ 7FH (0 ~ 127 )
n = MIDI Channel OH - FH (1- 16)
Ш Mode message
@ All notes off
Status Second Third
BnH TBH 00H
n = MIDI Channel OH- FH (1- 16)
Turns off all notes that have been turned on by MIDI Note on.
Ф OMNI! OFF
Status Second Third
BnH TCH оон
n * MIDI Channel OH - FH (1-1)
Recognized as only Al notes off.
CM - 32L remains іп mode З ( omni off, poly ).
€ OMNI! ON
Status Second Third
Ван три 00H
n = MIDI Channel OH- FH (1- 16)
Recognized as only All notes off.
CM - 821. remains in mode З ( omni off, poly ).
€ MONO
Status Second Third
BnH ТЕН mmH
mm = MONO Channel range ignored
n * MIDI Channet 0H - FH (1- 16)
Recognized as only Ай notes off.
СМ - 32L remains in mode З ( omni off, poly ).
e POLY
Status Second Third
Ван ТЕН оон
n = MIDI Channel OH - FH (1- 16)
Recognized as only АЙ notes off.
CM - 32L remains іп mode 3 ( omni off, poly 7,
WExciusive
Status
FOH :System Exclusive
F7H :EOX (End Of Exclusive)
Using exclusive message, a sel of parameters for a timbre or individual parameters
in a palch or timbre can be transferred іо CM - 32L.
Refer to Roland Exclusive Messages and Sections З and 4.
W Active sensing
Status
FEH : Active Sensing
Once recieving this message, the CM - 321, expects to accept status or data in sequence,
at last within 300 msec intervals.
И the unit fails to recieve a message within 300 msec after previous one, it judges
there is a problem somewhere in MID] path, muting the current sound and setting each
of controllers as below, then stopping 300 msec - interval monitoring of incoming signal.
Controller setting
Modulatíon Depth MIN ( 0)
Expresston MAX ( m )
Rold 1 OFF ( 0)
Pitch Bender Change — CENTER
Parameters for patches or timbres can be transferred to/from СМ ~ 32L through
Exclusive message. Model - ID # of CM - 32L is 16H.
In a system where more than one MIDI channel is assigned to CM - 32L, Unit # may
be set to the CM ~ 32L instead of Device - 10 # of a basic channel, The advantage
of Unit # is that a specific part is made accessible independent of MIDI channel of
that part,
Whether to use MIDI channel or Unit # depends on parameter address.
CM - 321, recognizes MID! channels 1 thru 16 and Unit # 17 as Device - ID +. Note
that the actual Device - ID # is the number 1 less MIDI channel number or Unit #.
Ш Опе way communication
Request Data І RQ! HH
Byte Deseriptton
FOH Exclusive status
А418 Manufacturer's IN ( Roland )
DEV Device ID
16K Model 1р
nn Command ID ( 801 )
аай Address MSB & 3-1
аан Address
аай Address LSB
ss Size — MSB
ssil Size
558 Size LSB
sum Check sum
FI EOX ( End Of Exclusive )
Data set ! отъ 12H
Byte Description
FOR Exclusive status
4n Manufacturer's ID ( Roland )
DEV Device ID
158 Model ID
128 Command 10 DTI )
аай Address М5В # 3-1
aall Address
аай Address 158
ddh Data # 3-2
sun Check sum
FH EOX ( End Of Exclusive )
