LA SOUND MODULE
Model CM — 32L
[1 TRANSMITTED DATA]
M Exclusive
Status
FOH : System exclusive
F7H : EOX (End Of Exclusive)
For details, see Sections З and 4, and Roland Exclusive Messages.
2. RECOGNIZED RECEIVE DATA
WNote event
@ Note oft
Status Second Third
BnH kkH УУН
пн KKH 00H
kk = note number OOH ~ ТЕН ( 0 - 127)
vv = velocity ignored
n * MIDI Channel OH - FH СТ 16 )
A tone whose envelope mode is "NO SUS" ignores Note off message.
@ Note on
Status Second Third
дон ККИ УУН
kk = note number 00H ТЕН ( O - 127)
уу = velocity СН - ТЕН СІ 127 )
п + MIDI Channel oH - FH СІ 16)
Part 1. 8:Note numbers outside of the range 12 - 108 are transposed to the nearest
octave inside the range.
Rhythm Part: Note numbers outside of the range 24 - 108 are ignored.
Ш Control change
@ Modulation Depth
Status Second Third
Ван Ove vvli
уу Modulation depth OOH - 7ЕН (0 - 127 )
n = MIDI Channel OH - FH СІ 16 2
Ф Data Entry
Stetus Second Third
Ван 06H МУН
уу = Value of a parameter specified by RPN. (See description іп RPN MSB.)
п = MIDI Channel OH FH € 6}
® Main Volume
Status Second Third
Ван 071 vvH
vv = Volume Value OOH - 7FH ( 0 - 127 )
n = MIDI Channel он FH ( 1- 18 )
Controls the volume of a Part accessible through the received MIDI channel. The
maximum volume is determined by Master volume and Expression message.
24
Date : Apr. 18. 1989
MIDI Implementation Version : 1.00
@ Panpot
Status Second Third
Ван ОАН УУН
уу - Panpot Value OOH ~ 7FH (ОС 127 )
n = MIDI Channel OH - FH Сі 16)
Orientation of sound is as follows.
127 = LEFT, 64 = CENTER, O = RIGHT
This information is ignored in the Rhythm Part.
@ Exprassion
Statue Second Third
BnH OBH ven
vv - Expression OOH - 7FH ( 0 ~ 127 )
n = MIDI Channel oH FH (1 IG )
Controls the volume of a Part accessible through the received MIDI channel. The
maximum volume is determined by Master volume and Main Volume message.
@ Hold - 1
Status Second Third
Вай 40H УУН
vv = OOH ЗЕН : off
vv ДОН - 7ЕН : оп
n - MIDI Channel ОН. PHA C E 16)
Ф RPN LSB
Status Second Third
Balt 64H wH
vv = The lower byte of a parameter number controlled by RPN. (Refer to RPN MSB.)
n = MIDI Channel он PH СІ 16)
Ф АРМ MSB
Status Second Third
BnH 65H vvH
vv = The upper byte of a parameter number controlled by RPN.
n = MIDI Channel он - FH (1- 16)
Using MIDI RPN, CM - 32L parameters can be controlled by Control change message.
RPN MSB and LSB specify the parameter (о be controlled while Data entry sets the
parameter value.
Effective RPN to CM - 32L is Bender range.
RPN Data Entry
№58 158
Description
00H ooi Ун Bender Range
vv 0 - 24
Unit in semitone, 2 octaves maximum
@ Reset All Controllers
Status Second Third
Ван тен 00H
n - MIDI Channel 0H- FH (1- 16)
Sets eatch of the foliowing controls as follows.
Controller setting
Modulation Depth MIN ( 0)
Expression MAX (17 }
Hold 1 OFF ( 0;
Pitch Bender Change — CENTER
