parts list
for Bling ring Pro 40T HD Package
comPaTaBle wiTH Bafang BBshd
includes
a
1x lekkie Bling ring Pro 40T HD
B
1x 2mm Bling ring HD SPacer
1x Drive cover HD aSSemBly
c
lekkie Bling ring PrO 40T hD user Manual
, M625, M325
B
a
c
www.lekkie.Tech
Doc v2.0
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lekkie Bling Ring PRO 40T HD
Summary of Contents for Lekkie Bling Ring PRO 40T HD
- Page 1 Bling ring Pro 40T HD Package , M625, M325 comPaTaBle wiTH Bafang BBshd includes 1x lekkie Bling ring Pro 40T HD 1x 2mm Bling ring HD SPacer 1x Drive cover HD aSSemBly Doc v2.0 lekkie Bling ring PrO 40T hD user Manual www.lekkie.Tech...
-
Page 2: Tips And Tricks
• loctite 243 • Scribe/fine tip marker • Small metal file when installing the lekkie Drive cover HD you will require some tools and some hands on experience with your motor. If you do not the have required tools, confidence or skills to install this take your motor to your local bike shop or engeering shop and they should be able to help you out. - Page 3 Before you can install the lekkie Drive cover HD you need to remove the stock Bafang cover and bearing. This also gives you the opportunity to check the condition of your drive gear, pinion and bearings and replace any parts as needed. it is important to keep the internal compontents free from dirt/grit, so before opening the housing thoroughly wipe down external surfaces and keep a clean work area to ensure it all goes back together without contamination.
- Page 4 Motor Modification you must complete the motor modification steps or your Bling ring pro 40t hd will hit your motor and damage the Bling ring voiding warranty. This modification will require you to file a small amount of material off your motor. when completed correctly, the performance and durablitly of the motor will not be effected.
- Page 5 Note: Grease all touching surfaces to make maintanance easy. 243 to the threads of the six m5 drive cover bolts. Tighten to 6nm. Note: replace gasket if damaged. lekkie Bling ring PrO 40T hD user Manual www.lekkie.Tech...
- Page 6 To keep your motor running its best its important to regularly grease the main drive gear and pinion. we have added a grease port to the lekkie Drive cover HD v2 to allow this. To do so simply remove the grease port screw and using a grease gun, squirt moly-grease in while slowly turning the motor.
- Page 7 THe Bling ring pro 40t hd tools required • 4mm hex key install tips • Double-check clearance between the inside edge of the chainring and the motor (where material has been removed). ensure the ring turns freely without rubbing.
- Page 8 73mm BB frame,(or have had to space your motor out on the drive side) try installing without the spacer first. You must have at least 1.5mm gap between the ring and chain-stay, space out as required. Measurements in mm, illustration not to scale. lekkie Bling ring PrO 40T hD user MAnuAl www.lekkie.Tech...
- Page 9 The lekkie Blingring Pro is compatible with most chains up to 12-speed but suits 10-12-speed best. Some chains do not fit so if you are usnsure please get in touch with us. geoMetry The 40T, 42T and 46T Blingring offsets give you the best possible chainline without interfering with the motor.
-
Page 10: Warranty
Qc system and made it to your hands let us know and we will put it right. if one of our products fails we want to know so we can make our products better. if you destroy a lekkie product in extreme use tell us. we can learn from this and sell you something so suit your needs.
