TIPS AND TRICKS

FOR BLING RING PRO 42T HD
COMPATABLE WITH BAFANG BBS01/BBS02/BBSHD
INCLUDES
1X LEKKIE BLING RING PRO 42T HD
A
1X 2MM BLING RING HD SPACER
B
TOOLS REQUIRED
• 4mm hex/Allen key
INSTALL TIPS
• Clean and lubricate axle with a multi-pupose grease before install.
• Apply Loctite 243 to bolt thread.
• Always install a new chain when installing a Bling Ring
• If you are offsetting by more than 2mm use longer bolts.
• Make sure when you install your Bling Ring you have at least 1.5mm gap between wide tooth and
chainstay to allow flex.
• Tighten to 6Nm
• Try to get the chainline to the centre of your cassette - see below for details.
• Clean and lubricate chain regularly.
• DO NOT use half links in the chain.
• Always grease axle before re-installing cranks.
LEKKIE BLING RING PRO 42T HD USER GUIDE V1
A
B
V1 42T PRO Doc-V1.0
WWW.LEKKIE.TECH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAFANG BBS01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lekkie BAFANG BBS01

  • Page 1 • Try to get the chainline to the centre of your cassette - see below for details. • Clean and lubricate chain regularly. • DO NOT use half links in the chain. • Always grease axle before re-installing cranks. V1 42T PRO Doc-V1.0 LEKKIE BLING RING PRO 42T HD USER GUIDE V1 WWW.LEKKIE.TECH...
  • Page 2 73mm BB frames. If you are building a 73mm BB frame try installing without the spacer. You should have at least 1.5mm gap between the ring and chain-stay. Measurements in mm, illustration not to scale. V1 42T PRO Doc-V1.0 LEKKIE BLING RING PRO 42T HD USER GUIDE V1 WWW.LEKKIE.TECH...
  • Page 3 A central chainline may not be possible on all frames. In this case do the best you can to get the chain central. CHAIN COMPATIBILITY The Lekkie BLINGRING PRO is compatible with most chains up to 12-speed but suits 10-12-speed best. Some chains do not fit so if you are usnsure please get in touch with us. GEOMETRY The 40T,42T and 46T offset gives you the best possible chainline without interfering with the motor.
  • Page 4 QC system and made it to your hands let us know and we will put it right. If one of our products fails we want to know so we can make our products better. If you destroy a lekkie product in extreme use tell us. We can learn from this and sell you something to suit your needs.
