Ph2 Electric Plinth Heaters For Base Units - Creda Heating Solution Brochure

PH2
Electric plinth heaters for base units
"
Small and compact, plinth
heaters provide effective
warmth to a cold floor and
rapidly heat the room,
with 3 fascia choices in
"
every box.
The plinth heater will heat a room much
faster than a traditional radiator many
times its size but will not occupy valuable
wall space. The heater sits neatly in
kitchen base units, reception desks,
shop counters and even stair risers to
provide an unobtrusive flow of warm air
at floor level.
Available with integral controls or hand
held infra-red remote control. Each model
comes complete with white, brown and
silver fascias to complement modern
room designs.
Key features
• Choice of 3 models: manual, remote or no controls
• Each model comes complete with white,
brown and silver fascias
• Automatic over temperature cut out
• Maximum output of 2kW
(1kW on TM and TR models)
• Low noise fan only option for cool air circulation
(on TM models)
• Easy slot in profile (no metal sleeve required)
Product Selector
Model Reference
PH2TM 75 774701
PH2TR 75 774702
PH2NC 75 774703
RFRTK 75 770917
RFRTK7 75 770920
RFRI 75 770921
Remote model (silver fascia fitted)
No controls model (brown fascia fitted)
Control options
RFRTK RF remote thermostat kit.
Enables thermostatic control using
wireless signalling between the remote
wall mounted thermostat and the
receiver unit at the appliance.
Rating Product description
2kW Plinth heater 2kW thermostatic manual
2kW Plinth heater 2kW thermostatic remote
2kW Plinth heater 2kW no controls
2kW RF remote thermostat kit
2kW RF remote thermostat and programmer
2kW RF additional receiver unit only
+44 (0) 1733 456789
Underfloor heating
& fan heaters
Manual model (white fascia fitted)
Technical Specification
• Element - stitched 'black heat' type
• Fan - crossflow type
• Thermoplastic body
• Powder coated fascias white, brown
and silver
• Weight 2.5kg
• Supply - 230/240V AC single phase
Dimensions
PH2TR supplied
complete with hand
held on/off infra-red
remote control.
Height A
100mm
100mm
100mm
www.creda-heating.co.uk
Width B Width C
400mm 200mm
400mm 200mm
400mm 200mm
- - -
- - -
- - -
33
