Creda SFH24AW Technical Specification

SFHA Sensair Automatic
Electric storage fan heaters
"
The ultimate combination
of storage and direct
fan heating. Able to
regulate input with direct
acting heat flexibility, the
SFHA Sensair is more
effective at retaining heat
than a conventional
storage heater.
Able to operate on virtually any tariff
and with superior high performance
insulation levels, it achieves higher SAP
and NHER ratings than manual input
storage heaters.
Product Selector
Model Reference
SFH18AW 70305
SFH24AW 70315
22
Key features
• Combines electric storage fan heating,
direct acting heating and fanned heat output
with simple controls
• Fully automatic heat storage - no user adjustment
required on input controls
• High performance insulation works more
effectively than a conventional storage heater
• Heat output is via a quiet two speed fan
"
• Boost setting for high speed room heat up
• Fan can be switched off without altering
thermostat setting
• Operates on virtually any tariff and takes better
advantage of extended or split tariffs
• Fanned heating avoids heat stratification
• Lockable controls cover
• Negative pressure air movement through the
storage core avoids hotspots and heat leakage
Rating Direct Charge
Storage Acting Acceptance (7 hrs)
2.5kW 1.5kW 17.6kWh
3.4kW 1.5kW 23.5kWh
+44 (0) 1733 456789
Electric storage
heating
Net Storage Weight Number
of Elements
14.9kWh 121kg 3
20kWh 158kg 4
www.creda-heating.co.uk
Technical Specification
• Elements (storage) - mineral insulated stainless
steel sheathed
• Insulation - opacified silicaceous aerogel and
mineral fibre mat
• Storage Core - high density iron oxide compound
• Fan Unit - two speed crossflow fan
• Controls (Output) - regulated by fan, activated
by integral adjustable thermostat
• Controls (Input) - hydraulic head temperature
compensated, room and storage core temperature
sensitive, auto-set charge control
• Protection - two level thermal safety overheat
• Supply - 230/240V AC single phase
Dimensions
Model Height A Width B
SFH18AW 705mm 788mm
SFH24AW 705mm 1016mm
Number of Remaining Useful Heat* (Fan Off)
Core Bricks After 17hrs (Static) Discharge
12 40%
16 40%
Depth C
187mm
187mm
