TSR Electric Storage Heaters
Assembly Instruction
Model Nos:
Cat. Nos:
This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
© GDC Group Ltd. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing.
A division of the GDC Group Ltd, Millbrook House, Grange Drive, Hedge End, Southampton SO30 2DF
Automatic
79331S
TSR6AW
Manual
79334/6S
TRS6MW

Advertisement

loading
Need help?

Need help?

Do you have a question about the NewEra 79331S and is the answer not in the manual?

Questions and answers

Summary of Contents for Creda NewEra 79331S

  • Page 1 TSR Electric Storage Heaters Assembly Instruction Automatic Manual Model Nos: 79331S 79334/6S Cat. Nos: TSR6AW TRS6MW This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC ©...
  • Page 2 IMPORTANT NOTES: It is important to read these instructions carefully and also note the information given on the heater itself. As these particular instructions refer to the assembly and installation of a new heater, they should be retained by the installer; not left behind for the user as this would invite the dismantling and servicing by unqualified persons.
  • Page 3 PLEASE DON’T TAKE CHANCES Site conditions may vary considerably and Creda cannot recommend the correct wall fixings to be used. It is the responsibility of the installer to ensure that adequate permanent fixing has been achieved. Purely for guidance the suggested fixings are made for certain wall materials but this list is not comprehensive or authoritative.
  • Page 4 First, turn carton upside down Open bottom flaps on carton Packing corner fitments contain TSR6AW MODEL ONLY - heater feet Attach the Room Sensor to the plastic clip which is located at It is preferable to fit the heater feet the rear of the of the heater, as whilst the heater is still in its carton.
  • Page 5 WALL FIXINGS - VERY IMPORTANT You must fit a retaining screw at each end of the heater. There are two fixing slots at each end of heater, allowing different stand-offs for different thicknesses of skirting board. Do not fully tighten these screws until the bricks are loaded into Outer Slot Outer Slot Inner Slot...
  • Page 6: Connecting The Mains Supply Cable

    MAINS TERMINALS IMPORTANT: for earthing, loosen the earth screw sufficiently to wrap the mains’ earth wire around it between flat washer and cup washer, and retighten the earthing screw. Feed the mains cable through the cable clamp and make ENSURE THAT CABLE CLAMP connections as marked on the heater.
  • Page 7 Temporarily remove the element to allow access for the rear rank of bricks. Loosen the terminals on the element and remove this to allow installation of rear rank of storage bricks. Note the way the bricks are positioned in the heater. Otherwise, they will not fit.
  • Page 8: Heater Operation

    Instructions on this are given in the Users Guide which we ask you to ensure is left with the User. IMPORTANT NOTICE TO INSTALLER TSR 79331S MODEL To ensure that the correct charge level is achieved by the heater, the flat surface of the charge control thermostat spindle MUST be positioned towards the rear of the heater and parallel with the wall.
