24V rear gear box
1
2
5
4
3
1. Plug the connector of the rear box to the connector from the body. Fit
the rear gearbox onto the rear axle.
2. Place the driving wheel onto the rear axle.
3. Slide a
Ø10 washer onto the rear axle.
4. Tighten a locknut to the end of the rear axle with a spanner.
Repeat for the other wheel.
5. 'Snap' the wheel covers to the wheels.
