E2S D1xL1FV725-A Instruction Manual

INSTRUCTION MANUAL
D1xL1 & D1xL2
Loudspeaker
Class I, Zone 1, 2, 21 & 22
1)
Product Table
Unit Type Code
D1xL1FV100-A
D1xL1FV070-A
D1xL1FR008-A
D1xL1FR016-A
D1xL1FV725-A
D1xL2FV100-A
D1xL2FV070-A
D1xL2FR008-A
D1xL2FR016-A
D1xL2FV725-A
D1xL2HV100-A
D1xL2HV070-A
D1xL2HR008-A
D1xL2HR016-A
D1xL2HV725-A
Frequency Range: 400Hz to 8000Hz
The table shows the input current taken by the various Loudspeakers.
Nominal current at nominal voltage.
Table 1: Electrical Ratings.
2)
Warnings
CAUTION
TO REDUCE THE RISK
ATMOSPHERES:
DISCONNECT FROM SUPPLY BEFORE OPENING.
KEEP TIGHTLY CLOSED WHEN IN OPERATION.
WARNING
FIT SEALING FITTING IN CONDUIT RUNS WITHIN 18 INCHES FROM
ENCLOSURE.
EQUIPMENT MUST NOT BE INSTALLED WITH THE HORN FACING
UPWARDS OF HORIZONTAL
DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT
DO NOT OPEN WHEN ENERGISED
POTENTIAL ELECTROSTATIC CHARGING HAZARD - CLEAN ONLY
WITH A DAMP CLOTH
ENCLOSURE ENTRIES: TWIN M20 X 1.5 / SINGLE 1/2" NPT
ATEX/IECEx & UKEx INSTALLATIONS: IF TEMPERATURE EXCEEDS
70°C AT ENTRY OR 80°C AT BRANCHING POINT USE SUITABLE
RATED CABLE AND GLANDS
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D190-00-201-IS
D1xL1F D1xL2F
Input Power (Watts)
100V Line
70V Line
8 Ohm
16 Ohm
25V
70V
100V Line
70V Line
8 Ohm
16 Ohm
25V
70V
100V Line
70V Line
8 Ohm
16 Ohm
25V
70V
OF IGNITION OF HAZARDOUS
Issue 3
Max I/P Volts
15 100
15 70
15 10.95
15 15.49
15 25V
15 70.7V
25 100
25 70
25 14.14
25 20
25 25V
25 70.7V
25 100
25 70
25 14.14
25 20
25 25V
25 70.7V
ATTENTION
POUR REDUIRE LE RISQUE D'INFLAMMATION DES ATMOSPHÈRES
DANGEREUSES :
COUPER L 'ALIMENTATION AVANT OUVERTURE.
CONSERVER FERMÉ PENDANT LE FONCIONNEMENT.
AVERTISSEMENT
CONDUITS DOIVENT ETRE SCELLES EN MOINS DE 18 POUCES.
ÉQUIPEMENT NE DOIT PAS ETRE INSTALLE AVEC LE KLAXON
TOURNEE VERS LE HAUT DE HORIZONTAL.
NE PAS OUVRIR UN PRESENCE D'ATMOSPHERE EXPLOSIVE
NE PAS OUVRIR ENERGIE
DANGER POTENTIEL CHARGE ÉLECTROSTATIQUE - NETTOYER
UNIQUEMENT AVEC UN CHIFFON HUMIDE
ENTRÉES DE BOÎTIER: 2 x M20 X 1.5 / 1 x 1/2" NPT
ATEX/IECEx & UKEx INSTALLATIONS : SI LA TEMPÉRATURE
DÉPASSE 70 °C À L'ENTRÉE OU 80 °C AU POINT DE
BRANCHEMENT,
D'ÉTANCHÉITÉ APPROPRIÉS
21-12-2023
D1xL2H
Sound Pressure Level dB(A)
Max Rated Pink Noise @ 1W
117
123
126
UTILISER UN CÂBLE
www.e2s.com Tel: +44 (0)208 743 8880
101
104
106
ET DES JOINTS
Sheet 1 of 6
