DUAL SEAL
CERTIFIED
Installation and Operation Instructions
Please read all instructional literature carefully and thoroughly before starting.
GENERAL
MISUSE OF THIS PRODUCT MAY CAUSE EXPLOSION AND
PERSONAL INJURY. THESE INSTRUCTIONS MUST BE THOROUGHLY
READ AND UNDERSTOOD BEFORE UNIT IS INSTALLED.
Cert number E40857-19971015
Applicable Area North America
Class I, Groups A, B, C and D; Class II, Groups
Markings
E, F and G; Class III
UL 1203, UL 508; CAN/CSA C22.2 No. 14,
Applicable Standards
CAN/CSA C22.2 No. 25
CAN/CSA C22.2 No. 30
Cert number
DEMKO C8 ATEX 0717128X
Applicable Area Europe (EU)
Markings II 2 G Ex db IIC T6 Gb; II 2 D Ex tb IIIC T85 °C Db
Applicable Standards
EN IEC 60079-0; EN 60079-1; EN 60079-31
Cert number IECEx UL 14.0072X
Applicable Area International
Ex db IIC T6 Gb
Markings Ex tb IIIC T85 °C Db IP66
-50 °C to +80 °C
Applicable Standards IEC 60079-0; IEC 60079-1; IEC 60079-31
Cert number
DEMKO 11 ATEX 1105261X
Applicable Area Europe (EU)
Markings II 1 G Ex ia IIC T6 Ga; -50 °C to +60 °C
Applicable Standards
EN IEC 60079-0; EN 60079-11
Cert number IECEx UL 14.0075X
Applicable Area International
Ex ia IIC T6 Ga
Markings
-50 °C ≤ Tamb ≤ +60 °C
Applicable Standards IEC 60079-0; IEC 60079-11
12 SERIES FOR USE IN CLASS I, DIV. 1, GROUPS A, B, C & D;
CLASS II, DIV. 1, GROUPS E, F & G; CLASS III HAZARDOUS
LOCATIONS. ENCLOSURE TYPE 4X, IP66. AMBIENT
TEMPERATURE RANGE -50°C (-58°F) TO 95°C (203°F).
12 Series
Explosion-Proof, Pressure, Vacuum, and
Diff erential Pressure Switches
DUAL SEAL
CERTIFIED
Refer to the final page for the Warranty.
ATEX AND IEC SPECIFIC CONDITIONS OF USE: THE WIRING
TO THE PRESSURE SWITCH MUST ONLY BE CONNECTED IN A
SAFE AREA OR BY AN APPROVED TERMINAL BOX CERTIFIED
TO EN 60079-0/IEC 60079-0, EN 60079-1/IEC 60079-1, AND EN
60079-31/IEC 60079-31 FOR HAZARDOUS LOCATIONS. THE
EPOXY RESIN SHALL NOT BE SUBJECTED TO A TEMPERATURE
GREATER THAN 125°C (257°F). THE WIRES SHALL BE PROTECTED
AGAINST MECHANICAL DAMAGE, E.G., BY USE OF CONDUIT.
OPTION M515 WITH DIN CONNECTOR IS NOT COVERED BY
THIS CERTIFICATE. OPTION M460, EXTERNAL EARTH GROUND
SCREW, IS TO BE USED IF METAL CONDUIT IS NOT USED.
ELECTRICAL CONDUIT FITTING THREADED CONNECTION SHALL
BE M20 X 1.5 WITH 7 THREADS MINIMUM ENGAGEMENT.
UE declarations and third-party issued Agency certifi cations
are available for download at www.ueonline.com.
PRIOR TO INSTALLATION, CHECK THE WETTED PARTS
MATERIAL FOR COMPATIBILITY TO THE PROCESS MEDIA.
THE DUAL SEAL DEVICE METHOD OF PRIMARY SEAL
FAILURE ANNUNCIATION IS VISIBLE LEAKAGE FROM
THE ENCLOSURE. DEPENDING UPON MEDIA SENSED,
ADDITIONAL METHODS OF LEAK DETECTION SHALL BE
REQUIRED.
THIS PRODUCT DOES NOT HAVE ANY FIELD REPLACEABLE
PARTS. ANY SUBSTITUTION OF COMPONENTS SHALL
INVALIDATE AGENCY CERTIFICATION(S), AND IMPAIR
SUITABILITY FOR CLASS I, DIV. 1 LOCATION.
PROOF PRESSURE * LIMITS STATED IN THE LITERATURE
AND ON NAMEPLATES MUST NEVER BE EXCEEDED, EVEN
BY SURGES IN THE SYSTEM. OCCASIONAL OPERATION OF
UNIT UP TO PROOF PRESSURE IS ACCEPTABLE (E.G., START-
UP, TESTING). CONTINUOUS OPERATION SHOULD NOT
EXCEED THE DESIGNATED OVER RANGE ** OR WORKING
PRESSURE RANGE***.
* Proof Pressure - the maximum pressure to which a pressure sen-
sor maybe occasionally subjected, which causes no permanent dam-
age (e.g., start-up, testing). The unit may require re-gapping.
** Over Range Pressure - the maximum pressure to which a pres-
sure sensor may be continuously subjected without causing damage
and maintaining set point repeatability.
*** Working Pressure Range - the pressure range in which two op-
posing sensors can be safely operated and still maintain set point
provided the diff erence in pressure between the low and high sides
does not exceed the designated adjustable range.
