- Page 1 Installation and operating instruction HERZ clever&smart Room Controller Clima WiFi 3 F810 24 Read carefully before installation, commissioning and operation...
-
Page 2: Table Of Contents
Room Overview Operating Mode Menu Set Operation Hours Set Operation Hours Example Expert Menu Settings Devices Rooms Sensors Room Controller WiFi Access Point WiFi Sensor Service Values Connecting HERZ clever&smart App to the HERZ clever&smart Room Controller Clima WiFi Support Notes... -
Page 3: Safety Instructions
HERZ clever&smart Room Controller Clima WiFi Safety Instructions EG-Conformity By affixing the CE mark to the unit the manufacturer declares that the HERZ clever&smart Room Controller Clima WiFi conforms to the following relevant safety regulations: EU low voltage directive 2014/35/EU... -
Page 4: Warranty And Liability
HERZ clever&smart Room Controller Clima WiFi Warranty and Liability The device has been manufactured and tested with regard to high quality and safety requirements. The warranty and liability shall not include, however, any injury to persons or material damage that is attributable to one or more of the following causes:... -
Page 5: Description Herz Clever&Smart Room Controller Clima Wifi
HERZ clever&smart Room Controller Clima WiFi 2 screws 3,5 x 35 mm and 2 plugs 6 mm for wall installation. Terminating resistor (120 Ohm) pre-installed on one of the two CAN High/CAN Low connections, operating tool, switch HERZ clever&smart Room Controller Clima WiFi installation guide... -
Page 6: Installation
When wall mounting, make sure that the cables are kept as short as possible (max. 40 mm for direct wall mounting), as unnecessary vein loops in the HERZ clever&smart Room Controller Clima WiFi housing can lead to problems. When mounting on a switch box, make sure that the cables are kept as short as possible (strip cables max. - Page 7 Power supply 24 VDC, ensure correct polarity or it may cause damage to the unit! For the pin assignment of the CAN bus line on the HERZ clever&smart Control Box, please refer to the corresponding instructions for use or operating manual.
-
Page 8: Operation
HERZ clever&smart Room Controller Clima WiFi Operation Room Overview Displays the room temperature, humidity and outdoor temperature after activating the start screen. Room humidity Relative humidity. °C Room icon Room temperature Selecting a room icon takes you to the room temperature settings. -
Page 9: Operating Mode
HERZ clever&smart Room Controller Clima WiFi Operating Mode Overview > Operating Mode Menu Back/ Forward Navigate to the main menu Navigate back to the overview. Room Displays the selected space. Operating Modes The operating mode shown in colour is currently active and can be changed by selecting another mode. -
Page 10: Set Operation Hours
HERZ clever&smart Room Controller Clima WiFi Set Operation Hours Overview > Operating Mode > Menu > Timer Setting of individual heating and cooling times for the selected room. Menu Operating Modes Opens the copy function. The function Selection of the operating mode to... -
Page 11: Set Operation Hours Example
HERZ clever&smart Room Controller Clima WiFi Set Operation Hours Example Step 2 Select the desired mode (Normal, Comfort, Eco or Off) and then move your index finger over the desired time period. The selected period changes colour to the colour of the selected operating Step 1 mode after selection. -
Page 12: Expert Menu
HERZ clever&smart Room Controller Clima WiFi Expert Menu Overview > Operating Mode > Menu > Expert Select Language Set the device language Date & Time Setting the time and date and automatic summertime/wintertime Settings changeover Parameterisation of the heating/cooling system... -
Page 13: Settings
Zones Assigning rooms to heating and clever&smart Control Box Clima. This cooling zones. menu is only visible if this HERZ clever&smart Room Controller Clima was set as the "Configurator" ("Expert > Settings > Devices > Control box > Configurator") of the HERZ clever&smart Control Box Clima... -
Page 14: Devices
HERZ clever&smart Room Controller Clima WiFi Devices Overview > Operating mode > Menu > Expert > Settings > Devices Clima systems must first be switched to 'heating' mode before another device can be added to the system during operation. Add Device... - Page 15 HERZ clever&smart Room Controller Clima WiFi...
-
Page 16: Rooms
HERZ clever&smart Room Controller Clima WiFi Rooms Overview > Operating mode > Menu > Expert > Settings > Rooms Add Room Adding rooms Room 2 Setting the location, sensors and actuators of the respective room Overview > Operating mode > Menu > Expert > Settings > Room 2... -
Page 17: Sensors
HERZ clever&smart Room Controller Clima WiFi Sensors Overview > Operating mode > Menu > Expert > Settings > Rooms > Room 1 > Sensors > Temperature Icon Already selected sensor CAN ID of the Control Box + serial number Temperature sensor selection in the selected room Overview >... -
Page 18: Room Controller
HERZ clever&smart Room Controller Clima WiFi Room Controller Overview > Operating mode > Menu > Expert > Settings > Room Controller Activate and set additional functions. Thermostat 1 Switches the defined output to the set room / rooms depending on time and temperature. - Page 19 HERZ clever&smart Room Controller Clima WiFi Overview > Operating mode > Menu > Expert > Settings > Room Controller > Dehumidifier The dehumidifier function switches the defined output depending on the set humidity in the set room(s). Output Assign the output to be switched by the Operating Mode function.
- Page 20 HERZ clever&smart Room Controller Clima WiFi Overview > Operating mode > Menu > Expert > Settings > Room Controller > Timer 1 The function Timer 1-2 switches the defined output depending on the set times. Output Assign the output to be switched by the function.
- Page 21 HERZ clever&smart Room Controller Clima WiFi Overview > Operating mode > Menu > Expert > Settings > Room Controller > Fan coil 1 The fan coil function controls convection heating and cooling via the 0-10V/PWM outputs . Output Assign the output to be switched by the function.
-
Page 22: Wifi
HERZ clever&smart Room Controller Clima WiFi WiFi Overview > Operating mode > Menu > Expert > Settings > WiFI Activate WiFi Activate WiFi function WiFi status Information about the WiFi status and the device address (which is needed Select Network to connect to the HERZ clever&smart... - Page 23 HERZ clever&smart Room Controller Clima WiFi DNS/ DNS 2 Entering the DNS address Connecting the HERZ clever&smart Room Controller Clima WiFi to a Access Point WPS-enabled router Settings for routing and the WPS repeater WiFi Sensor Settings for the LED display and the...
-
Page 24: Access Point
HERZ clever&smart Room Controller Clima WiFi Access Point Overview > Operating Mode > Menu > Expert > Settings > WiFi > Access Point Routing Mode The automatic routing independently selects between a direct connection of WiFi devices with the access point of the HERZ clever&smart Room... -
Page 25: Service Values
Connect HERZ clever&smart Room Controller Clima WiFi with the WLAN network: Expert Settings WiFi Choose Network Enter the selected e-mail address in the access list in HERZ clever&smart Room Con- troller Clima WiFi when logging in to the account: Expert Settings WiFi "Man- age access". -
Page 26: Support
CAN high and CAN low connections for terminating the CAN bus? No additional function can be assigned to Is the selected function already assigned to another output? Is the output already assigned to another function? the analogue outputs V1/V2 of the HERZ Room Controller Clima WiFi. Notes... - Page 27 Subject as a basic principle to errors and technical changes. Date and time of installation: Name of installation company: Space for notes: Herz Armaturen Ges.m.b.H. Richard-Strauss-Straße 22 1230 Wien, Österreich +43 (0) 1 616 26 31 - 0 office@herz.eu...
