Accessory Description
Mounting kit, isolated
1
2
For reliably insulated fixing of the probe.
Maximum process temperature: 150 °C (300 °F)
For rope probes 4 mm (1/6 in) or 6 mm (1/4 in) with PA>steel:
• Eye-bolt M8 DIN 580
• Diameter D = 20 mm (0.8 in)
• Order-No.: 52014249
For rope probes 6 mm (1/4 in) or 8 mm (1/3 in) with PA>steel:
• Eye-bolt M10 DIN 580
• Diameter D = 25 mm (1 in)
• Order-No.: 52014250
Due to the risk of electrostatic charge, the insulating sleeve is not suitable for use in
hazardous areas. In these cases the fixing must be reliably grounded.
1
2
D
Insulating sleeve
Eye-bolt
The mounting kit can also be ordered directly with the device (see the Levelflex
product structure, feature 620 "Accessory Enclosed", option PG "Mounting kit,
isolated, rope").
A0013586
