- Page 1 S.E.A. Paraglider cocoon RUNA pilot manual...
-
Page 2: Table Of Contents
CONTENT Introduction Description Speci cations General information Before you y Pre- ight check-list Connection of the rescue parachute Installation the rescue parachute Compatibility between harness and rescue parachute Activating the rescue parachute Adjust and t the harness Inspections Disposal, recycling Repairs Care and storage of harness Environmental information... -
Page 3: Introduction
INTRODUCTION S.E.A. Paragliders follow the philosophy of “paragliding is not just ying”. We believe that paragliding does not start after takeo and does not end with landing. For us, lightweight and reliable equipment is a means to expand the pilot's possibilities in choosing starts and ying places. -
Page 4: Description
DESCRIPTION OF RUNA HARNESS Runa was designed to be the lightest harness for regular cross-country pilots who want more freedom of movement without sacri cing ight quality. The Runa is lighter, but without compromising on ight comfort, safety, aerodynamics or usability. The Runa power structure is made with a large margin of safety and does not require special handling, but do not forget that the outer skin of your harness is made of almost the same fabric as your paraglider. -
Page 5: General Information
GENERAL INFORMATION FEATURES 1. Outer pocket (twin) 7. Back in atable protector 13. Footplate 2. Rescue parachute container 8. Bottom pocket 14. Main carabiner (twin) a) container pocket 9. Shoulder strap (twin) 15. Left cocoon panel b) container fastener 10. Side adjustment strap (twin) 16. - Page 6 POWER STRUCTURE Runa has a hammock design. The harnesses of this type does not have a rigid board under the pilot. This design saves weight, and allows more precise tuning of the harness to the individual proportions of the pilot. ACCELERATOR The harness is supplied with a compact two-step speedbar.
- Page 7 BACK PROTECTOR The in atable protector — is a key element of the harness Runa concept. Thanks to him, the packing volume of the harness is so small that it can be used instead of a roller inside the glider, taking care of its long plastic rods. AEROBATICS Runa harness is not intended for acrobatic maneuvers in order to avoid getting into dangerous ight situations.
-
Page 8: Before You Y
BEFORE YOU FLY Before the rst ight, the harness must be prepared at home: install a reserve parachute, adjust the harness for the pilot, adjust the accelerator. Harness adjustments can require serious attention, with many pilots adjusting the new suspension after several ights to achieve maximum comfort and control. It is very important to understand here that tting the harness is a long process, but the reward is high. - Page 9 Second, pass the lines through Third, route the lines through Fourth, route the lines through metal rings on front end of both pulleys on the sides of both eyelets under harness seat board. harness. carabiners. Then tie the line to the brummel hook with a bowline knot and attach the speed system to the corresponding cords on risers of paraglider.
-
Page 10: Pre- Ight Check-List
PRE FLIGHT CHECK LIST Before each take-o you must do next check: - there no any damage on the harness or carabiners; - the rescue chute container closed correctly; - deployment handle attached correctly; - all buckles, belts, zips are securely fastened; - all ight instruments are secured;... -
Page 11: Connection Of The Rescue Parachute
CONNECTION OF THE RESCUE PARACHUTE 1. Connect the handle to the inner container of the rescue parachute. Use a loop in the middle of your inner container. 2. The main riser of the rescue parachute must be connected to V-bridle of the harness. Two methods of this connection are commonly used: - by the steel carabiner (it must be tighted): - by loop “bridle-to-bridle”... -
Page 12: Installation The Rescue Parachute
INSTALLATION THE RESCUE PARACHUTE Lightweight compact parachutes such as the S.E.A. Paragliders WTF are better suited for Runa harness. It is best to leave the rescue parachute installation to an experienced instructor or harness manufacturer's representative. It is very important that the rescue parachute is repacked shortly before being installed in the harness - this directly a ects the safety of the pilot. -
Page 13: Compatibility Between Harness
COMPATIBILITY BETWEEN HARNESS AND RESCUE PARACHUTE After installation of the rescue parachute, it is necessary to check the compatibility of the parachute and harness. Use the harness simulator - put on the harness with installed parachute, fasten all the buckles and attach the harness with main carabiners to the simulator. -
Page 14: Adjust And T The Harness
- Immediately after opening the parachute it is necessary “to kill” the canopy of the paraglider to avoid the “bell” regime. To do this, tighten the B- or C-risers of the glider rmly and deeply. If this is not possible, you need to deeply tighten the brakes of the paraglider until it enters a complete stall;... - Page 15 ADJUSTMENTS PRINCIPLES The cocoon frontal lines (12) de nes the overall harness pitch adjustment. The relative lengths of the upper (12u) and lower (12d) frontal lines de nes the angle of footplate (13). The lumbar adjustments (11) re ect the shape of the pilot's body and their adjustment depends on his body size. The side straps is adjusted with strong plastic buckles (10).
- Page 16 FOLLOW THE NEXT INSTRUCTION TO PUT ON THE HARNESS: 1. Place the shoulder straps over 2. Lock the Get Up system 3. Pass the right ball through your shoulders. (Arms are inside the left loop of the speedbag the shoulder straps). 4.
-
Page 17: Inspections
INSPECTIONS We at S.E.A. Paragliders recommend to do a technical inspection of the harness every 24 months. The full inspection can be done by the manufacturer or his representative. It is highly recommended with regular pre- ight checks to do inspection thoroughly on every rescue repack of 6 months. -
Page 18: Repairs
REPAIRS Only the manufacturer or his approved specialist can perform any repair that involves critical parts of the harness. This will ensure that the correct materials and repair techniques are used. CARE AND STORAGE OF HARNESS - put the harness in a bag or backpack as carefully as possible; - store the harness at a temperature between 10°... -
Page 19: Environmental Information
WARRANTY We at S.E.A. Paragliders provides a 12-month or 100 ight hours warranty - for the correct and ¬ awless function of the harness. The warranty covers only manufacturing or functional defects. The warranty does not cover hidden defects in material, as well as defects caused by improper use, inappropriate storage, damages during transporta- tion, or harsh handling and using that is not in appropriate accordance with the product design. - Page 20 HARNESS DATA SIZE COLOR Date of manufacturing Serial number Checks and repairs: S,E,A, Paragliders Gvardeytsev Shironintsev str. 40D, 62 Kharkov, 61123, UKRAINE, +38 050 159-27-76 +38 050 257-46-38 www.sea-wings.pro...
