https://wiki.teltonika-gps.com/view/Teltonika_FMx_640_With_TCP_Link_Mode
Teltonika FMx 640 With TCP Link Mode
Main Page
>
EOL Products
Contents
1 Introduction: Understanding what is FMB640 RS232/RS485 TCP Link mode:

2 Step 1. Connect the FMx640 to the RS232 on COM1:

3 Step 2. FMx640 Configuration:

4 Step 3. Establishing FMx test link with server through Hercules and sending messages with
Hercule:
Introduction: Understanding what is FMB640 RS232/RS485 TCP Link mode:
In this mode link with external device (for example PC) using text messages can be established. FMx
has to be connected to the external device through RS 232 on COM1/COM2 port of FMx. Any string
of data coming to COM port will be routed to server (if link is currently active). Messages that are
exchanged between FMx device and server, have to be packed in Codec.12 format. Here for TCP link
establishment, we will use Hercules. For sending messages from FMx to server Terminal will be
used.
Step 1. Connect the FMx640 to the RS232 on COM1:
Step 2. FMx640 Configuration:
The FMx configurator you have to set parameters for COM1 or COM2 (depends on which COM port
you are using) in global parameters window. You have to modify the server sittings to your PC IP and
your TCP port.
>
FMB640
>
FMB640 Manual
> Teltonika FMx 640 With TCP Link Mode

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMx 640 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teltonika FMx 640

Summary of Contents for Teltonika FMx 640

  • Page 1 > FMB640 > FMB640 Manual > Teltonika FMx 640 With TCP Link Mode Contents 1 Introduction: Understanding what is FMB640 RS232/RS485 TCP Link mode: 2 Step 1. Connect the FMx640 to the RS232 on COM1: 3 Step 2. FMx640 Configuration: 3.1 Message Timestamp...
  • Page 2 · Modify the Mode from silent to TCP/UDP Ascii mode. · Make sure that the Baud rate is matching with the baud rate in the terminal, in our example it is the sensor...
  • Page 3 Note: Try to make sure that your TCP Port is open by checking it with any port checker websites. Message Timestamp Message Timestamp parameter is used to determine if it is necessary to include a timestamp in the RS232 TCP packet when sending it to the server. If the parameter is Enabled, then Codec 13 is used for data sending.
  • Page 4 Step 4. Receiving messages with Hercules: In this step we need to use the terminal log. When you want to send a message from FMx 640 to the server, write it in Terminal but change your com port and select port which is assigned for...
  • Page 5 Terminal Log Sending Text After doing the mentioned configuration you can type your message in the marked field, check +CR and press Send button. If sent successfully, you will see it in Hercules Received data field.
  • Page 6 Receiving Text from The Terminal to Server Hercules The Conclusion: In this mode link with an external device for example PC using text messages can be established. We can apply this scenario on FMx640 or FMx125 which have to be connected to the external device through RS232 or RS485.
