3. Product Introduction

3.1 Scope

This product is designed for breaking masonry materials,
including brick, concrete, blockwork, hard earth and
stone.
WARNING! DO NOT use this product to chisel
into materials such as wood, metals and
plastics.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts
no responsibility for improper use of this product.

3.2 Specification

Stock No.
Part No.
Rated voltage
Rated frequency
Rated input
Impact force
Impact rate
Chuck type
Noise emissions
Sound pressure level
Sound power level
Uncertainty
Vibration levels (chiselling)
Main handle
Auxiliary handle
Uncertainty
Appliance Class
Net Weight (bare)
Important: The declared vibration total values and noise emissions values have been measured in accordance with a
standard test method and may be used for comparing one tool with another. These values may also be used in a
preliminary assessment of exposure.
WARNING! The vibration and noise emissions during actual use of the product can differ from the declared
values depending on the mode selected and the workpiece upon which it is used. Before each use, estimate
the likely exposure resulting from the actual conditions of use. Take into account all parts of the operation
cycle in order to identify any safety measures required to protect the operator.
Part of our Expert range, this product is intended for
frequent trade use, with the quality and features to meet
and exceed expectations of the most demanding user.
WARNING! This product is not a toy and
must be respected.
Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later
use.
81077
PHD1050MAX
220–240V AC
50Hz
1,050W
25J
4,300bpm
SDS MAX
92dB(A)
105dB(A)
3dB(A)
17.44m/s
2
10.92m/s
2
1.5m/s
2
Class II
7.3kg
