5. The reduced battery capacity in low-temperature environments reduces the wind speed
resistance performance of the aircraft. Fly with caution.
6. Fly with extra caution at high sea levels.

Charging the Battery

Fully charge the Intelligent Flight Battery before every flight
Using DJI 65W Portable Charger
1. Connect the DJI 65W Portable Charger to an AC power supply (100-240 V, 50/60 Hz).
2. Attach the aircraft to the charger using the battery charging cable with the battery powered off.
3. The battery level LEDs display the current battery level during charging.
4. The Intelligent Flight Battery is fully charged when all the battery level LEDs are off. Detach the
charger when the battery is fully charged.
• DO NOT charge an Intelligent Flight Battery immediately after flight as the temperature
may be too high. Wait until it cools down to room temperature before charging again.
• The charger stops charging the battery if the battery cell temperature is not within the
operating range of 5° to 40° C (41° to 104° F). The ideal charging temperature is 22° to 28°
C (71.6° to 82.4° F).
• Fully charge the battery at least once every three months to maintain battery health.
• DJI does not take any responsibility for damage caused by third-party chargers.
• It is recommended to discharge the Intelligent Flight Batteries to 30% or lower before
transportation. This can be done by flying the aircraft outdoors until there is less than 30%
charge left.
The table below shows the battery level during charging.
LED1 LED2
Battery Protection Mechanisms
The battery LED indicator can display battery protection prompts triggered by abnormal charging
conditions.
46
©
2022 DJI All Rights Reserved.
LED3 LED4
Battery Level
0% < Battery Level ≤ 50%
50% < Battery Level ≤ 75%
75% < Battery Level < 100%
Fully Charged
