Assembly Instructions
E.C. Woods, Inc. Outdoor Furniture
WESTBROOK

Tools Needed

5/32" Allen Wrench
7/16" Wrench
6" #2 Square Drive Bit
STEP 1: Lay all pieces on smooth, soft surface, such as cardboard, to avoid scratching. Be careful to not over tighten any of
the fasteners.
