Assembly Instructions
Tools Needed
Cordless Drill
6" #2 Square Drive Bit
STEP 1: (a) Lay all pieces on a smooth soft surface such as cardboard or carpet to help avoid scratching. We suggest using a 6"
#2 square drive bit to fasten all screws (available at your local hardware store). Be careful to not over tighten any of the
fasteners.
SHAWNEE/CONTEMPORARY
E.C. Woods, Inc. Outdoor Furniture
(a)
Advertisement
Table of Contents
Related Manuals for E.C. Woods SHAWNEE
Summary of Contents for E.C. Woods SHAWNEE
- Page 1 Assembly Instructions E.C. Woods, Inc. Outdoor Furniture SHAWNEE/CONTEMPORARY Tools Needed Cordless Drill 6” #2 Square Drive Bit STEP 1: (a) Lay all pieces on a smooth soft surface such as cardboard or carpet to help avoid scratching. We suggest using a 6”...
- Page 2 STEP 2: (b) Use a soft hammer (if necessary) to insert the seat skirts and stretchers in to the mortises in the Side Assembly making sure that the screw pockets in the seat skirts are facing up. (c) Place the other Side Assembly on top of the subassembly, with the mortises facing down, and then line the seat skirts and stretchers up with the mortises in the Side Assembly and gently pound them in using your hand or a soft hammer.
- Page 3 STEP 4: (h) Stand the assembled chair up and loosen the screws in one side of the rear seat skirt to aid in inserting the chair back assembly. (i) Insert the chair back assembly in to the mortises in the chair back legs and fasten using the 1½” stainless steel round head screws provided.
- Page 4 ecwoutdoorfurniture.com...
