Assembly Instructions
Tools Needed
Cordless Drill
6" #2 Square Drive Bit
Tape Measure
Soft Hammer
STEP 1: (a) Lay all pieces on a smooth soft surface such as cardboard or carpet to help avoid scratching. We suggest
using a 6" #2 Square bit to fasten all screws (available at your local hardware store). Be careful to not over tighten any
of the fasteners.
WESTPORT TABLE
E.C. Woods, Inc. Outdoor Furniture
(a)
Advertisement
Related Manuals for E.C. Woods WESTPORT TABLE
Summary of Contents for E.C. Woods WESTPORT TABLE
- Page 1 Assembly Instructions E.C. Woods, Inc. Outdoor Furniture WESTPORT TABLE Tools Needed Cordless Drill 6” #2 Square Drive Bit Tape Measure Soft Hammer STEP 1: (a) Lay all pieces on a smooth soft surface such as cardboard or carpet to help avoid scratching. We suggest using a 6”...
- Page 2 STEP 2: (b) (4x) Insert the side stretchers in to the mortises in a leg assembly and secure them with 1 ½” stainless steel round head screws. (c) Insert the stretchers in to the mortises of the other leg and secure them with 1 ½” stainless steel round head screws.
- Page 3 STEP 3 For a square top go to (h) & (i) (f) Secure the leg assembly to the bottom of the table top through the pocket holes using 1 ½” stainless steel round head screws with the wide part of the leg in line with the table top boards. (g) Secure the aluminum braces to the legs through the predrilled holes in the braces with 1 ¼”...
