Assembly Instructions
Tools Needed
Cordless Drill
6" #2 Square Drive Bit
2" #2 Square Drive Bit
STEP 1: Lay all pieces on smooth, soft surface, such as cardboard, to avoid scratching. Be careful to not over tighten any of
the fasteners.
LIBERTY ROCKER
E.C. Woods, Inc. Outdoor Furniture
Advertisement
Summary of Contents for E.C. Woods LIBERTY
- Page 1 Assembly Instructions E.C. Woods, Inc. Outdoor Furniture LIBERTY ROCKER Tools Needed Cordless Drill 6” #2 Square Drive Bit 2” #2 Square Drive Bit STEP 1: Lay all pieces on smooth, soft surface, such as cardboard, to avoid scratching. Be careful to not over tighten any of...
- Page 2 STEP 2: (a) Remove the shipping blocks from both rocker side assemblies. (b) Place the front of the seat assembly into the mortise of one of the rocker side assemblies (use a soft hammer if needed). (c) Fasten the front seat rail to the rocker side assembly by using 1 –...
- Page 3 STEP 3: (e) Place the rear of the seat assembly into the mortise of the rocker side assembly. (f) Fasten the seat side support to the rocker side assembly by using 2 - 1 ½” stainless steel flat head screws thru the pre drilled holes in the seat side support (flip assembly over and repeat (b), (c), (d), (e), (f) for the other side).
- Page 4 STEP 4: (i) (x2) Fasten the back center support to the arms thru the pocket holes in the back center support into the pre drilled holes in the arm by using 2 – 1 ½” stainless steel pan head screws on each side (making sure that the pocket hole and the mortise for the arm support are facing up).
