IM PO R TANT ! R EAD CARE F ULY AND KE EP
TH I S US ER 'S M ANUAL IN A S AFE P LACE
F OR F UT U RE REF E RE NCE !
INSTRUCTION MANUAL FOR
BABY STROLLER "AMORE"
This stroller
has
been
manufactured
in
accordance with the Product Safety Directive 2001/95/EU of the
European Parliament and The Council and with European standard
EN 1888-1 + A1:2022 "Child care articles. Wheeled child conveyances.
Part 1: Baby strollers and carry cot", EN 1888-2 + A1:2022 "Child care
articles. Wheeled child conveyances. Part 1: Baby strollers from 15
up to 22 kg and the regulations of national law, including Consumer
Protection Law.
Advertisement
Related Manuals for Chipolino AMORE
Summary of Contents for Chipolino AMORE
- Page 1 IM PO R TANT ! R EAD CARE F ULY AND KE EP TH I S US ER ’S M ANUAL IN A S AFE P LACE F OR F UT U RE REF E RE NCE ! INSTRUCTION MANUAL FOR BABY STROLLER “AMORE” This stroller been manufactured...
- Page 2 ATTENTION! YOUR CHILD WILL BE MOST SECURE IF YOU FOLLOW THE INSTRUCTIONS AND RECOMMENDATIONS GIVEN IN THIS USER’S MANUAL! WARNING! INSTRUCTIONS AND WARNINGS FOR SAFETY! CAUTION! NEVER LEAVE YOUR CHILD UNATTENDED! CAUTION! ALWAYS USE SAFETY BELTS, AS SOON AS THE CHILD CAN REMAIN IN A SITTING POSITION UNAIDED AND CAN PUSH HIMSELF WITH HANDS OR KNEES! ...
-
Page 3: Main Features
Stroller is suitable for newborn babies and children aged up to 4 years and weighing up to 22 kg (whichever comes first); The seat transforms into a carry cot that can be used for children aged less than 6 months and weighting not more than 9 kg.; Car seat “AMORE”, Child’s height from 40 up to 85 cm, weight ≤ 13 kg, age from birth up to 15 months. It is safe and compatible with stroller’s frame; Note: Car seat is sold separately. All instructions and recommendations for safety usage and installation are given in separate user’s manual;... -
Page 4: Main Parts
MAIN PARTS Canopy Handle Handle height Front adjustment button bumper Sliders for folding Safety belt Storage basket Parking device Rear wheels Front wheels ATTENTION! Before assembly make sure that all parts are available. ASSEMBLY INSTRUCTION AND FUNCTIONS This stroller is supplied partially assembled. In order to complete the assembly, you don’t need any tools. -
Page 5: Backrest Adjustment
ASSEMBLY 1 – OPEN THE FRAME Release the fixing (1). Grab the handle and pull upwards (2) until stroller opens and you hear a click sound. 2 – INSERT AND REMOVE OF FRONT WHEELS Insert the front wheel into the hub at frame (1) and press. You must hear a click. Make sure that wheel is securely fixed to frame, as trying to pull it out. To remove the front wheel, press the button for removal (2) and pull the wheel downwards. 3 –... - Page 6 10 – SWIVELING AND STRAIGHT DIRECTION OF FRONT WHEELS Press the levers (1) downwards to activate the straight direction of front wheels. Pull the levers (1) upwards to activate the swiveling of front wheels. ATTENTION! When using the stroller on uneven terrains, set the front wheels in straight direction only. 11 –...
- Page 7 Place the foot cover over the stroller as shown in the photo. Attach it to the seat via zipper (1). Wrap the foot cover over the bumper bar and fix with snap buttons (2). 19 – INSTALLATION OF CAR SEAT “AMORE” ON FRAME OF STROLLER “AMORE” Note: For your comfort before installation of car seat on stroller’s frame activate the parking device.
- Page 8 “click” “click” “click” “click” “click” “click”...
- Page 9 Straight motion Released “click” Swivel motion Activated “click” 13-1 13-2 “click” 14-1 14-2 15-3 15-1 15-2...
- Page 10 “click” “click” 16-3 16-1 16-2 17-1 17-2 “click” “click” 19-1 19-2...
-
Page 11: Care And Maintenance
CARE AND MAINTENANCE The brakes and wheels wear out faster than other parts. Replace them when necessary. Regularly oil the moving parts. Use silicone oil or silicone spray for oiling. Dirt could make difficult the function of your stroller. Clean and oil all dirty metal and plastic parts regularly. - Page 12 1 Goliamokonarsko shosse, Plovdiv, BULGARIA www.chipolino.com...
