dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc
FPGA setup for 2-Ch RAID0 by NVMe-IP Demo
This document describes the FPGA and test environment setup for running 2-ch RAID0 by using
NVMe-IP, NVMeG3-IP, NVMeG4-IP, or NVMe-IP for Gen4 demo on FPGA development board by
using the AB17-M2FMC board or AB18-PCIeX16 board with Quad M.2 card for connecting with
two M.2 NVMe SSDs. It is recommended to use the same SSD models for RAID0 operation to
match SSD characteristic. User controls test operation via Serial console.
1 Test Environment setup
To run the demo on FPGA development board, please prepare following environment.
1) FPGA development board: VCK190, VCU118, ZCU106, ZCU102, KCU105
2) The adapter of M.2 SSD
a. AB17-M2FMC board
https://dgway.com/ABseries_E.html
b. AB18-PCIeX16 board with Quad M.2 card
https://dgway.com/ABseries_E.html
https://www.asrock.com/mb/spec/product.asp?Model=ULTRA%20QUAD%20M.2%20CA
RD
3) Two M.2 NVMe SSDs, inserting to M.2 connector on AB17/Quad M.2 card
4) For AB18 only, ATX power supply for PCIe adapter board
5) Xilinx power adapter for FPGA board
6) Two micro USB cables/one USB type-C cable for programming FPGA and Serial console,
connecting between FPGA board and PC
7) PC installing Xilinx programmer software (Vivado) and Serial console software such as
TeraTerm and HyperTerminal
3-Aug-22
Rev2.2
3-Aug-22
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VCK190 and is the answer not in the manual?

Questions and answers

Summary of Contents for DG VCK190

  • Page 1 SSD characteristic. User controls test operation via Serial console. 1 Test Environment setup To run the demo on FPGA development board, please prepare following environment. 1) FPGA development board: VCK190, VCU118, ZCU106, ZCU102, KCU105 2) The adapter of M.2 SSD a. AB17-M2FMC board https://dgway.com/ABseries_E.html...
  • Page 2 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc Figure 1-1 NVMe RAID0x2 demo setup by AB17 on KCU105 3-Aug-22 Page 2...
  • Page 3 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc Figure 1-2 NVMe RAID0x2 demo setup by AB17 on ZCU106 3-Aug-22 Page 3...
  • Page 4 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc Figure 1-3 NVMe RAID0x2 demo setup by AB17 on ZCU102 3-Aug-22 Page 4...
  • Page 5 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc Figure 1-4 NVMe RAID0x2 demo setup by AB18 on VCU118 3-Aug-22 Page 5...
  • Page 6 Figure 1-5 NVMe RAID0x2 demo setup by AB17 on VCK190 3-Aug-22 Page 6...
  • Page 7 For AB17, connect two M.2 NVMe SSDs to Drive#1 and #2 connector and then connect AB17-M2FMC to HPC on KCU105 (J22), HPC-1 on ZCU106 (J5), HPC-0 on ZCU102 (J4), or FMCP-1 on VCK190 (J51) as shown in Figure 2-1. Figure 2-1 Connect M.2 NVMe SSDs to AB17-M2FMC...
  • Page 8 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc b) For Quad M.2 card, please follow below steps. i. Insert two M.2 NVMe SSDs to M2_1 and M2_2 connectors on Hyper Quad M.2 card, as shown in Figure 2-2. Figure 2-2 Two M.2 NVMe SSDs on Hyper Quad M.2 Card ii.
  • Page 9 3) Connect USB cable between FPGA board and PC for FPGA programming and Serial console as shown in Figure 2-4 a) VCK190: Connect one USB type-C cable. b) Other boards: Connect two micro USB cables. Figure 2-4 USB cable connection 4) Turn on power switch of AB17/AB18, ATX power supply for AB18 (when using AB18), and FPGA development board as shown in Figure 2-5.
  • Page 10 5) After connecting USB cables to PC, many COM ports are detected. a) KCU105/VCU118: Select Standard COM port b) ZCU106/ZCU102/VCK190: Select the lowest number of the additional COM ports. Figure 2-6 Additional COM port when USB cable is plugged-in On Serial console, the setting is as follows.
  • Page 11 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc 6) For KCU105 board by AB17, open Serial console to connect with Enhanced COM port (Buad rate=115,200 Data=8 bit Non-Parity Stop=1). The console shows System Controller menu, as shown in Figure 2-8. To set VADJ of FMC to 1.8V, the following step is recommended.
  • Page 12 ZCU102, ZCU106, and VCK190 board Open Vivado TCL shell and change directory to download or directory that batch file is located. Next, type “NVMeXXRaid0x2Test_ZCU106/ZCU102/VCK190.bat”, as shown in Figure 2-10. Figure 2-10 Command script to download demo file on Vivado TCL shell...
  • Page 13 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc 8) Check LED status on FPGA board. The description of LED is as follows. Table 2-1 LED Definition GPIO LED Normal operation 1) PCIe Clock or system Clock is not locked. 2) Reset button is pressed. System is busy Idle status IP Error detect Normal operation...
  • Page 14 dg_nvmeip_raid0x2_fpgasetup_xilinx_en.doc 10) Main menu is displayed in Serial console and ready to receive command. Figure 2-12 Main menu after RAID0 finishes initialization 3-Aug-22 Page 14...
  • Page 15: Revision History

    3 Revision History Revision Date Description 3-Aug-22 Include NVMe-IP for Gen4 and support VCK190 board 15-Jul-21 Include NVMeG4-IP demo 29-Jun-20 Remove demo instruction from the document and add NVMeG3-IP 9-Oct-17 Initial version release 3-Aug-22 Page 15...
