Introduction:

Congratulations. You have selected one of the finest sound reinforcement amplifiers available,
the Crate Audio SPA100 1/2-Rack Power Amplifier. Our many years of experience in high-perform-
ance audio equipment, combined with our extensive research and development procedures, have
enabled us to produce an amplifier which provides the highest quality and reliability possible.
Like all Crate products, your SPA100 amplifier was designed and manufactured using only the
finest components and materials. Each amplifier design must satisfy our team of highly-trained tech-
nicians and musicians before it is approved. We insist upon high level of quality control to ensure that
each amplifier produced will provide its owner with years of trouble-free, ear-pleasing performance.
Your new SPA100 is a flexible part of any sound system – simple to connect and easy to operate
– if you first know how to incorporate it into your application. Several configurations are covered in
this manual, along with important information regarding impedance ratings and output power. In
order to get the best performance and highest level of quality and reliability from your new amplifier,
please read this user's guide before operating the unit.

Features:

The Crate SPA100 is a ruggedly constructed high quality power amplifier designed to give you
continuous performance with professional results. Two of these amplifiers can be mounted side by side
in a standard 19" rack, requiring only 1-3/4 inches of vertical rack space. The automatic variable-
speed internal cooling system uses the front, side and rear of the amplifier - not the top and bottom -
for its air intake and exhaust, allowing you to stack multiple components closer together in a rack
mount situation.
The SPA100 produces up to 100 watts of power @ 4 ohms, or 75 watts @ 8 ohms. Several "pro-
fessional" features have been built into the SPA100, such as 1/4" phone and XLR input jacks with elec-
tronically balanced Low or High impedance operation. Built-in limiting circuitry constantly monitors
the output of the amplifier for clipping, thus helping prevent the generation of speaker-damaging
square waves. A built-in protection circuit guards the amplifier against damages from overloads, short
circuits, or overheating. In addition, each channel features a Signal LED to assist in hookup and trou-
bleshooting, and a Peak LED to allow you to set the input level for the best signal to noise ratio.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
•
READ, FOLLOW, HEED, AND KEEP ALL INSTRUCTIONS AND WARNINGS.
•
DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOT BLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS. FOR PROPER OPERATION, THIS UNIT REQUIRES 3"
(75CM) OF WELL VENTILATED SPACE AROUND HEATSINKS AND OTHER AIR FLOW PROVISIONS IN THE CABINET.
•
DO NOT USE THIS APPARATUS NEAR SPLASHING, FALLING, SPRAYING, OR STANDING LIQUIDS.
•
CLEAN ONLY WITH LINT-FREE DAMP CLOTH AND DO NOT USE CLEANING AGENTS.
•
ONLY CONNECT POWER CORD TO A POLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES AND COMPATIBLE WITH VOLTAGE, POWER, AND
FREQUENCY REQUIREMENTS STATED ON THE REAR PANEL OF THE APPARATUS.
•
PROTECT THE POWER CORD FROM DAMAGE DUE TO BEING WALKED ON, PINCHED, OR STRAINED.
•
UNPLUG THE APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME.
•
ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE OPERATION AND TO AVOID INJURY.
•
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
•
SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.
•
OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH SOUND PRESSURE LEVELS CAN CAUSE PERMA-
NENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND EAR PROTECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME.
EXPLANATION OF GRAPHICAL SYMBOLS:
EXPLICACION DE SIMBOLOS GRAFICOS:
EXPLICATION DES SYMBÔLES GRAPHIQUES:
1 / 2 - R a c k P o w e r A m p l i f i e r
PRECAUCION
RIESGO DE CORRIENTAZO
NO ABRA
PRECAUCION: PARA REDUCIR EL RIESGO DE INCENDIOS O DESCARGAS ELECTRICAS, NO PER-
MITA QUE ESTE APARATO QUEDE EXPUESTO A LA LLUVIA O LA HUMEDAD. PARA DISMINUOIR EL
RIESGO DE CORRIENTAZO. NO ABRA LA CUBIERTA. NO HAY PIEZAS ADENTRO QUE EL USARIO
PUEDO REPARAR DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS.
IMPORTANT SAFETY INSTRUCTIONS
"DANGEROUS VOLTAGE"
=
"VOLTAJE PELIGROSO"
"DANGER HAUTE TENSION"
ATTENTION
RISQUE D'ELECTROCUTION
NE PAS OUVRIR
ATTENTION: PROTÉGEZ CET APPAREIL DE LA PLUIE ET DE L'HUMIDITÉ AFIN D'ÉVITER TOUT
RISQUE D'INCENDIE OU D'ÉLECTROCUTION. POUR REDUIRE D'ELECTROCUTION NE PAS ENLEVER
LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE PAR L'UTILISATEUR. POUR TOUTE
REPARATION, S'ADRESSER A UN TECHNICIEN QUALIFIE.
"IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL"
=
"ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES."
"REFERREZ-VOUS AU MANUAL D'UTILISATION"
