Ruijie Reyee RG-EW3000GX PRO User Manual page 4

Managing the Router
Method 1: App-based Configuration
Scan the QR code to download the Reyee Router APP to manage the router. You can check
the connection status and change the Wi-Fi name and password through Reyee Router
APP.
Method 2: Web-based Configuration
Connect the PC to the SSID broadcast by the router. Access the Web management IP
address 192.168.110.1 by browser to perform configuration.
Installing a Single Router
WAN Port
Connect the
Ethernet cable.
SP Modem
1GE LAN Port
Reyee Router APP
Connect the
power supply.
Power Supply
2
System Status LED
After the system status LED
turns solid on, connect the PC to the
SSID @Ruijie-sXXXX broadcast by the
router. You will be redirected to the
configuration page automatically.
Follow the prompts to complete the
configuration.
*If the configuration page does not pop up,
access the Web management IP address
192.168.110.1 by browser to perform
configuration as prompted.
