Branson DCX V-Series Quick Start Manual

Overview

This Quick Start guide is intended to help you with the basic installation and setup of
your new DCX V Power Supply.
Consult your power supply manual for detailed information on ventilation, environmen-
tal requirements, operating the power supply, accessing the web page interface, main-
tenance, and troubleshooting.

Location

The DCX V Power Supply is available in three different sizes. Two different form factors
allow for operating the power supply on a benchtop or mounted vertically:
5.0 in (127 mm) recommended clearance for cables
c f
b
a
d
e
3.0 in (76 mm) recommended
Benchtop
fan clearance (both sides)
Dim. Inch mm
a 10.37 263
b 8.37 212.6
c 7.12 180.8
d 5.53 140.5
e 14.00 355.6
f 0.31 7.9
g 17.38 441.5
Size Small
Weight 15 lb (6.8 kg)
Use the keyhole mounting bracket to mount the unit in the needed position. Use M6
(6mm) screws to mount the unit.
© 2022 Branson Ultrasonics Corporation
DCX V-Series Power Supply - Quick Start Guide
h
i
j
Small
g
Medium
k
Large

Mounting

Plate
Back-mounted Side-mounted
Vertical
Dim. Inch
h 5.22
i 4.5
j 3.5
k 15.75
l 3.62
m 2.62
n 1.31
Medium Large
17 lb (7.7 kg) 21 lb (9.5 kg)

Connect the Power Supply

• Ensure the power source is disconnected before working on line connections
• Ensure the power switch on the back of the unit is in the OFF position before making any
electrical connections
• Always connect the power supply into a grounded power source
• Ground the power supply by securing an 8 gage grounded conductor to the ground screw
located next to the air outlet
• The power supply installation should only be performed by qualified personnel and in
accordance with local standards and regulations
l
1. Detach the connector block on the back of the power supply.
m
n 2. Use two properly sized wires (according to local standards) to connect a 24 VDC
2.5 A safety certified and agency approved power supply as shown.
3. Use three properly sized wires (No. 12 gage, 2.5 mm or according to local stan-
dards) to connect line 1, line 2, and ground to the connector block as shown.
Choose wires according to the current rating as specified on the label located on the
back of the unit. Be sure to use agency approved wiring and use sleeving or tubing
on each wire for double insulation.
4. Secure an 8 gage grounded conductor to the ground screw located next to the air
outlet.
5. Connect the converter-booster-horn stack to the power supply using the RF cable.
Ensure the end with the ferrite is connected to the power supply.
6. Ensure the power switch on the back of the unit is in the OFF position. Plug the con-
nector block back into the power supply. Tighten the two securing screws.
7. Connect the power supply to a single-phase, grounded, 3-wire, 50 or 60 Hz
mm
200-240 V power source.
132.6
RF
114.3
Connector
89
400
91.9
66.5
33.3
Ground
Ferrite
Screw
Page 1 of 2
User I/O
Ethernet
Connector
Connector
4000842, REV. 01
On/Off
Switch
L1
L2/N
GND
24VDC
24VR/0V
Use Sleeving
or Tubing
