- Page 1 Instruction Manual Free-Standing Twin Cavity Electric Cooker LFTC60W12/LFTC60A12 Image for indication only. LFTC60W_A12_IB_rollover.indd 1 05/12/2014 16:54...
- Page 2 LFTC60W_A12_IB_rollover.indd 2 05/12/2014 16:54...
-
Page 3: Table Of Contents
Contents Safety Warnings ..........................4 Unpacking ............................. 6 Product Overview ......................... 7 Front View ...................................7 Top View ..................................7 Control Panel ................................8 Before Using Your Cooker ......................8 First Time Use of the Hob ......................8 Choosing the Right Cookware ..................... 8 Using Your Hob .......................... -
Page 4: Safety Warnings
Safety Warnings IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • It is recommended that this appliance is installed by a qualified electrical engineer. The manufacturer is not responsible for any damage caused by incorrect installation. • Check whether there is any damage to the appliance after you have unpacked it. - Page 5 • Cleaning and user maintenance shall not be made by children without supervision. • Children should be supervised to ensure that they do not play with the appliance. • The appliance and its accessible parts become hot during use. Young children should be kept away.
-
Page 6: Unpacking
Thank you for purchasing your new Logik Free Standing Twin Cavity Electric Cooker. You must read this manual in order to fully understand how to operate it correctly. This cooker must be installed by a competent engineer. Please allow the installer to view the installation section of this manual. -
Page 7: Product Overview
Product Overview Front View Main Oven Door Control Panel Shelves Grill Pan Adjustable Feet Grill Door Top View Large Ceramic Heater 1700W Hot Hob Warning Light Small Ceramic Heater 1200W * All images are for indication only; please refer to your individual unit for actual item. LFTC60W_A12_IB_rollover.indd 7 05/12/2014 16:54... -
Page 8: Control Panel
Control Panel Grill Control Grill Indicator Lamp Oven Control Oven Indicator Lamp Ceramic Heater Controls Hob Indicator Lamp Before Using Your Cooker Before using your new cooker, please: • Make sure all the controls are turned off. • Read this Instruction/Installation Manual, taking special note of the 'Safety Warnings' section. •... -
Page 9: Using Your Hob
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. •... -
Page 10: First Time Use Of The Oven
First Time Use of the Oven Ensure that nothing has been left in the oven. Remove any insert cards or plastic bags. Before connecting the power, use a damp cloth to carefully wipe the inner cavity wall and housing. Clean all the detachable parts in hot, soapy water before using. -
Page 11: Using The Oven Control
Using the Oven Control Function Description Defrost Function Defrost function can be started by placing the frozen food into your oven and turning the oven control to the defrost sign or below. This function does not cook the food only the fan operates, and this helps to defrost the food in a very short time. -
Page 12: Using The Grill
Using the Grill The first time your use the grill, heat it on maximum, making sure the room is well ventilated as there may be a little smoke and odour. This is normal, and is due to the protective substance on the appliance which protects it during shipping from the factory. -
Page 13: General Advice
General Advice Before you start cleaning your cooker, please: • Read the cleaning instructions and the ‘Safety Warnings’ sections. • Turn the cooker off at the isolating switch. • Allow the cooker to completely cool down before cleaning and disconnect the appliance from the electrical supply. -
Page 14: Cleaning The Cooker Door Glass
Cleaning the Cooker Door Glass Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they may scratch the surface, which could result in the glass shattering. Take care when handling parts with glass, knocks, and chips; heavy handling and dropping could cause the glass to shatter. -
Page 15: Replacing The Oven Lamp
Lift the door slightly. The notch on the bottom of the hinge will disengage. Now pull the door forwards off the appliance, releasing both hinge sections from the slots. To replace the door, repeat the above steps in reverse order. Replacing the Oven Lamp •... -
Page 16: Hints And Tips
Hints and Tips Problem Possible Causes What To Do The cooker cannot be No power. Make sure the cooker is connected turned on. to the mains socket and the socket is switched on. Check whether there is a power outage in your home or area. -
Page 17: Product Fiche And Specifications
Product Fiche and Specifications Brand Logik Model LFTC60W12 / LFTC60A12 Product Type Electric Cooker Mass of the appliance (LFTC60W12) 47.6 Kg Mass of the appliance (LFTC60A12) 47.1 Kg Grill ( upper cavity) Heat Source Electric Volume 36 litres Main Oven ( lower cavity) Energy Efficiency Index - Fan Forced 104.3... -
Page 18: Energy Saving Tips And Energy Label
Energy Saving Tips and Energy Label Main Oven • Cook the meals togeter, if possible. • Keep the pre-heating time short. • Do not elongate cooking time. • Do not forget to turn off the oven at the end of cooking. •... -
Page 19: Installation
Installation • The cooker must be installed by a competent person, if in doubt consult a qualified technician, and in compliance with local electrical, safety and building regulation standards. • If the cooker is installed adjacent to furniture which is higher than the hob, a gap of at least 100 mm must be left between the side of the cooker and the furniture unless non-combustible materials (e.g., ceramic tiles, metal splashback, etc.) are used which then allows this distance to be reduced to 20 mm. -
Page 20: Adjusting The Feet
Adjusting the Feet Using the fitted adjustable feet is MANDATORY. For safety reasons and to ensure adequate ventilation, the cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface. The cooker stands on 4 levelling legs. As the levelling legs are adjusted at lower position, it is required to control whether the product is levelled before operating it. -
Page 21: Electrical Connection
Electrical Connection Electric cookers come without a power supply cable. The cooker is designed to operate on an electricity supply which conforms to the electrical data shown on the Rating Plate. The cooker can be connected to the mains only after you complete the connection at the junction box. - Page 22 LFTC60W_A12_IB_rollover.indd 22 05/12/2014 16:54...
- Page 23 LFTC60W_A12_IB_rollover.indd 23 05/12/2014 16:54...
- Page 24 For general information about this appliance and handy hints and tips, please visit www.knowhow.com/knowledgebank or call 0344 5611234. Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only).
