Related Manuals for Cylinda SIB8362KVEP
Summary of Contents for Cylinda SIB8362KVEP
- Page 1 DETAILED INSTRUCTIONS FOR USE OF AN INDUCTION FREE STANDING COOKER SIB8362KVEP SIB8362KVEPRF...
- Page 2 We thank you for your trust and the purchase of our appliance. This detailed instruction manual is supplied to make the use of this product easier. The instructions should allow you to learn about your new appliance as quickly as possible. Make sure you have received an undamaged appliance.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM FOR FUTURE REFERENCE. This appliance may only be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if supervision or instructions are provided to them concerning use of the appliance in a safe way and if they understand the hazards involved. - Page 4 CAUTION: possibility of tilting. WARNING: In order to prevent tipping of the appliance, stabilising means must be installed. Refer to the instructions for installation. WARNING: Before replacing the light bulb, make sure the appliance has been disconnected from the mains power, in order to prevent the hazard of an electric shock.
- Page 5 WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
- Page 6 Oven door become very hot during operation. A fourth glass is installed for extra protection, reducing the temperature of the outside surface (only with some models). Oven door hinges may be damaged when under excessive load. Do not place heavy pans on open oven door and do not lean against open oven door when cleaning the oven cavity.
- Page 7 During the automatic cleaning process, the oven gets very hot from the outside. Risk of burns! Keep children away from the oven. Pyrolytic cleaning involves very high temperatures that may cause smoke and fumes to be released from food residues. We recommend that you ensure thorough ventilation of the kitchen during the pyrolytic cleaning process.
-
Page 8: Before Connecting The Appliance
Appliance operation is safe with and without tray guides. As a result of the automatic cleaning, the oven cavity and oven equipment cleaned in such way may discolour and loose some shine, which has no influence on function. BEFORE CONNECTING THE APPLIANCE Carefully read the instructions for use before connecting the appliance. -
Page 9: Control Unit
APPLIANCE DRAWER The grid or the tray should always be inserted into the groove between the two wire profiles. Do not store combustible, explosive, volatile or temperature-sensitive items (such as paper, dish cloths, plastic bags, cleaners or detergents and spray cans) in the oven's storage drawer, as they can ignite during over operation and cause a fire. - Page 10 − This avoids any losses through the glass ceramic aggressive cleaners, such as abrasive cleaners that could cause scratches, abrasive dishwashing surface. Power consumption is considerably lower sponges, or stain removers. than in conventional cooking zones with radiation When the oven heats up for the first time, the heaters.
-
Page 11: Energy Saving Tips
− When using special cookware, observe the manufacturer's instructions. − Only use cookware with flat bottom! Concave or convex (indented or bulging) bottom may impede the operation of overheat protection mechanism and the cooking hob may become too hot. This could lead to cracks in the glass surface and melting of the pan bottom. -
Page 12: Switching On The Cooking Zones
OPERATING THE COOKING HOB SWITCHING ON THE COOKING ZONES CONTROL UNIT (depending on the model) After the hob is switched on (in the next 10 seconds), switch on the desired cooking zone (E). Use the keys (C) and (D) to select the desired setting for the activated cooking zone. - Page 13 CHILD LOCK signal will be emitted, and with a decimal point will Child lock may be activated on the hob to prevent the appear on the cooking zone display unit (G). appliance from being switched on easily and quickly Remaining time will appear on the opposite cooking and to prevent any changes during operation.
- Page 14 the hob has been switched off, there is residual heat in SETTING THE MAXIMUM TOTAL the cooking zone, which can be used to keep the food APPLIANCE POWER warm or for defrosting. When the sign "H" disappears, the cooking zone may still be hot. Be careful as there is danger of burns! MAXIMUM COOKING TIME For safety, the cooking time for each cooking zone is...
- Page 15 Activating the bridged cooking zone Switch on the cooking hob by pressing the on/off In case of an operation failure or if the fault sensor (A). / error indication does not disappear, disconnect the cooking hob from the power mains for a few Simultaneously touch the two sensors and hold minutes (undo the fuse or turn of the main them for 3 seconds (E).
-
Page 16: Electronic Timer
ELECTRONIC TIMER 1. Cooking system selector knob After a few minutes of idling, the appliance will switch 2. Child lock key to standby mode. 3. Oven lighting ON/OFF key 4. Temperature key CHANGING THE CLOCK SETTING 5. Electronic timer key (Cooking duration, End of Clock settings may be changed when no timer cooking, Alarm, Clock) function is activated. -
Page 17: Choosing The Settings
The functions depend on the model. See button System Description symbols below. Suggested temperature System Description °C Suggested Cooking systems temperature HOT AIR °C Round heater and the fan will Cooking systems operate. The fan installed in the RAPID PREHEAT back wall of the oven cavity Use this function if you wish to makes sure the hot air constantly... -
Page 18: Selecting Additional Functions
Press START to start the cooking process. The timer will wait for the time to start the cooking process and the symbol will be lit up. The oven automatically switches on (at 4 pm) and stops operating and the selected time (at 6 pm). -
Page 19: Rapid Preheating
Turn the COOKING SYSTEM SELECTOR KNOB to OVEN LIGHTING position "0". Oven lighting is switched on automatically when the door is opened or when the oven is switched on. After the end of the cooking process and after After the end of the cooking process, the light will oven been switched... - Page 20 − Set the oven to the desired temperature using the The grill shall only be used when the ʺtemperature dial knobʺ. oven door is closed. Grill heater, grid, and other oven accessories get UPPER AND BOTTOM HEATER very hot during grilling. Therefore, use oven mitts The heaters in the bottom and in the ceiling of the and meat tongs.
- Page 21 Only use the probe intended for use with HOT AIR AND BOTTOM HEATER your oven. Make sure the probe does not touch the heater during cooking. The bottom heater, the round heater, and the hot air After the cooking process, the probe will fan will operate.
-
Page 22: Cleaning The Glass Ceramic Surface
Enamel surfaces (oven, cooking hob) Use a damp sponge with detergent for cleaning. Fatty ECO COOKING stains can be removed with warm water and special Heating by means of hot air. ECO hot air uses less detergent for enamel. Never clean enamelled energy but gives the same result as the hot air setting. -
Page 23: Start/Stop Key
AUTOMATIC OVEN CLEANING – PYROLYSIS For average use of the oven, we recommend running the pyrolytic cleaning program once per month to keep the oven cavity clean and free from old grease and dirt. Remove stubborn and burnt residues with a scraper. After pyrolytic cleaning... - Page 24 COMFORT DOOR CLOSING Do not attempt to open the oven door (depending on the model) while the automatic cleaning program is Cookers are equipped with new secure door hinges in progress. The program may be COMFORT. These special hinges guarantee very terminated.
-
Page 25: Removing And Inserting The Oven Door Glass Pane
Removing and replacing the oven door (depending on the model) 1. Open the oven door (up to end position). 2. Raise up and turn the flaps. 3. Slowly close the oven door, lift it slightly and pull it out from the both hinges of the appliance. Hold the door glass pane by the lower edge;... -
Page 26: Troubleshooting Table
TROUBLESHOOTING TABLE During the warranty period, only a service center authorized by the manufacturer may carry out any repairs. Before making any repairs, make sure the appliance is disconnected from the power mains either by removing the fuse or by disconnecting the power plug from the wall outlet. - Page 27 3. Set the desired height. INSTALLATION AND 4. Screw the screws back together. CONNECTION INSTRUCTIONS APPLIANCE PLACEMENT (mm) The cooker must be installed horizontally! Follow these steps: 1. Rotate the height adjustment screws (see figure 1) to adjust the height of the cooker to the correct position.
-
Page 28: Connecting To The Power Mains
PREVENTION FROM TIPPING OVER (mm) A device disconnecting the appliance from mains, whose off contacts of all poles are in a minimum distance of 3 mm, must be built in the stable electrical energy distribution before the appliance. Solely an authorised, skilled person may install the range. -
Page 29: Clamp Protection
CLAMP PROTECTION DISPOSAL The clamps should be protected by a clamp cover, see additional equipment. Electric shock danger. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging... -
Page 30: Cooking Test
COOKING TEST Tested in compliance with the EN 60350-1 standard. BAKING Dish Equipment Guide (from System Temperature Cooking time (°C) the bottom) (minutes) Cookies 140-150* 25-40 single level Cookies 140-150* 25-40 single level shallow enamel-coated baking sheet Cookies 2, 3 140-150* 30-45 two levels... - Page 32 CYLINDA SIB8362KVEP, SIB8362KVEPRF 2021 06 06 IFU ES6IPY TC IL+ MP C CYL6 EN SAP 862121...
