Description:

The Ocean Matrix OMX-01UBUB0001 is a USB 2.0 extender that transmits signals up to 150m
over CAT5e/6/6A. The OMX-01UBUB0001 features 4 USB 2.0 outputs that support a wide
range of devices including printers, cameras, keyboards, mice, and more. The transmitter is
powered by the source device, allowing for more streamlined setups.

Features:

Supports USB 2.0 high-speed, compatible with USB 1.1 full speed, USB1.0 low-speed
Supports 4 USB 2.0 inputs at the receiver "Hub" and 1 USB 2.0 output at the transmitter "Host"
Compatible with CAT5e/6/7 network cables- Cat5e transmission distance can reach 100M, and
Cat6/7 transmission distance can reach 150M
Supports USB hub connection
The Transmitter is powered by the source device- no additional power supply is required.
*Note- some high-powered USB devices may require their own power supply.*
Lightning protection, surge protection, and ESD protection

Specifications:

Compatibility: USB 2.0, USB 1.1, USB 1.0
Supports CAT5e / CAT6 / CAT6A / CAT7 / IEEE-568B Standard
Transmission Distance: Up to 150m via CAT6/6A/7; Up to 100m via CAT5e
Power Supply: TX: Powered by Source Device | RX: DC5V/1A
Power Consumption: TX: ≤ 0.69W | RX: ≤ 1.23W
Operating Temperature: -4 – 140°F (-20 – 60°C)
Storage Temperature: -22 – 158°F (-30 – 70°C)
Dimensions (LxWxH): Both TX & RX: 3.035 x 2.37 x 0.81
Weight: TX: 0.275 lbs (125g) RX: 0.288 lbs (130g)
Item Includes:
OMX-01UBUB0001 USB 2.0 Extender Set (1 x
Transmitter / 1 x Receiver)
1 x DC5V/1A
1 x USB Cable
