Operating instruction
DF 250 145
GI 235 545
Dish washer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF 250-145 and is the answer not in the manual?

Questions and answers

Related Manuals for Gaggenau DF 250-145

Summary of Contents for Gaggenau DF 250-145

  • Page 1 Operating instruction DF 250 145 GI 235 545 Dish washer...

  • Page 3: Table Of Contents

    Index Safety instructions ... . . auto 3in1 ..... Getting to know your appliance Programme overview .

  • Page 4: Safety Instructions

    Safety instructions Built-under and built-in appliances should always be installed under a Delivery continuous work surface which is attached to the adjacent cupboards, in Immediately check the packaging and order to ensure that the appliance is dishwasher for any damage which may entirely stable.
  • Page 5 In daily use If a fault occurs Repairs or other work on the dishwasher should only be carried out Warning by a qualified specialist. Knives and other utensils with sharp points The dishwasher must be disconnected must be placed in the baskets either flat or from the electricity supply before any with the points downwards.

  • Page 6: Getting To Know Your Appliance

    Getting to know your Appliance interior appliance Upper basket with additional cup rack Diagrams of the control panel and the Additional cutlery basket for the interior of the appliance can be found top basket* in the envelope at the front. Top spray arm Individual positions are referred to in the text.

  • Page 7: Water Softener

    Water softener Press and hold the B programme button, and set the main switch In order to rinse dishes and glasses ON, before releasing the programme satisfactorily, the dishwasher requires soft button again. water, i.e. containing little or no lime, The indicator lamp for the B button otherwise water stains will be left behind flashes, as does the figure...

  • Page 8: Filling The Special Salt Container

    Filling the special salt container How the salt works While washing is taking place, salt is automatically rinsed out of the salt container into the water softener where it dissolves the lime in the water. The dissolved lime is pumped out of the dishwasher.

  • Page 9: Adding Rinse Aid

    Adding rinse aid Adjusting the amount of rinse-aid The rinse aid is required for stain-free The amount of rinse-aid added to the utensils and clear glasses. water can be varied by adjusting the Use only rinse aid for domestic stepless control. The rinse-aid control has dishwashers.

  • Page 10: Not Suitable For The Dishwasher

    Not suitable for Damage to glassware and other dishes the dishwasher Possible causes: The following should not be type of glass or manufacturing process cleaned in the dishwasher: chemical composition of detergent Wooden cutlery and utensils – these water temperature and duration of will leach out and become unsightly;...

  • Page 11: Arranging Crockery, Glasses, Etc. In The Dishwasher

    Arranging crockery, glasses, Pots and pans etc. in the dishwasher Lower basket Loading the dishwasher Scrape off any large amounts of left-over food. It is not necessary to rinse the dishes under running water. Place objects in the dishwasher in such a way that D items such as cups, glasses, pots/pans, etc.
  • Page 12 Shelf * Adjusting position of basket * * not on all models * not on all models Lean tall glasses and those with long stems against the shelf – not against other items to be washed. Place glasses, cups and small bowls on the additional cup rack.
  • Page 13 Top basket with side levers Baking sheet spray head * (Rackmatic) * some models You can clean large baking sheets or Pull out the top basket. grilles with the baking sheet spray head. To do this, remove the top basket and insert the spray head as illustrated in the diagram.

  • Page 14: Detergents

    Detergents Detergent compartment with measuring marks Information about detergents The side of the detergent compartment is You can use any brand of liquid or powder marked with lines to help you determine detergent, as well as tablets, that have how much powder to add. been specifically designed for use in The capacity of the detergent container is domestic dishwashers.

  • Page 15: Auto 3In1

    auto 3in1 Reduce costs! The use of so-called combined detergent If your dishes are only products may make the use of rinse aid moderately dirty, you may be and/or salt unnecessary. able to use less detergent than There are currently several types of recommended.
  • Page 16 Switching the salt refill Note indicator / water softening Optimum rinsing and drying results can be system off and on obtained by using standard detergents in Hold down the programme button B conjunction with separate application of and switch on the main switch salt and rinse aid.

  • Page 17: Programme Overview

    Programme overview This overview lists the max. possible number of programmes. The programmes supplied with your appliance are indicated on the fascia. Type of crockery e.g.china, pots/pans, Nondelicate Mixed Delicate Mixed cutlery, glasses, etc. Type of food Rinse off if Soups, casseroles, Soups, potatoes, Coffee, cakes,...

  • Page 18: Washing Dishes

    Washing dishes Switching the dishwasher ON Turn on the tap. Set main switch to ON. Reduce costs! Indicators light up according to the last programme that was selected. If only a small number of This same programme will run again if dishes have been loaded into no other programme button the dishwasher, selecting a...
  • Page 19 Time delay * Switching the dishwasher OFF Several minutes after the programme has on applicable models ended: You can delay the start of the programme Open the door when the programme in 1-hour steps up to 19 hours. has ended. Switch on the appliance.

  • Page 20: Maintenance And Care

    Changing the programme Maintenance and care It is possible to change the programme A regular inspection and maintenance within 2 minutes after you have switched of your machine will help to prevent faults. the dishwasher on. This saves time and prevents problems. Should it be necessary to change the Therefore you should occasionally have programme after this period, the...
  • Page 21 Rinse-aid Spray arms As soon as the rinse-aid refill indicator Lime and remnants of food in the washing water can block the nozzles in the spray lights up on the control panel arms and the arm refill with rinse aid. mountings .

  • Page 22: Fault Finding

    Pump * Fault finding on applicable models Resolving minor problems Larger remnants of food that have not yourself been trapped by the filters and have been Experience has shown that you can left in the water can cause a blockage in resolve most problems that arise during the pump.
  • Page 23 ... when the appliance “Check water supply” display lights up. is switched on Tap turned off. The appliance does not start. Water supply interrupted. The mains fuse has tripped. Filter in the water supply blocked. The appliance plug has not been Supply hose kinked.
  • Page 24 Knocking sound can be heard Although water is quite hard, no while washing is taking place salt has been put in appliance. A spray arm is knocking against Water softener was set too low. the dishes inside the appliance. Lid on salt container is not screwed tight.

  • Page 25: Customer Service

    Customer Service Information Please call your local service agent, if you Notes on comparison tests are not able to resolve any problem You will find details of the conditions for yourself. The name of your nearest service the comparison tests on the additional agent is shown in the Customer Service ”Notes on comparison tests”...

  • Page 26: Installation

    Installation Fresh water connection Using the enclosed parts, connect the The dishwasher must be connected by fresh water connection to the tap a qualified technician to ensure correct according to the installation instructions. operation. The specifications for supply, Ensure that the fresh water connection is drainage and connected load must fulfil not kinked, crushed or twisted.

  • Page 27: Waste Disposal

    Transporting the dishwasher Waste disposal Drain water from the dishwasher. Secure Disposal all loose parts. The appliance should only be transported in an upright position. Old appliances are not worthless rubbish. Valuable raw materials can be reclaimed If the appliance is not kept upright by recycling old appliances.
  • Page 28 Disposal of the packaging Warning Please dispose of the packaging Children could become locked in the material in an environmentally appliance (risk of suffocation) or find friendly manner. themselves in other dangerous situations. Keep children away from shipping carton and packaging components. Therefore: Pull out the mains plug, sever Danger of suffocation from folding and dispose of the power cord.
  • Page 29 en Subjekt to modification...
  • Page 31 A call set–up free of up to 6 pence may apply. 01450 2655 Pease find the contact data of all countries in the enclosed customer service list. Internet: www.gaggenau.com GAGGENAU HAUSGERÄTE GMBH CARL WERY STR. 34 · D 81739 MÜNCHEN 9000 111 468 en (8507-2) 450I...
