Larson Electronics GAU-ID-36-1L-UVC-SPF Instruction Manual

30W Fluorescent UV Strip Fixture -(1) 36" T8 Style Shatterproof
Fluorescent UV-C Tubes - G13 Bi-Pin - 22G Steel - Baked White
Thank you for your purchase of the Larson Electronics GAU-ID-36-1L-UVC-SPF.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. THE GAU-
ID-36-1L-UVC-SPF MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND ALL APPLICABLE LOCAL
CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS PRODUCT. IF
YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET, CONSULT AN
ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –
RISK OF PERSONAL INJURY –
RISK OF BURN –
ALLOW FIXTURE TO COOL BEFORE SERVICING.
WARNING: ULTRAVIOLET LIGHT IS HARMFUL TO EYES AND SKIN. DO NOT STARE DIRECTLY INTO THE
ULTRAVIOLET BEAM WITHOUT WEARING PROTECTIVE GEAR TO PROTECT EYES FROM LONG TERM DAMAGE.
UNPLUG LAMP BEFORE SERVICING.
Note: Do not touch bulb with bare hands. The oils in your skin will damage the lamp. Fingerprints will result in reduced
performance and significantly reduce the lifespan of the lamp unless they are removed with alcohol.
The Larson Electronics GAU-ID-36-1L-UVC-SPF Fluorescent UV-C Strip Fixture is an excellent choice for germicidal and sanitation use.
This 30-watt unit is equipped with one, 30-watt shatterproof fluorescent UV-C tube. Constructed of steel (housing) and polycarbonate
(lens), the fluorescent strip fixture is compatible with universal 120-277 V AC voltages.

Installation Guide

1.
Remove lamp by rotating 1/4 turn to free from receptacles, and
remove fixture cover by lifting up on the exposed edges of part.
Start in the middle and work outward. Remove parts pack from
inside fixture. Be sure power supply is off at the breaker!
2.
Determine appropriate knockout for removal depending on
incoming power supply wiring. Knockouts are on each end and
on the back of the fixture. Remove knockout by placing a
flathead screwdriver at the edge of the circle opposite the
retaining tabs, and strike gently with a hammer. Flex knockout
back and forth until removed.
3.
If using a strain relief bushing, install the bushing into the hole. Insert power supply wiring through the open hole or
strain relief bushing.
4.
Position the fixture against the desired mounting surface and mark the screw hole locations with a pencil. Be sure to
make these marks in the narrow section of the key holes. Make two small pilot holes in these locations using a 1/16''
drill bit. If you do not hit a stud, use toggle bolts or other suitable hardware capable of structurally supporting the load of
the fixture. Be sure the surface is also capable of supporting the weight of the fixture. If hole is drilled into wood, #10
wood screws should be used.
5.
Partially install screws, about half way in. Position the fixture housing against the mounting surface with screw heads
through the keyholes. Slide the fixture until the screw heads are in the narrow section of the keyhole, and finishing
tightening the screws to secure the fixture in place.
6.
Use wire nuts from parts pack and complete connections with the supply wiring - white to white, black to black, green to
green or ground wire. Be sure supply voltage matches fixture rating. Bundle wiring inside fixture housing and replace
the cover onto the fixture. Reinstall lamp(s) by sliding pins into open slots in receptacles and rotate 1/4 turn to secure.
Larson Electronics, LLC
Enamel Finish
Instruction Manual
DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
Phone: (800) 369-6671 Fax: (903) 498-3364
GAU-ID-36-1L-UVC-SPF
www.larsonelectronics.com
1 of 2
