TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS

Screw, side stand switch
Remaining frame bolts
Screw, brake fluid reservoir of rear
brake
Screw, brake line holder
Screw, chain guard
Screw, chain sliding guard
Screw, fuel level indicator
Screw, fuel tank guard
Screw, painted trim parts
Screw, steering damper fixing bracket
Bolt, foot brake lever stub
Remaining chassis nuts
Remaining chassis screws
Screw for wheel speed sensor bracket
Screw, exhaust clamp
Screw, exhaust heat shield
Screw, foot brake cylinder
Screw, foot brake lever
Screw, fuel pump
Screw, mirror bracket
Screw, shift lever stub
Screw, shift rod
Screw, shift shaft deflector on chain
securing guide
Screw, shift shaft deflector on shift
shaft
Fork end pinch bolts
Nut, forked bracket on foot brake lever
Remaining chassis nuts
Remaining chassis screws
Screw for lifting gear support, rear
Screw of rear brake caliper
Screw, bottom triple clamp
Screw, clamp, eccentric shaft of
deflector
Screw, front brake disc
Screw, front footrest bracket
Screw, handlebar stub
Screw, ignition lock
Screw, rear brake disc
Screw, rear footrest bracket
Screw, rear footrest bracket (footrest
bracket not mounted)
Screw, shift lever
Screw, side stand bracket
Screw, spring holder on side stand
bracket
Screw, steering damper clamp on con-
sole
Screw, steering damper fixing bracket
on triple clamp
Screw, steering stem
Screw, subframe
M4
M5
M5
M5
M5
M5
M5
M5x12
M5
M5
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8
M8x25
M8
M8
M8
M8
M8
M8
M8
2 Nm (1.5 lbf ft)
5 Nm (3.7 lbf ft)
5 Nm (3.7 lbf ft)
5 Nm (3.7 lbf ft)
5 Nm (3.7 lbf ft)
5 Nm (3.7 lbf ft)
3 Nm (2.2 lbf ft)
3 Nm (2.2 lbf ft)
3.5 Nm (2.58 lbf ft)
5 Nm (3.7 lbf ft)
10 Nm (7.4 lbf ft)
10 Nm (7.4 lbf ft)
10 Nm (7.4 lbf ft)
3 Nm (2.2 lbf ft)
8 Nm (5.9 lbf ft)
15 Nm (11.1 lbf ft)
10 Nm (7.4 lbf ft)
15 Nm (11.1 lbf ft)
6 Nm (4.4 lbf ft)
6 Nm (4.4 lbf ft)
10 Nm (7.4 lbf ft)
12 Nm (8.9 lbf ft)
7 Nm (5.2 lbf ft)
18 Nm (13.3 lbf ft)
15 Nm (11.1 lbf ft)
30 Nm (22.1 lbf ft)
25 Nm (18.4 lbf ft)
25 Nm (18.4 lbf ft)
18 Nm (13.3 lbf ft)
22 Nm (16.2 lbf ft)
15 Nm (11.1 lbf ft)
18 Nm (13.3 lbf ft)
30 Nm (22.1 lbf ft)
25 Nm (18.4 lbf ft)
20 Nm (14.8 lbf ft)
16 Nm (11.8 lbf ft)
30 Nm (22.1 lbf ft)
25 Nm (18.4 lbf ft)
15 Nm (11.1 lbf ft)
25 Nm (18.4 lbf ft)
25 Nm (18.4 lbf ft)
15 Nm (11.1 lbf ft)
20 Nm (14.8 lbf ft)
10 Nm (7.4 lbf ft)
20 Nm (14.8 lbf ft)
20 Nm (14.8 lbf ft)
Loctite ® 243™
–
Loctite ® 243™
–
–
–
–
–
–
Loctite ® 243™
Loctite ® 243™
–
–
Loctite ® 243™
–
–
Loctite ® 243™
Loctite ® 243™
–
–
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
Loctite 243™
®
–
Loctite ® 243™
–
–
–
Loctite ® 243™
–
–
Loctite ® 243™
Loctite ® 243™
–
Loctite ® 243™
Loctite ® 243™
–
–
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
Loctite ® 243™
–
Loctite ® 243™
