Page 1
OWNER’S MANUAL Robot Cleaner Before using, please carefully read the Safety Precautions pages to allow for safe operation of the product. After reading this manual, please keep it in an easily accessible location. VR648***** www.lg.com MFL67680054...
Page 2
FEATURES Corner Master By having adopted a brand new concept design that is appropriate for walls, the Robot Cleaner's cleaning performance is incredibly efficient. Learning Mode The Robot Cleaner is capable of memorizing the cleaning environment via its Smart Operation feature for smarter cleaning. Turbo Mode In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes at a greater speed giving cleaner results.
CONTENTS BEFORE USING HANDLING METHOD AFTER USE Safety precautions Cleaning the dust bin Included with product Cleaning the dust bin filter Parts description Cleaning the brush 10~11 Button functions Cleaning the sensor/charging terminal Display status information Cleaning the side brush Before you start Cleaning the ultra microfiber mop (option) Overview...
3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard 4. This appliance can be used by children aged from 8 years and above and persons with reduced physical,...
Page 5
Failure to follow this warning can cause electric shock, fire or product failure. If the power cord is broken, do not plug it in. Take the product to an LG Electronics Authorised service repairer. Do not place the home station...
Page 6
SAFETY PRECAUTIONS WARNING Do not spray or use Turn the power supply off inflammable materials, immediately if any abnormal sound, odor, or smoke is surfactants, or drinking water generated from the Robot in the vicinity of the Robot Cleaner by removing it from the Cleaner.
Page 7
Doing so can cause product failure. Do not put any water failure. or detergent on the Robot Cleaner. If liquids get inside of the Robot Cleaner, turn off the power supply and contact an LG Electronics sales agent or customer care center.
Page 8
SAFETY PRECAUTIONS CAUTION If the floor is wet or has wet When the robot cleaner is spots, wipe them up before operating, it may hit the chair leg, desk leg, table leg or other using the Robot Cleaner. Do narrow pieces of furniture. not use the Robot Cleaner on a wet surface.
Before using, please carefully read the Safety Precautions pages to allow for safe operation of the product. After reading this manual, please keep it in an easily accessible location. www.lg.com Cleaning Tool Dust bin filter (spare) Quick guide Operation manual...
Page 10
PARTS DESCRIPTION - ROBOT CLEANER Plan view Upper camera sensor Dust bin cover Display & function buttons Dust bin compartment release button Tag On Front view Ultrasonic sensors Obstacle detecting sensor window Detecting sensors of home station & Receiving sensors of remote controller Front Camera Rear view...
Page 11
PART DESCRIPTION – HOME STATION / DUST BIN Home station Remote controller holder Charging terminal Power switch Power cord fixing hook Dust bin Dust bin handle Cleaning brush Dust bin cover Suction port flap Sponge filter Dust bin lid opening button EPA Filter Filter cover s Figures can be different from actual objects.
BUTTON FUNCTIONS – ROBOT CLEANER • If the button is pressed, ‘Turbo Mode’ will be set with a voice confirmation. TURBO • If the button is pressed whilst in ‘Turbo Mode’ , it will be canceled. • Used to turn the power on from Standby, start or stop cleaning. •...
Page 13
BUTTON FUNCTIONS – REMOTE CONTROLLER Home Used to recharge the Robot Start Cleaner by making it return to the Pressing this button will Home Station. (p18) start the cleaning. (p17) Mode Turbo Changes the cleaning Used to activate or deactivate mode.
DISPLAY STATUS INFORMATION Mute icon This icon indicates Lock icon whether the Mute is Indicates ON or OFF. whether 'Lock‘ is Battery icon activated or not. This icon indicates Remote the residual battery connection Icon level, it flashes if Is Displayed when the battery needs the smartphone recharging.
BEFORE YOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor.
OVERVIEW Install the home station. (p15) Insert the power cord plug into an outlet and locate the station against a wall. If power is not supplied to the home station, the Robot Cleaner will not charge. Turn on the power supply of the Robot Cleaner.
Do not operate the Robot Cleaner if the Home Station has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid electrical hazards, the cord must be replaced by LG Electronics, Inc. or a qualified service person.
HOW TO TURN THE ROBOT CLEANER POWER SUPPLY ON & OFF Turning on the main power supply Make sure the Power Switch is on at the rear-left of the Robot Cleaner. If the power is OFF, turn the switch ON. ※...
HOW TO START AND STOP CLEANING Using the buttons on the Robot Cleaner After the Robot Cleaner main power switch is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning.
HOW TO CHARGE THE BATTERY Automatic charging The Robot Cleaner returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ If 10 minutes elapse without the Robot Cleaner moving or the battery is too low, the power will be automatically turned OFF.
Page 21
HOW TO CHARGE THE BATTERY Remaining Battery Charge Indicator The Battery level is indicated on the Status Display, as follows. • If recharging is in progress, the Battery Level indicator flashes showing the battery charge status level. • If recharging is complete, only the 'Battery' and 'Clean Mode' icons are displayed to save the energy. •...
CLEANING MODES Zigzag Cleaning In 'Zigzag' mode, Robot Cleaner repeats a zigzag operation to clean each and every spot in the cleaning area. If you need to quickly clean an area choose 'Zigzag' mode. Press ‘Mode’ button on Remote Controller or main unit to select 'Zigzag' mode and press 'Start' button.
Page 23
CLEANING MODES My Space Cleaning Pressing 'My Space' on the Remote Controller will set the My Space cleaning mode with a voice message. For cleaning of particular spaces, select this mode. The 1st stage: Use the Remote Controller to manually set the parameters of each cleaning block.
AUXILIARY CLEANING MODES Manual Cleaning By pressing a direction key on the Remote Controller, you can move the Robot Cleaner manually. Robot Cleaner will clean the area, by pressing the forward/backward/left/right buttons accordingly on the keypad of the remote control. While in 'Manual' mode, the robot cleaner will run into obstacles placed behind it if the backward key on the remote is pressed or held down.
Page 25
AUXILIARY CLEANING MODES Turbo Mode Pressing the 'Turbo' button on the Remote Controller or main unit will activate 'Turbo' mode, with a voice message. While in 'Turbo' mode, pressing the same button will cancel 'Turbo' mode, with a voice message. In 'Turbo' mode, Robot Cleaner runs more intensely for a powerful clean.
TIME SETTING You can set or change the current time on the Robot Cleaner. Pressing ‘Clock' button on the Remote Controller, when the Robot Cleaner is in standby mode, will start the clock setting mode. Set the hour by using 'uv' buttons Flickering on Remote Controller.
SCHEDULED CLEANING You can schedule cleaning so that the Robot Cleaner starts cleaning at a scheduled time. Pressing 'Schedule' button on Remote Controller, only when the Robot Cleaner is recharging, will start the scheduled cleaning setting. Setting/Cancelling the schedule cleaning is only possible when the unit is recharging on the home station Select ‘Once reservation’...
MOP CLEANING (OPTION) By attaching the ultra microfiber mop, you can effectively use the Robot Cleaner to remove dust on hard floor surfaces. When the mop plate is attached, the Robot Cleaner will not climb on to carpets or over thresholds, in order to prevent transferring dirt Caution from the mop.
LOCATION SEARCH FUNCTION The Robot Cleaner remembers its location while cleaning. If the user moves the Robot Cleaner while it is operating, it will search for the location it was moved from by using its navigational location search function before continuing to clean.
SMART DIAGNOSIS Robot Cleaner uses this Smart Diagnosis feature to run a self-diagnosis. If any irregularity is found from the diagnosis, please contact the local LG Electronics service center. ※ During Smart Diagnosis, the Robot Cleaner will move about within a 50 cm radius. So, make sure no objects are in the way within a 1 m radius around the Home Station, before starting Smart Diagnosis.
Page 31
Smart diagnosis mode will be turned off. Please try smart diagnosis again after turning the main power switch off and on from the back of Robot Cleaner. If the problem continues, please contact LG Electronics customer care. Smart Diagnosis mode cannot be operated with mop plate Run Smart Diagnosis again after removing the Mop being attached.
SMART APPLICATION FUNCTION You can control the Robot Cleaner from your smartphone. The "LG Roboking" application provides the following functions: • HomeView, HomeGuard, Cleaning Diary, Schedule Cleaning, Smart Diagnosis AP with Internet access Smartphone (Android) Robot Cleaner with network access...
Page 33
SMART APPLICATION FUNCTION Signing up for membership You need to subscribe your personal login ID on the server to control the Robot Cleaner from your smartphone. 1. The [Startup Screen] opens when you run the "Smart ThinQ" application. Click "Sign in". 2.
Page 34
SMART APPLICATION FUNCTION How to register the product You will need to register the product on the application to control the Robot Cleaner from your smartphone. Add your Robot Cleaner to the app with the Tag On feature to use the Smart function. 1.
Page 35
SMART APPLICATION FUNCTION Tag On / Register product The Robot Cleaner can easily be added to the app via the Tag On function. 1. Check the locations of Tag On of Robot Cleaner and NFC of your smartphone. [Location of Tag On of Robot Cleaner] [Product category] [Register product Fig.1] [Register product Fig.2]...
Page 36
SMART APPLICATION FUNCTION Product network / Register product 1. After the connection has been successful in the product category type, the [Server connection] screen will open. 2. Select the AP on the network list; automatic connection mode will be enabled to connect to the server.
Page 37
SMART APPLICATION FUNCTION Startup screen of application The following screen will open when you connect to the Robot Cleaner for the first time from the "Smart ThinQ" application: Displays the product's You can check for any nickname. alert history. Menu The home icon selects Homeguard, Schedule the product list page.
Page 38
SMART APPLICATION FUNCTION Startup screen of application Menu Homeguard, Schedule Cleaning, Cleaning Diagry, Smart Diagnosis, Setting. HomeView you can use the remote- control function, and monitor the surrounding environment around the robot cleaner through the front camera. Mode Menu Cleaning mode, Repeat mode, Turbo mode.
Page 39
SMART APPLICATION FUNCTION HomeView (interface configuration) Open HomeView; the following control screen icons will appear: HomeView main menu Each button provides the corresponding function. Status icons Wi-Fi, battery, Reserve Cleaning, cleaning mode, Turbo mode, repeat mode, lighting mode, and cleaning time are displayed here.
Page 40
SMART APPLICATION FUNCTION HomeView (Cleaning) You can change to the cleaning mode during HomeView and have the Robot Cleaner start cleaning by clicking “Start cleaning." [Waiting to clean] Click “Start cleaning” to engage the cleaning mode. You can select another cleaning mode by clicking the “Mode setting”...
Page 41
SMART APPLICATION FUNCTION HomeView (Redock for charging) Click “Start Charging” when the Robot Cleaner is not charging to have the Robot Cleaner start searching for the Home station. Click "Stop" to have the Robot Cleaner stop searching. [Moving to Home station] [Charging] HomeView (Manual control) Press the "Manual Control"...
Page 42
SMART APPLICATION FUNCTION Menu - HomeGuard (Main screen) HomeGuard lets you monitor the house through the Robot Cleaner's camera at its designated location while you are away from home. The Robot Cleaner will take pictures of any activity it detects and sends them to you as Alerts.
Page 43
SMART APPLICATION FUNCTION Menu - HomeGuard (Location setting) To start HomeGuard, first, you have to set the location where the Robot Cleaner will remain during the HomeGuard mode. Select the location on the virtual map. 1. Click the target location on the map or drag the Robot Cleaner to the desired location within the designated area.
Page 44
SMART APPLICATION FUNCTION Menu - HomeGuard (Location setting) 3. Check if the location is satisfactory from the video feed and click "Save" to complete location setup. [Saving Location setting] • The Robot Cleaner searches for the saved location with the Home station as the starting point, so you will have to set up the location again if the station has been moved.
Page 45
SMART APPLICATION FUNCTION Menu - HomeGuard (Alert) Upon detecting any movement while in HomeGuard mode, the Robot Cleaner takes pictures and sends an alert to your smartphone. Press "Confirm" on the alert pop-up to view the picture or use the "Call"...
Page 46
SMART APPLICATION FUNCTION Menu – Schedule Cleaning You can schedule the time you want the Robot Cleaner to start cleaning. To set up Schedule cleaning, toggle across the Schedule cleaning key to turn it on or off in the Schedule cleaning menu. After enabling Schedule cleaning, set up the time and repetition, and then click "Save"...
Page 47
SMART APPLICATION FUNCTION Menu – Cleaning Diary You can view the diary to find out when the Robot Cleaner did the cleaning. Cleaning Diary records information such as date, mode, and the start and completion times of each cleaning. Click Play button on the right of the completed cleaning list; an active cleaning map of that particular cleaning event will appear.
Page 48
Be sure to resolve any issue identified in the diagnosis by taking a corresponding measure. If the symptom persists, contact the customer service center of LG Electronics. • Smart Diagnosis on the application provides the same function as that of the remote control.
Page 49
SMART APPLICATION FUNCTION Menu – Setting You can check or change the current information set up on Robot Cleaner. Click Voice gender to change the voice of the Robot Cleaner to male or female. Click Product nickname to change the current nickname of the Robot Cleaner; a pop-up where you can enter a new nickname opens (up to 10 characters allowed including English, Korean and numeric).
Page 50
SMART APPLICATION FUNCTION Misc. 1 - Software update The network-enabled model of the Robot Cleaner can update the software automatically via the application. 1. Make sure that the "Smart ThinQ" application is up to date on the Play Store.(Unless you update the app to the latest version, software update will not be available.) 2.
Page 51
SMART APPLICATION FUNCTION Misc. 2 - Mode You can order to robot cleaner simply without connection with robot cleaner through Mode function. Mode function has total 4 functions. If you push ‘ A pplied’ button, Robot cleaner will act according to Mode like below.
3. Pressing "Start/Stop" again will turn Robot Cleaner on with a melody. ※ Any dispute between seller and buyer is an issue between the two parties. LG Electronics provides a product initialization function for smooth transaction. • Initialization returns the following information as factory default setting.
CLEANING THE DUST BIN If the dust bin is full, suction power can be reduced. Clean the dust bin before or after each cleaning session. Clean the dust bin using the following sequence: 1. Open the dust bin compartment cover by pressing the PUSH button on the Robot Cleaner.
CLEANING THE DUST BIN FILTER The Dust Bin Filter consists of a EPA and Sponge Filter. Clean both the EPA and Sponge filters as per the following sequence. 1. Pull the hook on the left of the EPA Filter module on the rear side of Dust Bin to separate the EPA Filter and the sponge.
CLEANING THE BRUSH The rotating Brush, located on the bottom of Robot Cleaner, helps collect the dust. Clean the Brush as per the following sequence. ※ Before turning over the main unit, lay a soft cloth on the floor and remove the Dust Bin. Otherwise, the main unit can get scratched and dust will fall from the Dust Bin.
CLEANING THE SENSORS/CHARGING TERMINALS There are sensors on the Robot Cleaner that detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the Robot Cleaner, regularly clean the sensors and charging terminals as follows: 1.
CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is the risk of damage to the brushes. If the floor is rough or frequently cleaned, the side brushes may bend or become deformed.
※ If the Mop is used in a damp or wet state, it will cause the Robot Cleaner to malfunction. • To avoid product malfunction, only use the ultra microfiber mop provided with the Robot Cleaner. • Additional microfiber mops can be purchased by visiting a nearby LG Electronics service center.
TROUBLESHOOTING Upon a voice message, "The wheels are not touching the floor. Please move Robot Cleaner onto flat floor." A warning message will be given if a wheel does not contact the floor surface for any reason. • Is a wheel trapped in the front door, balcony, stairway, etc? s Move the Robot Cleaner on to the flat floor.
Page 60
TROUBLESHOOTING Upon a voice message, "Please check if the dust bin is installed with the filter." A warning message will be given if there is no Dust Bin or Filter housing fitted. • Is the Dust Bin fitted to the Robot Cleaner? s Open the Dust Bin compartment cover and check to ensure the Dust Bin is in place.
Page 61
TROUBLESHOOTING Upon a voice message, "Please remove foreign material from the brushes on the bottom." A warning message will be given if foreign materials restrict the Brush's rotation. Turn off the main power switch on the rear of the Robot Cleaner. Lay a soft cloth on the floor and put the Robot Cleaner upside down on it.
Ƭ Check whether the main power switch is turned on. (Page 16) ※ To improve the quality of the application in use, modifications may be proceeded without notice to customers. The maunals for the modified applications can be downloaded at LGE website. (http://www.lg.com)
Rating DC 14.4 V / 2330 mAh LG Electronics Inc. hereby declares that this Automatical Battery Operated Vacuum Cleaner with Docking Station is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm between...
REFERENCE ITEMS Open source software notice To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.
Page 65
Disposal of waste batteries/accumulators 1. When this crossed-out wheeled bin symbol is attached to batteries/accumulators of Your product it means they are covered by European Directive 2006/66/CE. 2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more that 0.0005% of mercury, 0.002% of cadmium or 0.004% of lead.
Page 67
מדריך למשתמש שואב רובוטי לפני השימוש, קרא בתשומת לב את העמודים העוסקים .באמצעי בטיחות, להפעלה בטוחה של המוצר .לאחר קריאת מדריך ההפעלה, שמור אותו במיקום נגיש VR648***** www.lg.com MFL67680054...
Page 68
תכונות Corner Master הודות לתכנון קונספט חדש לחלוטין המתאים לקירות, ביצועי הניקוי של . הינם יעילים באופן יוצא מן הכללRobot Cleaner מצב למידה מסוגל לזכור את סביבת הניקוי באמצעות התכונהRobot Cleaner ., לניקוי חכם יותרSmart Operation מצב טורבו , פועל בעצמה גבוהה יותרRobot Cleaner ,”במצב “טורבו .ומשיג...
Page 69
תוכן העניינים אופן הטיפול לאחר השימוש לפני השימוש אמצעי בטיחות ניקוי מכל האבק כלול במוצר ניקוי מסנן מכל האבק תיאור חלקים ניקוי המברשת פונקציות לחצנים 10~11 ניקוי חיישן/מסוף הטעינה מידע מצב תצוגה ניקוי המברשת הצדית לפני שתתחיל (ניקוי במטלית מיקרופייבר )אופציונלי מבט...
Page 70
אמצעי בטיחות אמצעי הבטיחות המתוארים להלן נועדו לאפשר למשתמש להשתמש במוצר באופן בטוח ונכון, כדי למנוע סיכונים .בלתי-צפויים לפציעה או נזק אמצעי בטיחות בסיסיים .לאחר קריאת מדריך זה, שמור אותו במיקום נגיש זהו סמל התראת הבטיחות. סמל זה מתריע בפני סכנות אפשריות העלולות להוביל לנזק לרכוש .ו/או...
Page 71
ברצונך להחליף את הסוללה או את , קח את המכשירRobot Cleaner פעולה זו עלולה לגרום לשריפה או אל מוקד השירות או הספק המורשה .לתקלה במוצר לקבלתLG Electronics הקרוב של .סיוע אי ציות לאזהרה זו עלול לגרום .לשריפה או לתקלה במוצר Robot Cleaner-אל תשתמש ב...
Page 72
אמצעי בטיחות אזהרה Robot Cleaner אל תפעיל את אין להכניס שום איבר, כגון יד או .בחדר שבו נמצא ילד ישן רגל, אל מתחת למברשת או Robot Cleaner לגלגלים של פעולה זו עלולה לגרום לפציעה או .במהלך השימוש .לנזק למוצר פעולה זו עלולה לגרום לפציעה או .לנזק...
Page 73
.פעולה זו עלולה לגרום לתקלה במוצר .פעולה זו עלולה לגרום לתקלה במוצר מיםRobot Cleaner אין לשפוך על או חומרי ניקוי כלשהם. במקרה של ,Robot Cleaner-חדירת נוזלים ל כבה את אספקת המתח ופנה לנציג מכירות או למוקד שירות לקוחות של .LG Electronics...
Page 75
כלול במוצר Robot Cleaner תחנת בית שלט רחוק .◀ האיורים עשויים להיות שונים מהפריטים בפועל www.lg.com כלי ניקוי (מסנן מכל אבק )חלופי מדריך מהיר מדריך הפעלה ()אופציונלי לניקוי חיישנים לניקוי המסנן מברשת ניקוי (לוחית מטלית )אופציונלי מטלית אולטרא מיקרופייבר ()נמצאת על-גבי כיסוי מכל האבק...
Page 76
- תיאור חלקים ROBOT CLEANER מבט מישורי חיישן מצלמה עליון כיסוי מכסה אבק לחצן תצוגה ואפשרויות לחצן כיסוי מכסה אבק Tag On מבט קדמי חיישני אולטראסאונד חלון חיישן לזיהוי מכשולים, חיישני זיהוי של תחנת הבית וחיישני קליטה של השלט הרחוק מצלמה...
Page 77
תיאור חלקים - תחנת בית/מכל אבק תחנת בית מחזיק שלט רחוק מסוף טעינה מתג הפעלה קרס החזקת כבל מתח מכל אבק ידית מכל אבק מברשת ניקוי כיסוי מכסה אבק מסך פתח שאיבה מסנן ספוג לחצן פתיחה של כיסוי מכסה אבק EPA מסנן...
Page 78
- פונקציות לחצנים ROBOT CLEANER .• לחיצה על הלחצן תגדיר את מצב טורבו, עם אישור קולי TURBO .• לחיצה על הלחצן במצב טורבו תבטל את המצב .• משמש להפעלת המכשיר, להתחלת הניקוי ולהפסקתו .• לחיצה על הלחצן כאשר היחידה מופעלת תתחיל בניקוי .•...
Page 79
פונקציות לחצנים - שלט רחוק Start Home .לחיצה על לחצן זה תתחיל בניקוי Robot Cleaner משמש לטעינת (17 ’)עמ (18 ’על-ידי החזרתו לתחנת הבית. )עמ Mode Turbo (20 ’שינוי מצב הניקוי.)עמ משמש להפעלה וביטול של מצב (23 ’‘טורבו’. )עמ לחצן כיוונים לחצן...
Page 80
מידע מצב תצוגה סמל השתקה סמל מנעול סמל זה מציין אם מצב השתקה ’מציין אם ‘נעילה .פועל או מבוטל .מופעלת או לא סמל סוללה סמל החיבור מרחוק סמל זה מציין את רמת הוא מוצג כאשר הסוללה הנוכחית, ומהבהב הסמארטפון מתחבר .כאשר...
Page 81
לפני שתתחיל בדוק פריטים אלה לפני הניקוי .• אל תשתמש במכשיר זה בחדר שבו ילד נמצא לבדו. הילד עלול להיפצע .• סלק כל עצם שביר או מיותר מהחדר המיועד לניקוי .בייחוד, סלק פריטי קרמיקה יקרים וחפצי ערך מהרצפה .• סגור את כיסוי מכל האבק לפני הניקוי .•...
Page 82
מבט כולל ( 15 ’התקן את תחנת הבית. )עמ הכנס את תקע כבל המתח לשקע, והצב את התחנה .בסמוך לקיר . לא ייטעןRobot Cleaner ,אם לא יסופק מתח לתחנת הבית . Robot Cleaner -הפעל את אספקת המתח ל ( 16 ’)עמ הפעל...
Page 83
כיצד להתקין את תחנת הבית כיצד להתקין את תחנת הבית ,1. הצב את תחנת הבית כנגד קיר, על-גבי רצפה ישרה וקשיחה .כדי למנוע החלקה במהלך העגינה .סלק עצמים בטווח 5.1 מטר מימין ומשמאל ובטווח 2 מטר מלפנים .2. חבר את כבל המתח לשקע לפף...
Page 84
-כיצד להפעיל ולכבות את אספקת המתח ל Robot Cleaner הפעלת אספקת המתח הראשית Robot Cleaner ודא כי מתג ההפעלה בצדו האחורי-שמאלי של .נמצא במצב מופעל. אם המכשיר במצב כבוי, הפעל את המתג ※ בעת הפעלת מתג ההפעלה, אל תלחץ על הלחצן שבחלקו ..
Page 85
כיצד להתחיל בניקוי ולהפסיק אותו Robot Cleaner שימוש בלחצנים של START/STOP , לחץ על הלחצןRobot Cleaner לאחר הפעלת .כדי להתחיל בניקוי. תישמע מנגינה, והניקוי יתחיל במהלך מחזור הניקוי כדי להפסיקSTART/STOP לחץ על הלחצן .את הניקוי כאשר אספקת המתחSTART/STOP ※ לחיצה על הלחצן ....
Page 86
כיצד לטעון את הסוללה טעינה אוטומטית חוזר לתחנת הבית בסיום מחזור הניקוי או כאשרRobot Cleaner .הסוללה חלשה או אםRobot Cleaner ※ אם חלפו 01 דקות ללא תנועה של .הסוללה חלשה, המכשיר ייכבה באופן אוטומטי .※ אל תכבה את מתג ההפעלה הראשי, משום שהסוללה לא תיטען ,אם...
Page 87
כיצד לטעון את הסוללה מחוון טעינת הסוללה הנותרת .רמת הסוללה מצוינת בתצוגת המצב, באופן הבא .• אם מתבצעת טעינה, נורת רמת הסוללה מהבהבת .• בסיום הטעינה, רק הסמלים ‘סוללה’ ו’מצב ניקוי’ מוצגים, כדי לחסוך באנרגיה .• כשיש צורך בטעינה, רק הרמה הראשונה של נורת רמת הסוללה תופיע ותהבהב מהבהב...
Page 88
מצבי ניקוי ניקוי זיגזג חוזר על פעולתRobot Cleaner ,’במצב ‘ניקוי זיגזג .זיגזג לניקוי כל הנקודות באזור הניקוי אם ברצונך לנקות אזור מסוים במהירות, בחר במצב .’‘ניקוי זיגזג בשלט הרחוק או ביחידה הראשיתMode לחץ על הלחצן .Start כדי לבחור במצב ‘ניקוי זיגזג’, ולחץ על הלחצן .’※...
Page 89
מצבי ניקוי My Space ניקוי בשלט הרחוק תגדיר את מצבMy Space לחיצה על ., ותישמע הודעה קוליתMy Space הניקוי .לניקוי אזורים מסוימים, בחר במצב זה :שלב ראשון השתמש בשלט הרחוק לניהול ידני של הניקוי בשוליים .של בלוקי הניקוי השונים .※...
Page 90
מצבי עזר לניקוי ניקוי ידני . במצב ‘ידני’ על-ידי לחיצה על מקש כיוון בשלט הרחוקRobot Cleaner תוכל להזיז את . ינקה את האזור, תוך תנועה קדימה/אחורה/שמאלה/ימינה, בהתאם לקלט ממקש הכיווןRobot Cleaner . להתנגש במכשולים הנמצאים מאחוריוRobot Cleaner-במצב ‘ידני’, החזקת מקש התנועה אחורה תגרום ל ניקוי...
Page 91
מצבי עזר לניקוי מצב טורבו בשלט הרחוק או ביחידהTurbo לחיצה על הלחצן .הראשית תפעיל את מצב ‘טורבו’, ותישמע הודעה קולית במצב טורבו, לחיצה על אותו הלחצן תבטל את מצב .טורבו, ותישמע הודעה קולית פועל באופן אינטנסיביRobot Cleaner ,במצב טורבו .יותר, לניקוי...
Page 92
הגדרת זמן .Robot Cleaner-תוכל להגדיר את השעה הנוכחית ב , ממתיןCleaner Robot בשלט הרחוק, כאשרClock לחיצה על הלחצן .תתחיל בהגדרת השעה הנוכחית הגדר את יחידות השעות באמצעות מהבהב . בשלט הרחוקvu הלחצנים הגדר את יחידות הדקות באמצעות מהבהב . בשלט הרחוקvu הלחצנים ◀▶...
Page 93
ניקוי מתוזמן . יתחיל בו בשעה שנקבעהRobot Cleaner-תוכל לתזמן ניקוי כך ש בשלט הרחוק, כאשר הסוללה בטעינה, תתחיל בהגדרתSchedule לחיצה על הלחצן .ניקוי מתוזמן .קביעה/ביטול של ההגדרה אפשרית רק כאשר היחידה נמצאת בטעינה ’בחר באפשרות ‘הזמנה חד פעמית מהבהב או...
Page 94
(ניקוי במטלית )אופציונלי ,על-ידי חיבור המטלית האולטרא מיקרופייבר . לניקוי יעיל של אבקRobot Cleaner-תוכל להשתמש ב לאRobot Cleaner ,כאשר לוחית המטלית מחוברת יטפס על שטיחים או מעל ספים, כדי למנוע העברת לכלוך .מהמטלית שים לב אל תכסה את חיישן המצלמה התחתון .באמצעות...
Page 95
פונקציית חיפוש מיקום . זוכר את המיקום בעת הניקויRobot Cleaner במהלך הפעולה, המכשיר יחפש את המיקוםRobot Cleaner אם המשתמש יזיז את .שממנו הוזז באמצעות פונקציית הניווט לחיפוש מיקום, לפני שימשיך בניקוי Robot Cleaner-※ פונקציית הניווט תופעל לאחר ש .יזהה כראוי את סביבת הניקוי כאשר...
Page 96
אבחון חכם . משתמש בתכונה זו של ‘אבחון חכם’ לביצוע אבחון עצמיRobot Cleaner .LG Electronics אם האבחון יזהה חריגה, פנה למוקד השירות של ינוע בתוך רדיוס של כ05- ס”מ. לפיכך, ודא כי שום עצמיםRobot Cleaner ,※ במהלך האבחון החכם...
Page 97
אבחון חכם .אם תישמע הודעה קולית לאחר האבחון החכם, עיין בטבלה הבאה כדי לברר את הפעולות המתאימות (צעדים )לעיון הודעה קולית פנה את כל העצמים ברדיוס של מטר אחד מסביב לתחנת מתחיל אבחנה חכמה של ההומבוט. יש לזוז הצידה ולהזיז .הבית, והתרחק...
Page 98
פונקציית יישום חכם .ניתן לשלוט על השואב אבק הרובוטי באמצעות הסמארטפון שלך :” מספק את הפונקציות הבאותLG Roboking“ היישום • תצפית על הבית, שמירה על הבית, יומן ניקוי, תזמון ניקוי, אבחון חכם נקודת גישה בעלת גישה לאינטרנט (Android) סמארטפון שואב אבק רובוטי עם גישה לרשת...
Page 99
פונקציית יישום חכם רישום כחבר .עליך לרשום את הזיהוי שלך האישי בשרת כדי לשלוט על השואב אבק הרובוטי באמצעות הסמארטפון שלך .”[. לחץ על “כניסהStartup Screen] ” נפתחSmart ThinQ“ 1. בעת הרצת היישום .”[ שבדף ‘מסך הכניסהCreate account] 2. ניתן להירשם באמצעות הלחצן .[create account screen]-ליצירת...
Page 100
פונקציית יישום חכם כיצד לרשום את המוצר .עליך לרשום את המוצר ביישום כדי לשלוט על השואב אבק הרובוטי באמצעות הסמארטפון שלך .הוסף את השואב אבק הרובוטי באמצעות התכונה הפעלת תיוג כדי להשתמש בפונקציה החכמה .”Register product“ [. לחץ על הלחצןStartup Screen] ” נפתחSmart ThinQ“ 1. בעת הרצת היישום ...
Page 101
פונקציית יישום חכם / רישום המוצרTag On .ניתן להוסיף את השואב אבק הרובוטי בקלות ליישום באמצעות הפונקציה הפעלת תיוג . בסמארטפון שלךNFC-1. עליך לאתר את מיקום הפעלת התיוג בשואב אבק הרובוטי ואת מיקום ה []מיקום הפעלת התיוג בשואב אבק הרובוטי [2 ]רישום...
Page 102
פונקציית יישום חכם רשת המוצר / רישום המוצר .[Server connection] 1. לאחר חיבור מוצלח בסוג קטגוריית המוצר, יפתח המסך .2. בחר בנקודת גישה ברשימת הרשת, אז יופעל המצב חיבור אוטומטי כדי להתחבר לשרת .[Dashboard] 3. לאחר השלמת הרישום ייפתח מסך 4.
Page 103
פונקציית יישום חכם מסך האתחול של היישום :”Smart ThinQ“ המסך הבא ייפתח בהתחברותך הראשונה לשואב אבק הרובוטי דרך היישום ניתן לבדוק את כל .מציג את כינויו של המוצר .היסטוריית ההתראות תפריט סמל הבית בוחר את דף ,שמירה על הבית, תזמון ניקוי .רשימת...
Page 104
פונקציית יישום חכם מסך האתחול של היישום תפריט ,שמירה על הבית ,תזמון ניקוי, יומן ניקוי .אבחון חכם, הגדרה תצפית על הבית ניתן להשתמש בפונקציית השלט רחוק לסקירת המרחב שמסביב לשואב אבק הרובוטי .באמצעות המצלמה הקדמית תפריט מצב ,מצב ניקוי, מצב חזרה על הניקוי .מצב...
Page 105
פונקציית יישום חכם (תצפית לבית )תצורת הממשק :עם פתיחת התצפית לבית יופיעו סמלי הבקרה הבאים על המסך תפריט ראשי של התצפית לבית .כל לחצן מפעיל פונקציה מסוימת סמלי מצב ,, הסוללהWi-Fi-כאן מוצגים ה ,לו”ז הניקוי, המצב טורבו ,החזרה על הניקוי .המצב...
Page 106
פונקציית יישום חכם (תצפית לבית )ניקוי .”ניתן לעבור מהמצב תצפית לבית למצב ניקוי ולגרום לשואב אבק הרובוטי להתחיל לנקות ע”י לחיצה על “התחל לנקות []ממתין לתחילת הניקוי ”לחץ על “התחל לנקות” למעבר למצב ניקוי. ניתן לבחור במצב ניקוי אחר ע”י לחיצה על הלחצן “הגדרת מצב .”לפני...
Page 107
פונקציית יישום חכם (תצפית לבית )חזרה ליחידת הטעינה לחץ על “התחל טעינה” כאשר סוללת השואב אבק הרובוטי חלשה כדי שהוא יתחיל לחפש את יחידת .הטעינה. לחץ על “עצור” כדי שהשואב אבק הרובוטי יפסיק את החיפוש []בטעינה []התקדמות לעבר יחידת הטעינה (תצפית...
Page 108
פונקציית יישום חכם (תפריט - שמירה על הבית )המסך הראשי השמירה על הבית מאפשרת לך לפקח עליו באמצעות המצלמה של השואב אבק הרובוטי ממיקומו כאשר .הנך רחוק מביתך. השואב אבק הרובוטי יצלם כל תנועה שהוא מזהה וישלח לך תמונות כהתראות .(”)ניתן...
Page 109
פונקציית יישום חכם (תפריט - שמירה על הבית )הגדרת מיקום לאתחול שמירה על הבית, תחילה, עליך להגדיר את המיקום בו יוצב השואב אבק הרובוטי בעת היותו .במצב זה. בחר במיקום במפה הווירטואלית .1. לחץ על מיקום היעד על המפה או גרור את השואב אבק הרובוטי למיקום הרצוי באזור המיועד לפיקוח .ניתן...
Page 110
פונקציית יישום חכם (תפריט - שמירה על הבית )הגדרת מיקום .3. בדוק אם המיקום הוא משביע רצון בהתאם לשדר הווידאו ולחץ על “שמירה” להשלמת הגדרת המיקום []שומר על הגדרת המיקום טיפ • השואב אבק הרובוטי מחפש את המיקום הנשמר תוך התייחסות ליחידת הטעינה כמיקום .המוצא, לכן...
Page 111
פונקציית יישום חכם (תפריט - שמירה על הבית )התראה בעת זיהוי תנועה כלשהי כאשר הוא במצב שמירה על הבית, השואב אבק הרובוטי מצלם את המרחב ושולח התראה לסמארטפון שלך. אנא לחץ על “אישור” בחלון הקופץ, לצפייה בתמונה, או השתמש בפונקציות ”“שיחה”...
Page 112
פונקציית יישום חכם תפריט - תזמון ניקוי .ניתן לתזמן את פעולת השואב אבק הרובוטי לתזמון הניקוי, עבור למקש תזמון הניקוי להפעלתו או השבתתו בתפריט תזמון הניקוי. לאחר הפעלת תזמון .הניקוי, הגדר את השעה ואת החזרה ולאחר מכן לחץ על “שמור” להשלמת התזמון טיפ...
Page 113
פונקציית יישום חכם תפריט - יומן הניקוי .ניתן להציג את היומן כדי לבדוק מתיי שואב אבק הרובוטי ניקה יומן הניקוי שומר על מידע כגון התאריך, המצב ושעות התחלתו .וסופו של כל ניקוי לחץ על הלחצן הרצה בצד הימין של רשימת הניקויים שהושלמו .והפעל...
Page 114
.לחץ על “התחל אבחון חכם” במהלך הטענת השואב אבק הרובוטי הקפד לפתור כל בעיה שזוהתה באבחון ע”י נקיטה בצעד המתאים. אם התסמין נמשך, פנה למרכז .LG Electronics שירות הלקוחות של טיפ 29-• הפונקציה אבחון חכם שביישום היא זהה לזאת שבשלט הרחוק. עיין בדף 82 וב...
Page 115
פונקציית יישום חכם תפריט – הגדרה .ניתן לבדוק או לשנות את המידע הנוכחי שהוגדר בשואב אבק הרובוטי .לחץ על קול גברי/נשי לשינוי קולו של השואב אבק הרובוטי לקול גבר או אישה לחץ על כינוי המוצר לשינוי הכינוי הנוכחי של השואב אבק הרובוטי ;אז יופיע חלון קופץ בו ניתן להזין .(כינוי...
Page 116
פונקציית יישום חכם שונות. 1 - עדכון תוכנה .הדגם המותאם לרשת של השואב אבק הרובוטי יכול לעדכן את התוכנה באופן אוטומטי באמצעות היישום ,. )אם יישום זה אינו מעודכן לגרסה העדכנית ביותרPlay ” מעודכן בחנותSmart ThinQ“ 1. ודא שהיישום .(עדכון התוכנה לא יהיה זמין ....
Page 117
פונקציית יישום חכם שונות. 2 - מצב .ניתן להפעיל את השואב אבק הרובוטי ללא התחברות לרשת, באמצעות הפונקציה מצב לפונקציה מצב יש 4 פונקציות. לחיצה על הלחצן “מיושם” תפעיל את השואב אבק הרובוטי לפי המצב .המתואר להלן מצב מסע הביתה: התחל בחיפוש יחידת הטעינה מצב...
Page 118
.2. לחץ על “התחל/עצור” לאתחול המוצר; המכשיר ייכבה בליוויRobot Cleaner 3. לחיצה חוזרת על “התחל/עצור” תפעיל את .מנגינה מספקתLG Electronics ※ כל סכסוך בין המוכר לקונה היא נחשבת כבעיה בין שני צדדים אלו. חברת .פונקציה לאתחול המוצר להקלה על העברתו טיפ...
Page 119
ניקוי מכל האבק .אם מכל האבק מלא, תיתכן פגיעה בעוצמת השאיבה. נקה את מכל האבק לפני ואחרי כל הפעלת ניקוי :נקה את מכל האבק בסדר הבא 1. פתח את כיסוי מכל האבק על-ידי לחיצה על הלחצן .Robot Cleaner- בPUSH .2. אחוז בידית מכל האבק, ומשוך כלפי מעלה 3.
Page 120
ניקוי מסנן מכל האבק . ומסנן ספוגEPA מסנן מכל האבק כולל מסנן . והספוג בסדר הבאEPA-נקה את מסנני ה 1. משוך את הקרס שמשמאל למודול מסנן , בצדו האחורי של מכל האבקEPA-ה . והספוגEPA-כדי להפריד את מסנן ה מחלקיקי האבק הקטניםEPA-2. נקה היטב את מסנן ה .באמצעות...
Page 121
ניקוי המברשת ., עוזרת באיסוף האבקCleaner Robot המברשת המסתובבת, הנמצאת בצדו התחתון של .נקה את המברשת בסדר הבא .※ לפני הפיכת היחידה הראשית, הנח מטלית לחה על-גבי הרצפה, והוצא את מכל האבק .אם לא, היחידה הראשית עלולה להישרט, ואבק יישפך ממכל האבק באמצעות...
Page 122
ניקוי חיישן/מסוף הטעינה כולל חיישנים המאתרים מכשולים, מדרגות ואת תחנתRobot Cleaner ,Robot Cleaner הבית לטעינת הסוללה. כדי לשמור על ביצועי :נקה באופן שוטף את החיישנים ואת מסוף הטעינה באופן הבא .Robot Cleaner 1. הפעל את מתג ההפעלה בחלקו התחתון של ...
Page 123
ניקוי המברשת הצדית .עצמים/חומרים זרים כגון שערות עלולים להיצמד בקלות למברשת הצדית .יש לסלק חומרים כאלה פעם בשבוע לפחות ,במקרה של כמויות חריגות של חומרים זרים הנתקעים במברשת .קיים סיכון לנזק למברשות .אם הרצפה מחוספסת או שהקירות מנוקים בתדירות גבוהה, המברשת הצדית עשויה להתכופף או להינזק .במקרה...
Page 124
(ניקוי מטלית אולטרא מיקרופייבר )אופציונלי .כדי למנוע ריחות לא נעימים, יש לשטוף לכלוך ואבק מהמטלית לאחר השימוש בו לצורך ניקוי :בצע הנחיות אלה לשטיפת מטלית האולטרא מיקרופייבר .1. הפרד את מטלית האולטרא מייקרופייבר מלוחית הסמרטוט 012 מ”מ .2. נקה בזהירות באמצעות מים חמימים .3.
Page 125
פתרון בעיות :בהישמע ההודעה הקולית "."הגלגלים אינם נוגעים ברצפה. יש להזיז את ההומבוט לרצפה שטוחה .הודעת אזהרה תינתן במקרה שבו גלגל מסוים אינו נוגע במשטח הרצפה מסיבה כלשהי ?• האם הגלגל לכוד בדלת הקדמית, במרפסת, במדרגות וכדומה . אל הרצפה השטוחהRobot Cleaner ◀ הזז את :בהישמע...
Page 126
פתרון בעיות :בהישמע ההודעה הקולית "."יש לבדוק כי מיכל האבק והמסנן מותקנים כיאות .תינתן הודעת אזהרה אם מכל האבק או כיסוי המסנן אינן מורכבים ?Robot Cleaner-• האם מכל האבק מחובר ל .◀ פתח את כיסוי מכל האבק וודא כי מכל האבק מורכב במקומו .◀...
Page 127
פתרון בעיות :בהישמע ההודעה הקולית "."יש להזיז חומרים זרים מהמברשת שבתחתית ההומבוט .הודעת אזהרה תינתן במקרה שבו חומרים זרים מגבילים את סיבוב המברשת . עליה במצב הפוךRobot Cleaner הנח מטלית רכה על-גבי הרצפה, והנח את .※ לפני הפיכת היחידה הראשית, הסר את מכל האבק .אחרת, מכל...
Page 128
.השלט הרחוק (16 ◀ ודא כי מתג החשמל נמצא במצב פועל. )עמוד .※ לשיפור איכות היישום, אנו עשויים לערוך לו שינויים ללא הודעה מבלי להודיע מראש ללקוחות (http://www.lg.com)- בLEG ניתן להוריד את מדריכי המשתמש של היישומים שנערכו להם שינויים מאתר...
Page 129
מפרטי מוצר פריט/דגם LG Robot Cleaner VR648** Ser. ממדים חיצוניים 98 × 043 × 043 מ”מ 85 ואט צריכת חשמל 3 ק”ג משקל (סוללה )טעינה מלאה DC 16.8 V (053 מ”מ/ש’ )מרבית מהירות נסיעה כ001- דקות זמן שימוש ()בהתבסס על רצפת עץ כללית...
Page 130
פריטי עיון הודעה של תוכנת מקור פתוח , ורישיונות מקור פתוח אחריםMPL ,LGPL ,GPL כדי לקבל את קוד המקור הכלול במוצר זה במסגרת .http://opensource.lge.com בקר באתר בנוסף לקוד המקור, כל תנאי הרישוי, סייגים באחריות והודעות זכויות היוצרים המאוזכרים הינם זמינים .להורדה...
Page 131
השלכת סוללות/מצברים לאשפה מצורף לסוללות/מצברים של המוצר, פירוש הדבר הוא שהם מכוסיםX-1. כאשר סמל זה של פח אשפה מסומן ב .CE/66/2006 בהנחיית האיחוד האירופי ( אם הסוללה מכילהPb) ( או עופרתCd) (, קדמיוםHg) 2. סמל זה עשוי להופיע לצד סימונים כימיים עבור כספית .יותר...
