- Page 1 Conventional Flue Installation, Servicing and User Guide PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE GB & IE For use in (United Kingdom and Ireland) BS EN 613: 2001 + A1: 2003 +C1:2008 BK743 SPECIFIC Rev 02 ISSUE DATE : 16/12/2020...
- Page 2 Should you have any questions about your stove which are not covered by this manual, please contact the Arada retailer in your area, call our technical support department on +44 (0)1297 632052 or visit our website www.aradastoves.com which offers a wealth of information on how to care for,...
-
Page 3: Table Of Contents
4.5 Fire Control Valve—Red Indicator Meaning…………………. 26-27 4.6 Using The Remote Display Handset………………………….. 4.7 Trouble Shooting / FAQ ………………………………………… 28-32 4.8 Remote Display Handset Optional Features………………….. 5 Guarantee 5.1 Guarantee………………………………………………………... 33-34 5.2 Terms & Conditions……………………………………………… 5.3 General……………………………………………………………. 5.4 Notes………………………………………………………………. BK743 Page 3... -
Page 4: Appliance Information
Any purpose made ventilation must be checked periodically to ensure that it is free from obstruction. PLEASE NOTE—The stove is a very heavy appliance and care must be used when lifting and moving, we recommend 2 people lift following lifting guidelines. Preferably wear gloves when lifting. Page 4 BK743... -
Page 5: Flue & Chimney Suitability
/ flue, again do not proceed until the fault has been fixed. A tested and certificated flue terminal or cowl suitable for the relevant flue type should be considered. A spillage test must always be carried out during commissioning of this appliance. BK743 Page 5... -
Page 6: Installation
300 mm Left Right 100 mm 300 mm NOTE : Fitting the stove any closer to the back may cause nuisance shutdown of the stove as the airflow may be compromised and the thermal cut off will operate. Page 6 BK743... -
Page 7: Flue Connection
Once the frame has been removed, the 4 no. fixings, holding the burner in place can be removed and access to the gas inlet elbow can be gained. Once the connection has been made and soundness verified the burner can be replaced ensuring correct position and the 4no. fixings replaced. BK743 Page 7... -
Page 8: Placement Of The Ceramic Logs
Ecoburn (S3) Gas CF Stove Installation and Servicing 2.6 - PLACEMENT OF THE CERAMIC LOGS WARNING —DO NOT CHANGE THE FUEL BED LAYOUT, THE TYPE OR NUMBER OF LOGS. Contents Of Log Fuel Effect Kit - Page 8 BK743... - Page 9 STEP 1 Scatter the bag of embers, evenly over the grate and burner, as shown above, ensuring the pilot and pilot shield are left clear from embers as indicated. STEP 2 Place Log 1 as shown above. BK743 Page 9...
- Page 10 Ecoburn (S3) Gas CF Stove Installation and Servicing STEP 3 Position Log 2 as shown above. Note, this log rests upon the corner of log 1. STEP 4 Position Log 3 as shown above. Page 10 BK743...
- Page 11 Ecoburn (S3) Gas CF Stove Installation and Servicing STEP 5 Position Log 4 as shown above, centrally at the rear of the burner. STEP 6 Position Log 5 as shown above, centrally resting upon Logs 2 & 4. BK743 Page 11...
- Page 12 Position Log 7 as shown above. Note, this log sits on top of Log 6, Log 5 & Log 3 as shown with the arrows. The pine cone sits in the RH corner, as shown. NOTE : Check that the Pilot is clear and cross lights smoothly to the main burner. Page 12 BK743...
-
Page 13: Operating Instructions
Battery Compartment Release Lever Indicator Light Power Isolator Switch Decrease Flame Battery Compartment Cover Power Button Increase Flame Below the remote control handset. Visual Display Lock / Unlock LED Increase Flame Decrease Flame Power Button BK743 Page 13... - Page 14 Flashing Once A Second Valve Detects An Error Permanently Off Valve In Standby Or In A Stable Operation On Momentarily After Power Up Valve Doing A Self Test Appears After Pressing Start Indicates Time To Release Pressing The Start Button Page 14 BK743...
- Page 15 The handset is designed to be not too easily operated by accident for safety reasons. If for any reason the pairing has been altered, then the handset will not work. Note, by removing or replacing the batteries, the pairing will NOT be lost. BK743 Page 15...
- Page 16 + & - to adjust for the preferred heat setting. To Stop the stove, hold handset to unlock the buttons and then press the power button. The flame stops almost immediately. Page 16 BK743...
-
Page 17: Spillage
8. The flue will need sweeping periodically for safe use of the appliance. 3.1 REPLACEMENT PARTS Genuine replacement spare parts can be obtained from www.aradastovesandspares.com or your Arada dealer. Please note, that fitting non-official Arada parts to your stove will invalidate the guarantee. BK743 Page 17... - Page 18 Ecoburn (S3) Gas CF Stove Installation and Servicing ECOBURN (S3) GAS STOVE ARADA Ltd THE FIREWORKS WEYCROFT AVENUE AXMINSTER DEVON EX13 5HU NG : APPLIANCE IS CATEGORY I2H FOR USE WITH NATURAL GAS AT A SUPPLY PRESSURE OF 20 mbar.
-
Page 19: Important Information
THIS SYSTEM IS NOT ADJUSTABLE AND MUST NOT BE PUT OUT OF ACTION. IF REQUIRED TO BE REPLACED; ONLY ORIGINAL MANUFACTURERS PARTS MUST BE USED (IF THE STOVE SWITCHES OFF FOR NO APPARENT REASON THE APPLIANCE SHOULD NOT BE USED UNTIL EXPERT ADVICE IS TAKEN). BK743 Page 19... -
Page 20: Layout Of Ceramic Logs
STEP 1 Scatter the bag of embers, evenly over the grate and burner, as shown above, ensuring the pilot and pilot shield are left clear from embers as indicated. STEP 2 Place Log 1 as shown above. Page 20 BK743... - Page 21 Ecoburn (S3) Gas CF Stove User Guide STEP 3 Position Log 2 as shown above. Note, this log rests upon the corner of log 1. STEP 4 Position Log 3 as shown above. BK743 Page 21...
- Page 22 Ecoburn (S3) Gas CF Stove User Guide STEP 5 Position Log 4 as shown above, centrally at the rear of the burner. STEP 6 Position Log 5 as shown above, centrally resting upon Logs 2 & 4. Page 22 BK743...
- Page 23 Position Log 7 as shown above. Note, this log sits on top of Log 6, Log 5 & Log 3 as shown with the arrows. The pine cone sits in the RH corner, as shown. NOTE : Check that the Pilot is clear and cross lights smoothly to the main burner. BK743 Page 23...
-
Page 24: Operating Control Locations
(Flames Shown When Lit) Room Temperature Battery Condition Indicator (Alternates between RC— Handset Battery & FC –Valve Battery) Green Unlock Light Light Sensor Set Button (For Backlit Display) Increase Button Mode Button Decrease Button Power / Standby Page 24 BK743... -
Page 25: Battery Replacement
Flashing Once A Second Valve Detects An Error Permanently Off Valve In Standby Or In A Stable Operation On Momentarily After Power Up Valve Doing A Self Test Appears After Pressing Start Indicates Time To Release Pressing The Start Button BK743 Page 25... -
Page 26: Using The Remote Display Handset
- button to reduce the flame. Tapping the button will adjust the flame step by step. Holding the button will skip through the steps. Similarly, press the + button to increase the flame as described. Page 26 BK743... -
Page 27: Trouble Shooting / Faq
If the stove has been running allow to cool and operate the appliance using the fire control valve, to rule out faults with the appliance or remote handset. All remaining scenarios please contact a gas safe engineer, to verify the flue system and fault code analysis, to determine the problem. BK743 Page 27... - Page 28 Press “SET” to accept the day of the week and to progress to setting the Hour of the day. Note: Whilst doing this setup pressing “SET” advances to the next display and pressing “MODE” will return you to the previous display setting. Page 28 BK743...
- Page 29 NOTE: PRESS “+” Button ONLY , NOT “+” and “-‘ Together as you will accidentally break the hand- set pairing and have to reset handset to factory state and pair again (See other parts of the booklet if this happens). BK743 Page 29...
- Page 30 Press the set button again to see the temperature setting that is set and the mode (the default is 24 C ) and on the left of the display is a sun symbol showing it’s the day temperature. Page 30 BK743...
- Page 31 To put the fire into thermostat timer mode press and release the mode button until the thermostat and timer symbols are displayed on the display at the top. Press and release the “SET” button and the control will now run the timed program set up in the memory. BK743 Page 31...
- Page 32 8 times until CP0 is flashing on the display use the + and – buttons to change the display to CP1 – press SET – press SET again and the display will return to standby Manual mode and the timer setting have been completely removed for the timer memory. Page 32 BK743...
-
Page 33: Guarantee
SECTION 5. GUARANTEE 5.1 - GUARANTEE When you buy an Arada stove, you are not only buying a first class appliance, you are receiving a commitment from us to look after you and your appliance. If any part of the main body of the stove fails due to a manufacturing or material defect during the guarantee period that applies in respect of the relevant stove (as set out below), Arada will, at its sole discretion, repair or replace your stove, for no charge. -
Page 34: General
11. The guarantee is only valid where any spare parts used are supplied by Arada or an approved Arada dealer. The use of spares other than those supplied by Arada Limited shall invalidate the guarantee. -
Page 35: Notes
Ecoburn (S3) Gas CF Stove User Guide 5.4 - NOTES - BK743 Page 35... - Page 36 Ecoburn (S3) Gas CF Installation, Servicing and User Guide All Arada Stoves are manufactured in the UK Arada Ltd The Fireworks, Weycroft Avenue - Axminster - Devon EX13 5HU United Kingdom www.aradastoves.com T: +44 (0)1297 632050 Email : info@aradastoves.com Applicable Model Code : ECBGAS-S3-LOG DATE OF ISSUE—16/12/2020...
